Courtyard Creations KFS777U- Assembly Instructions

Advertisement

ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE

PARTS LIST

PART
MATERIAL CODE
NO.
1
KFS777U-CS04-6
2
KFS777U-CS02-1
3
KFS777U-CS01-2
4
KFS777U-CS01-3
5
17C33A0755001Y4
6
17C33A0706001Y4
7
17C02A0755131Y4
Attention:
Make sure that each bolt needed for all steps matches the
corresponding figure to ensure proper assembly.

Step 1:

Place the back assembly (#1) onto a non-abrasive surface,
such as a carpet. Insert the back assembly (#1) into the seat
assembly (#2). See Figure 1.
!
Use the correct bolts as indicated. Do not tighten any of the bolts until the chair is completely assembled.
!
Do not discard of any of the packaging until you have checked that you have all of the parts and fittings
required.
!
Keep children away during assembly. This item contains small parts that can be swallowed by children.
Children should always be under direct adult supervision while using this product.
!
Retain these assembly instructions for future reference.
!
Quote the following FQC NO. when contacting the service center.
INTENDED FOR RESIDENTIAL USE ONLY.
KFS777U-
PART
Q' TY
1
BACK ASSEMBLY
1
SEAT ASSEMBLY
1
LEFT ARM
1
RIGHT ARM
2
BOLT M6*65
4
BOLT M6*16
2
BOLT M6*14
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
DON'T RETURN TO STORE!
STOP
PAGE 1 OF 2
WM
PART
MATERIAL CODE
NO.
8
17FA05040301-Y4
9
18000337006
10
18000337004
11
17KAA0101----Y4
12
17KAA0201----Y4
13
61K777UJ00001BA
14
61K777UC00001BA
FIGURE 1
2
COURTYARD CREATIONS INC.
PART
Q' TY
6
WASHER d6.5*D13*1.0
2
BOLT CAP M6
6
BOLT CAP
1
HEX.KEY WRENCH 4MM
1
HEX.KEY WRENCH 6MM
1
PILLOW
1
SEAT CUSHION
2
1
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KFS777U- and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Courtyard Creations KFS777U-

  • Page 1 Children should always be under direct adult supervision while using this product. Retain these assembly instructions for future reference. Quote the following FQC NO. when contacting the service center. SERVICE CENTER TOLL FREE NO. TEL: 1-877-539-7436 FAX: 1-877-539-7439 DON’T RETURN TO STORE! STOP PAGE 1 OF 2 COURTYARD CREATIONS INC.
  • Page 2 FIGURE 2 FIGURE 3 #5 BOLT M6*65 #6 BOLT M6*16 Step 2: Step 3: At the rear of the seat, fasten the seat assembly (#2) to the Fasten both the left arm (#3) and the right arm (#4) to the seat back assembly (#1) by using bolts (#5) and washers (#8).
