B-Tech BT7165 Installation Manual & Parts List

Av component glass shelf
Hide thumbs

Advertisement

Quick Links

Download this manual
BT7165
AV COMPONENT GLASS SHELF
INSTALLATION GUIDE & PARTS LIST
This Pack Contains 1 Shelf
PLEASE KEEP THIS FOR FUTURE REFERENCE
Installation Safety Notes.....................................................................................................................2
Parts List.............................................................................................................................................4
Installation Instructions.......................................................................................................................6
Sample Installations..........................................................................................................................18
Product Dimensions..........................................................................................................................19
B-Tech Contact Details.....................................................................................................................20
INSTALLATION TOOLS REQUIRED
B-TECH AUDIO VIDEO MOUNTS
FEATURES
●
Designed for AV equipment up to 7.5kg (17lbs)
●
Shelf dimensions-:
450mm (17.7") x 320mm (12.6")
●
Fixes to BT8010 Flat screen wall unit and
BT8505 Flat screen trolley
●
10mm (0.4") thick tempered safety glass
●
Meets British Standard BS6206
CONTENTS
Crosshead
screwdriver
www.btechavmounts.com
CAUTION!! GLASS
This item contains glass -
Handle with care to avoid
damage or injury

Advertisement

loading
Need help?

Need help?

Do you have a question about the BT7165 and is the answer not in the manual?

Questions and answers

Related Manuals for B-Tech BT7165

Summary of Contents for B-Tech BT7165

  • Page 1: Table Of Contents

    CAUTION!! GLASS This item contains glass - Handle with care to avoid damage or injury CONTENTS Installation Safety Notes........................2 Parts List.............................4 Installation Instructions........................6 Sample Installations..........................18 Product Dimensions..........................19 B-Tech Contact Details........................20 INSTALLATION TOOLS REQUIRED Crosshead screwdriver B-TECH AUDIO VIDEO MOUNTS www.btechavmounts.com...

  • Page 2: Installation Safety Notes

    Do not attempt to install this product until all instructions and warnings have been read and properly understood. Please keep these instructions for future reference. B-Tech International Limited, its distributors and dealers are not liable or responsible for damage or injury caused by improper installation, improper use or failure to observe these safety instructions.
  • Page 3 Niniejszy produkt musi być zamontowany na odpowiedniej powierzchni, a podczas użytkowania nie wolno przekraczać podanego maksymalnego obciążenia. A B-Tech International Ltd. recomenda que a instalação deste produto seja efectuada por um instalador de AV profissional ou outra pessoa devidamente habilitada. A B-Tech International Ltd. e os seus distribuidores e concessionários não são responsáveis por danos ou lesões causados por uma instalação incorrecta.

  • Page 4: Parts List

    BT7165 PARTS LIST Suitable for loads up to 7.5kg (17lbs)
  • Page 5 PART NAME GLASS SHELF SHELF BASE M5 x 12mm SCREW M8 HANDWHEEL   PLEASE KEEP THIS FOR FUTURE REFERENCE...

  • Page 6: Installation Instructions

    INSTALLATION INSTRUCTIONS Shelf Installations: A) BT8010 FLAT SCREEN WALL MOUNT UNIT (page 7) B) BT8505 FLAT SCREEN DISPLAY TROLLEY (page 13) Fix the shelf base to either the wall unit or trolley. WARNING Attach shelf to wall unit or trolley before assembling the wall unit or trolley A) BT8010 FLAT SCREEN WALL MOUNT UNIT (page 7).
  • Page 7 BT8010 FLAT SCREEN WALL MOUNT UNIT Remove plastic covers. Remove lower wall plate.
  • Page 8 Slide the shelf base onto the wall unit.
  • Page 9 Move shelf base to desired height then fix in place. WARNING Ensure handwheels are fully tightened.
  • Page 10 Re-Attach the lower wall plate to the wall unit.
  • Page 11 COMPLETE BT8010 MOUNTING BEFORE CONTINUING WITH NEXT STEP. Place on the glass shelf and secure in place. i. Place on the glass shelf.
  • Page 12 ii. Secure in place using part 3.
  • Page 13 BT8505 FLAT SCREEN DISPLAY TROLLEY Remove the plastic column cap. Loosen the adaptor handwheels then slide the adaptor off the column.
  • Page 14 Slide the shelf base onto the trolley column. Fix the shelf attachment in place by tightening the handwheels. WARNING Ensure handwheels are fully tightened.
  • Page 15 Re-attach the adaptor plate onto the trolley column and then fix in place. Re-attach the plastic column cap onto the top of the trolley.
  • Page 16 COMPLETE BT8505 ASSEMBLY BEFORE CONTINUING WITH NEXT STEP. Place on the glass shelf and secure in place. i. Place on the glass shelf.
  • Page 17 ii. Secure in place using part 3.

  • Page 18: Sample Installations

    SAMPLE INSTALLATIONS FLAT SCREEN FLAT BLU-RAY SCREEN PLAYER BT7165 BT8010 BLU-RAY PLAYER BT8505 BT7165...

  • Page 19: Product Dimensions

    BT7165 PRODUCT DIMENSIONS 450mm 17.7" GLASS SHELF 100mm 3.9" 450mm 17.7" 100mm 3.9" THESE INSTRUCTIONS ARE INTENDED AS A GUIDE ONLY AND B-TECH ACCEPTS NO LIABILITY FOR THE ACCURACY OF THE INFORMATION CONTAINED IN THIS DOCUMENT.

  • Page 20: B-Tech Contact Details

    ©2010 Bennett Technologies Limited. All rights reserved. B-Tech Audio Video Mounts is a division of Bennett Technologies Limited. B-Tech, Better By Design & Mountlogic are registered trademarks of Bennett Technologies Limited. All other brands and product names are trademarks of their respective owners.
