  • Page 1 TKP-9600 Total Control Owner’s Manual TKP-9600 Owner’s Manual...

  • Page 2: Table Of Contents

    Releasing the Tamper Resistant Do Not Disturb Mode ....27 Lock..........4 Contact Support Scenes Menu ........28 Total Control is a URC product sold direct only. For questions or assistance contact For New Construction....5 Settings Menu ........29 your Custom Installer/Programmer. For Retrofit Boxes ......6 Sleep Settings .......

  • Page 3: Features And Benefits

    TKP-9600 Total Control Owner’s Manual Features and Benefits The TKP-9600 In-Wall Network Keypad is one of URC’s most advanced devices that is optimized for usage with Total Control. Enjoy these key features: Updated User Experience This device has the capability of using URC’s Total Control software suite. Using this software provides this device with a modern “look and feel”...

  • Page 4: Proximity Sensor

    This setting can be adjusted in the device’s Settings menu. Flexible Orientation The TKP-9600 offers the ability to display the device in either portrait or landscape mode making it the perfect keypad for almost any room. This feature can only be set from within the Accelerator software, speak to a custom home professional prior to installation.
  • Page 5 TKP-9600 Total Control Owner’s Manual Part List Included in the TKP-9600: • 1x - TKP-9600 Network Keypad • 1x - Mounting Ring • 4x - Mounting Screws Spacers • 4x - Spacers • 2x - Ribbon Spacers Unlock Tool Mounting Ring...

  • Page 6: Tkp-9600 Installation Guidelines

    Failing to do so could cause physical damage to the TKP-9600. Releasing the Tamper Resistant Lock The lock is located at the top of the TKP-9600 and requires the supplied tool in order to unlock. To unlock the TKP-9600 use engage the tool into the lock and gently lift up. The...

  • Page 7: For New Construction

    When installing a 3-gang or a 2-gang box it sits recessed in the wall as seen on the image to the right. The TKP-9600 cannot fit into the mounting plate properly. Due to the unique design of the TKP-9600, the mounting plate must be installed with the ribbon spacers (supplied in the box).

  • Page 8: For Retrofit Boxes

    Installing the TKP-9600 into a retrofitted 3-gang or 2-gang box is easy. The mounting plate must be installed directly onto the 3-gang/2-gang box. The frame of the retrofit box provides ample space for the TKP-9600 to mount properly on the mounting plate.

  • Page 9: Main Menu Navigation

    • Right Swipe: Swipe right to reveal the Scenes Menu. The Scenes Menu contains URC Scenes that are created by the custom integrator. Return to the Main Menu by swiping left from the Scenes Menu. • Button Tapping: On the Main Menu selecting each of these areas provide the end-user with control: A.

  • Page 10: Main Menu: View Modes

    TKP-9600 Total Control Owner’s Manual Ribbon View (Landscape & Portrait) Main Menu: View Modes Total Control features two different view modes for the TKP- 9600. Each view mode has its own unique properties that compliment the user experience. The view mode must be programmed from within the Accelerator software, speak to a custom home integrator for more details.

  • Page 11: Title Bar

    Title Bar The Title Bar is always present regardless of what menu and/or room the TKP-9600 is currently using. On the left of the Title Bar, the current room the TKP-9600 is controlling is Now Playing Current Room displayed. Selecting it reveals the Rooms Menu.

  • Page 12: Room's Menu

    This button can only be used to turn off a room. 4. Now Playing: This section displays what device/activity is currently active in that room. Selecting this jumps the TKP-9600 to that device/ activity’s menu for control. 5. Room Linking: This feature is only available on DMS Audio device.

  • Page 13: Room Linking

    TKP-9600 Total Control Owner’s Manual Room Linking Remember, Room Linking can only be used by DMS Zones/Areas. The following steps take place from within the Room’s Menu: 1. Select the Room Link button, this displays the Room Linking Menu. 2. Select which rooms in the system to link. Only rooms that are DMS Zones/Areas appear on the Room Linking Menu.

  • Page 14: Now Playing

    In the example at the right, Now Playing reads “SNP-2 Pandora”. This means that in the Home Theater the SNP-2 is using Pandora currently. Tapping the Now Playing area jumps the TKP-9600 to the menu for the device in that section. In the example this mean that, once tapped, the...

  • Page 15: Core Buttons

    TKP-9600 Total Control Owner’s Manual Core Buttons These buttons are almost always on display. Each one of these buttons has a specific function: A. Volume: Used to control an active audio device. B. Shortcut Popup: Use this to display the Shortcut Popup Menu. This menu contains up to six (6) current room activities.

  • Page 16: Shortcut Popup Menu

    TKP-9600 Total Control Owner’s Manual Shortcut Popup Menu The Shortcut Popup Menu holds the end-user’s favorite or most frequently used devices/activities and places them in one easy to access location. Adding Shortcuts Follow these steps to add a Shortcut: 1. Locate an available button and hold it down until the status bar on the top of the display fills.

  • Page 17: Removing Shortcuts

    TKP-9600 Total Control Owner’s Manual Just tap on a Shortcut button to launch that device/activity. Remember, this menu can only hold up to six (6) items and each item must already be a device/activity programmed into that current room. Removing Shortcuts Follow these steps to remove a Shortcut: 1.

  • Page 18: Status Bar

    TKP-9600 Total Control Owner’s Manual Status Bar Located above the Core Buttons, this section of the interface is almost always on display. The Status Bar is designed to inform the end-user of various customization options: A. Metadata Information: Located to the far left, options selected from the programming software cycle through here.
  • Page 19 TKP-9600 Total Control Owner’s Manual B. Page Indicator: The icons here represent the current page number the interface is on. However, the icon located to the left is the Scenes Menu icon. All icons to the right of that represent page numbers.

  • Page 20: Intercom

    Total Control Owner’s Manual Intercom The TKP-9600 has the capability of communicating across the home network to any Intercom-Enabled client (interface). There are three (3) different types of intercom calls that can be made: 1. Audio-Video: This type of call uses the camera and microphone of the calling and receiving client to provide auditory and visual feedback.
  • Page 21 TKP-9600 Total Control Owner’s Manual 3. Audio Broadcast Call: This type of call is audio communication between two or more clients. An ideal way to communicated across multiple Intercom-Enabled interfaces in almost any home.

  • Page 22: Navigating The Intercom Menu

    TKP-9600 Total Control Owner’s Manual Navigating the Intercom Menu As mentioned on page 6 of this document, accessing the Intercom button is performed by swiping down on the Title Bar. After selecting the Intercom button from the Title Bar Menu, the Intercom Menu displays.

  • Page 23: Making Calls: Audio-Video

    TKP-9600 Total Control Owner’s Manual Making Calls: Audio-Video Remember that the Intercom feature must be enabled from with in the Settings Menu. The following steps take place from the Intercom Menu, to access this menu refer to page 1. Select an available client from the Intercom Menu.
  • Page 24 Slide the indicator to the top for maximum volume or slide it down to the bottom to mute the audio. To end an Audio & Video call, select the End Call button (see image at right). This immediately ends the call and returns the TKP-9600 to the Intercom Menu. End Call...

  • Page 25: Making Calls: Audio Calls

    TKP-9600 Total Control Owner’s Manual Making Calls: Audio Calls Remember that the Intercom feature must be enabled from with in the Settings Menu. The following steps take place from the Intercom Menu, to access this menu refer to page 1. Select an available client from the Intercom Menu. After selecting a client, the three (3) call options are displayed.
  • Page 26 Slide the indicator to the top for maximum volume or slide it down to the bottom to mute the audio. To end an Audio Call, select the End Call button (see image at right). This immediately ends the call and returns the TKP-9600 to the Intercom Menu. End Call...

  • Page 27: Making Calls: Audio Broadcast

    TKP-9600 Total Control Owner’s Manual Making Calls: Audio Broadcast Remember that the Intercom feature must be enabled from with in the Settings Menu. The following steps take place from the Intercom Menu, to access this menu refer to page 1. Select Broadcast Call. A list populates of all available Intercom- Enabled devices.
  • Page 28 Slide the indicator to the top for maximum volume or slide it down to the bottom to mute the audio. To end an Audio Call, select the End Call button (see image at right). This immediately ends the call and returns the TKP-9600 to the Intercom Menu. End Call...

  • Page 29: Do Not Disturb Mode

    Total Control Owner’s Manual Do Not Disturb Mode Enabling the Do Not Disturb feature sets the current TKP-9600 unavailable. This means that the keypad cannot receive any calls from other interfaces. To enable this feature, use the slider located at the right of the text Do Not Disturb.

  • Page 30: Scenes Menu

    TKP-9600 Total Control Owner’s Manual Scenes Menu The Scenes Menu is dictated by the system programmer. Access this menu by swiping to the right from the Main Menu. The Scenes Menu can contain up to a hundred (100) Scenes (buttons) per room. Keep in mind that the Scene Menu is unique to each room.

  • Page 31: Settings Menu

    • Intercom: This is used to set up the Intercom of the TKP-9600. • Demo: Used to create a simulation system that the TKP-9600 can use to show off interface features. • Factory Reset: Allows the TKP-9600 to be reset to its factory state.

  • Page 32: Sleep Settings

    3. LCD Screen will Display a Night Mode: When selected the Start After and Duration option become active. • Start After: The TKP-9600 times out based on the value entered here and goes into Night Mode. • Turn Off After: The TKP-9600 turns off Night Mode after the value...

  • Page 33: General

    Hour • Minutes • Seconds • AM/PM • 12 Hour/24 Hour 3. Automatically Adjust Clock for Daylight Savings: Check this box to have the TKP-9600 automatically adjust for daylight savings. 4. Temperature Scale: Set this either to Fahrenheit or Celsius.

  • Page 34: Sound

    (+) button to increase the brightness. Sound Press the minus (-) button to lower the TKP-9600’s audio output or press the plus Additionally, dragging the slider to the right increase the display brightness while (+) button to increase the volume.

  • Page 35: Proximity Sensor

    Total Control Owner’s Manual Proximity Sensor Press the minus (-) button to lower the sensitivity on the TKP-9600’s Proximity Sensor or press the plus (+) button to increase the sensitivity. Additionally, dragging the slider to the right increases the sensitivity while dragging it to the left decreases it.

  • Page 36: System Information

    TKP-9600 Total Control Owner’s Manual System Information Although none of the information can be modified. These System Pages display important information about the TKP-9600. These pages are only needed by a custom install professional or by URC Technical Support.

  • Page 37: Network

    Caution, these settings should ONLY be changed by a professional. Entering values without specific instruction could easily result in the TKP-9600 failing to function correctly. Here is the information that can be displayed here: 1. Connection: Displays the status of the network connection, connected or not connected.

  • Page 38: Intercom

    The Audio-Video Intercom Settings menu is the location where the Intercom features must be enabled. By default this feature is disabled, it must be enabled in order for the TKP-9600 to communicate with other Intercom-Enabled devices. • Enable Intercom: Enables the audio intercom function. Once enabled,...

  • Page 39: Factory Default

    This should only be attempted by a custom install professional that is familiar with Total Control or under instruction from URC Technical Support. Selecting this option resets the TKP-9600 to its factory state and does not function until the device is reprogrammed by a custom install professional.

  • Page 40: Specifications

    TKP-9600 Total Control Owner’s Manual Specifications These are the technical specifications for the TKP-9600: Limited Warranty Statement Microprocessor: Cortex-A9 QuadPlus 1Ghz https://www.urc-automation.com/legal/warranty-statement/ Memory: 8GB eMMC, 2GB RAM End User Agreement Devices: Supports up to 255 devices The terms and conditions of the End User Agreement available at https://www.urc-automation.com/legal/end-user-agreement/...
  • Page 41 • CE conformity Notice Products with “CE” marking comply EMC Directive 2014/30/EU issued by the commission of the European Community. 1. EMC Directive • Emission • Immunity • Power • Declaration of Conformity “Hereby, Universal Remote Control Inc. declares that this TKP-9600 is in compliance with the Essential requirements.”...
