Wall / ceiling / stand /
bracket sold
separately
Installation Safety Notes.....................................................................................................................2
Parts List.............................................................................................................................................4
Installation Instructions.......................................................................................................................6
Sample Installations...............................................................................................................................10
Product Dimensions..........................................................................................................................11
B-Tech Contact Details.....................................................................................................................12
INSTALLATION TOOLS REQUIRED
B-TECH AUDIO VIDEO MOUNTS
BT7505
UNIVERSAL FLAT SCREEN ADAPTOR PLATE
INSTALLATION GUIDE & PARTS LIST
This Pack Contains 1 Adaptor Pate
PLEASE KEEP THIS FOR FUTURE REFERENCE
Actual screen size & weight limit
dependant on mount to which
BT7505 is attached
CONTENTS
www.btechavmounts.com
FEATURES
●
Designed for flat screens up to 40" (101cm) / 40kg (88lbs)
●
Universal adaptor kit to allow fitting of Non-VESA screens to
75 x 75mm and 100 x 100mm VESA mounts
●
Simple installation with all mounting hardware included
●
Must be used with a 75 x 75mm or 100 x 100mm
VESA flat screen mount (BT7510 / BT7511 / BT7512 / BT7513
/ BT7514 / BT7515 / BT7518 / BT7519 / BT7521 / BT7522)
Crosshead
screwdriver
Advertisement
Related Manuals for B-Tech mountlogic range BT7505
Summary of Contents for B-Tech mountlogic range BT7505
-
Page 1: Table Of Contents
Actual screen size & weight limit bracket sold dependant on mount to which separately BT7505 is attached CONTENTS Installation Safety Notes........................2 Parts List.............................4 Installation Instructions........................6 Sample Installations..........................10 Product Dimensions..........................11 B-Tech Contact Details........................12 INSTALLATION TOOLS REQUIRED Crosshead screwdriver B-TECH AUDIO VIDEO MOUNTS www.btechavmounts.com... -
Page 2: Installation Safety Notes
Do not attempt to install this product until all instructions and warnings have been read and properly understood. Please keep these instructions for future reference. B-Tech International Limited, its distributors and dealers are not liable or responsible for damage or injury caused by improper installation, improper use or failure to observe these safety instructions. - Page 3 Niniejszy produkt musi być zamontowany na odpowiedniej powierzchni, a podczas użytkowania nie wolno przekraczać podanego maksymalnego obciążenia. A B-Tech International Ltd. recomenda que a instalação deste produto seja efectuada por um instalador de AV profissional ou outra pessoa devidamente habilitada. A B-Tech International Ltd. e os seus distribuidores e concessionários não são responsáveis por danos ou lesões causados por uma instalação incorrecta.
-
Page 4: Parts List
BT7505 PARTS LIST Suitable for loads up to 40kg (88lbs) - Page 5 PART NAME ADAPTOR PLATE INTERFACE ARM M5 METAL WASHER M5 x 12mm SCREW INTERFACE KIT M4 x 12mm SCREW M4 x 16mm SCREW M4 x 25mm SCREW M4 x 40mm SCREW M5 x 25mm SCREW M5 x 50mm SCREW M6 x 12mm SCREW M6 x 25mm SCREW M5 METAL WASHER M5 x 12mm SPACER...
-
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS Attach adaptor plate to a 75 x 75mm or 100 x 100mm interface plate. BT7510 INTERFACE PLATE... - Page 7 Slide the interface arms onto the adaptor plate.
- Page 8 Fix the interface arms to the flat screen. FLAT SCREEN A B C D E F...
- Page 9 Fix the interface arms to the adaptor plate. FLAT SCREEN...
-
Page 10: Sample Installations
SAMPLE INSTALLATIONS The BT7505 must be used with a 75 x 75mm or 100 x 100mm mount BT7505 (BT7510 / BT7511 / BT7512 / BT7513 / BT7514 / BT7515 / BT7518 / BT7519 / BT7521 / BT7522) BT7505 BT7521 BT7511 BT7505 BT7514... -
Page 11: Product Dimensions
PRODUCT DIMENSIONS 570mm 22.4" 123mm 4.8" 20mm 0.8" 588mm 23.1" ADAPTOR PLATE 100mm 3.9" 75mm 3" 500mm 19.7" THESE INSTRUCTIONS ARE INTENDED AS A GUIDE ONLY AND B-TECH ACCEPTS NO LIABILITY FOR THE ACCURACY OF THE INFORMATION CONTAINED IN THIS DOCUMENT. -
Page 12: B-Tech Contact Details
©2010 Bennett Technologies Limited. All rights reserved. B-Tech Audio Video Mounts is a division of Bennett Technologies Limited. B-Tech, Better By Design & Mountlogic are registered trademarks of Bennett Technologies Limited. All other brands and product names are trademarks of their respective owners.
