BASIC OPERATION

MODE
1h
FAN
SWING
SET/C
When using your air-conditioner with multi-system
(GS-XPM9FGR,GS-XPM12FGR,GS-XPM18FGR)
With a multi system air conditioner, multiple indoor units can be connected to one outdoor
unit. When the setting mode differs among indoor unit(s), the indoor unit(s) operated later
may not work.
• When the indoor unit(s) is/are operating in HEAT mode, the remaining unit(s) can not operate in
COOL or DRY mode.
• When the indoor unit(s) is/are operating in COOL or DRY mode, the remaining unit(s) can not
operate in HEAT mode.
When the mode of the indoor unit(s) later operated is/are different from those which is /are in
operation, after a few seconds, a long BEEP will be emitted and the OPERATION lamp and
TIMER lamp will blink alternately. This shows that the later operated unit(s) is/are not working. In
such case, change the mode to the same mode which the other indoor unit(s) is/are operating in.
Press the MODE button to select the op-
1
eration mode.
Press the ON/OFF button to start opera-
2
tion.
• The red OPERATION lamp (
will light.
2
5
Press the THERMOSTAT button to set the
3
desired temperature.
• In the AUTO and DRY
3
modes, the tempera-
ture can be changed
1
in 1°C increments
within the range of 2°C
higher to 2°C lower
from the temperature
automatically deter-
4
mined by the air con-
ditioner.
• In the COOL and HEAT modes, the tempera-
ture can be set within the range of 18 to 32°C
Press the FAN button to set the desired fan
4
speed.
• In the DRY mode, the fan speed is preset to
AUTO and cannot be changed.
To turn off the unit, press the ON/OFF but-
5
ton again.
• The red OPERATION lamp (
will turn off.
E-8
AUTO
HEAT
COOL
(Example: 1°C higher)
(Example: 2°C lower)
AUTO
SOFT
LOW
DRY
) on the unit
C
C
HIGH
) on the unit
