B-Tech BT7340 Assembly And Installation

BT7340
WEBCAM SHELF
ASSEMBLY AND INSTALLATION
• Designed to support a webcam above a pole mounted screen
• Maximum webcam footprint: W 82 (3.2"), D 102mm (4")
• Adjusts to be used with screens 15" – 22" (widescreen)
• Designed to be used with the BT7320, BT7321, BT7332 or BT7333
• Maximum load: 1Kg (2.2lbs)
• All fixings included
Head Office
B-Tech International Ltd.
Bennett House, Long March, Daventry, Northants NN11 4NR, UK
Tel: +44 (0)1327 300 787 Fax: +44 (0)1327 706 562
Email: info@btechavmounts.co.uk
Made in China
This pack contains:
1 webcam shelf
110 mm (4.3")
82 mm (3.2")
Europe
B-Tech PRO-AV bvba
Brixtonlaan 32, Zaventem 1930,Brussels, Belgium
Tel: +32 (0)2 720 92 71 Fax: +32 (0)2 725 42 15
Email: info@btechproav.com
www.btechavmounts.com
Copyright 2008.
©
This webcam shelf is intended for use only with the maximum
Caution:
Do not exceed the maximum weight limit indicated for this product.
weights indicated. Use with heavier than the maximum
Failure to comply may cause instability and possible serious injury.
indicated may result in instability causing possible injury.
Important Safety Instructions.
Read first
Do not attempt to install this product until all instructions and warnings have been read and
properly understood. Please keep these instructions for future reference.
B-Tech International Limited, its distributors and dealers are not liable or responsible for
damage or injury caused by improper installation, improper use or failure to observe these
safety instructions. In such cases, all guarantees will expire.
General
B-Tech International Ltd recommends that a professional AV installer or other suitably qualified
person install this product. Great care must always be taken during installation as most AV
equipment is of a fragile nature, possibly heavy and easily damaged if dropped.
If you do not fully understand the instructions or are not sure how to install this product safely,
then please consult a professional for advice and/or to install this product for you. Failure to
mount this product correctly may cause serious injury or death both during installation and at
any time thereafter.
Do not mount any AV equipment that exceeds the specific weight limit of the product you are
installing. This weight limit will be clearly stated on each product and its packaging and will
vary from product to product.
Product location
Please pay careful attention to where this product is located.
Fixing hardware
It is highly recommended that all fixing screws be used where supplied and that the purpose of
all other fixing hardware is fully understood. In some cases more AV equipment fixing
hardware will be supplied to accommodate different models of equipment and set up
configurations.
The installer must be satisfied that any supplied fixing hardware is suitable for each specific
installation. If any fixing screws or included hardware are deemed not sufficient for a safe
installation then please consult a professional or your local hardware store.
Hazard limitation
When routing cables take advantage of any built in cable management features that the
product might provide and ensure that all cables are tidy and secure. Check to see that any
moving aspect of the product can do so unhindered by any cabling.
Some products have moving parts and the potential to cause injury through the crushing or
trapping of fingers or other body parts.
Particular attention to the nature of moving parts is required especially when assembling
installing and adjusting during set up.
Immediately after installations double-check that the work done is safe and secure. Double-
check all necessary fixings are present and are of ample tightness.
It is recommended that periodic inspections of the product and its fixing points are made as
frequently as possible to ensure that safety is maintained. If in doubt consult a professional AV
installer or other suitably qualified person.
North America
B-Tech Audio Video Mounts .
10 Greg Street, #108, Sparks, NV 89431, USA
Tel: (1)800 975 5812 Fax: (1)800 592 2876
Email: info@btechavmounts.com
v1208 OR1BX
Asia Pacific
B-Tech International (Hong K ong) Ltd .
23rd Floor, Manulife Tower, North Point, HK
Tel: (+852) 2556 7337 Fax: (+852) 2556 7321
Email: info@btechavmounts.com.hk
PAGE 1 / 3
