  • Page 1 TKP-8600 Total Control Owner’s Manual TKP-8600 Owner’s Manual...
  • Page 2 TKP-8600 Total Control Owner’s Manual Table � C�tents Coming So�!

  • Page 3: Total Control

    Amazon audio service directly through your system’s HDA audio. • 8” Capacitive LCD Screen: Displays vivid and colorful custom menus, backgrounds, images, icons and more. Speak with a certified URC Integrator for • Native Audio Video Intercom: Make calls audio or audio-video calls personalized backgrounds, room, and scene images! throughout the system with other TKP-8600s or intercom enabled keypads.
  • Page 4 TKP-8600 Total Control Owner’s Manual Parts List The following is included in the box:...
  • Page 5 TKP-8600 Total Control Owner’s Manual TKP-8600 Installation Guidelines The TKP-8600 can be iinstalled in a standard three-gang or dual gang wall box. Releasing the Tamper Resistant Lock 1. Prior to installing the TKP-8600, ALWAYS make sure the tamper lock has been released.

  • Page 6: Mounting Bracket

    TKP-8600 Total Control Owner’s Manual Wall New Construction The TKP-8600 fits into any 3-gang or 2-gang box. However, there are certain aspects of the installation that must be highlighted. 1. Measure the 3-gang or 2-gang box and using your preferred cutting tool, cut a hole in the wall that matches the measurements of the gang box.
  • Page 7 TKP-8600 Total Control Owner’s Manual For Retrofit Boxes Installing the TKP-8600 into a retrofitted 3-gang or 2-gang box is easy. The mounting plate must be installed directly onto the 3-gang/2-gang box. The frame of the retrofit box provides ample space for the TKP-8600 to mount properly on the mounting plate.
  • Page 8 Total Control Owner’s Manual Navigating the Main Menu Although the specific screen design and button option are dictated by your certified URC integrator, the general layout remains the same amongst URC interfaces. Navigating across pages is performed through screen swipes: •...
  • Page 9 8. Status Display Items: This area displays items that are programmed by the URC integrator. This can display information such as Sunrise, Sunset, Room Link Status, Alarm Clock Status, and more. 9. Current Time: Displays the current time, the Total Control system operates on an astronomical clock to accurately display time and trigger timed events.
  • Page 10 Total Control features two (2) different view modes for the TKP-8600. Each view mode has its own unique properties that compliment the user experience. The view mode must be configured by a certified URC integrator. Speak with your URC programmer about which view mode you want the TKP-8600 to be installed as.
  • Page 11 Keep in mind, your URC programmer has configured this device to operate at its best. Changes to certain settings may cause issues within your system and require troubleshooting. It is best to only access this menu if instructed to by your URC integrator or by URC’s Technical Support Team.
  • Page 12 2. Lights Off Action Command: Total Control supports a variety of lighting subsystems including, but not limited to, Z-Wave, Philips Hue, Lutron, and more. Your URC integrator can program this button to turn the lights off in the selected Room/Zone.
  • Page 13 Total Control Owner’s Manual HDA Zone Linking: This feature is only available when integrated with URC HDA audio distribution system. For more details, please speak with your certified URC integrator. To link two (2) or more Zones together, perform the following: 1.
  • Page 14 Owner’s Manual Using the Intercom The TKP-8600 has the capability of communicating across the home or business over the network to any other URC intercom-enabled device. There are three (3) types of calls that can be made: • Audio Call: Using the built-in microphone of your intercom-enabled device, the Total Control system can make audio only calls to any room/zone that contains a compatible interface.
  • Page 15 TKP-8600 Total Control Owner’s Manual • Audio Broadcast Call: This type of call is audio only and can communicate with all intercom-enabled devices found within the system. Audio Broadcast Call...
  • Page 16 TKP-8600 Total Control Owner’s Manual Navigating the Intercom Menu As mentioned on page 9, accessing the Intercom is performed by swiping down on the Title Bar and selecting the Intercom icon. This icon can also be manually placed within the Shortcuts menu. After selecting the Intercom icon, the following is displayed: 1.
  • Page 17 TKP-8600 Total Control Owner’s Manual Making an Audio Call 1. From the Intercom Menu, select an available intercom-enabled device. 2. Select Audio Call.
  • Page 18 TKP-8600 Total Control Owner’s Manual Once the call is accepted, the TKP-8600 provides two-way communication between intercom-enabled devices via audio. Below are descriptions of the available options on the Audio Call screen: a. Volume Slider: Allows the user to raise or lower the call volume. b.
  • Page 19 TKP-8600 Total Control Owner’s Manual Making an Audio-Video Call 1. From the Intercom Menu, select an available intercom-enabled device. 2. Select Audio & Video Call.
  • Page 20 TKP-8600 Total Control Owner’s Manual Once the call is accepted, the TKP-8600 provides two-way communication between intercom-enabled devices via audio and video. Below are descriptions of the available options on the Audio Call screen: a. Volume Slider: Allows the user to raise or lower the call volume. b.
  • Page 21 TKP-8600 Total Control Owner’s Manual Making an Audio Broadcast Call 1. From the Intercom Menu, select Audio Broadcast Call. 2. The Available Clients screen is displayed. This menu shows all supported devices in the system. Check the boxes of the interfaces you want to include in this Broadcast Call.
  • Page 22 TKP-8600 Total Control Owner’s Manual Once the call is accepted, the TKP-8600 provides two-way communication between intercom-enabled devices via audio. Below are descriptions of the available options on the Audio Call screen: a. Volume Slider: Allows the user to raise or lower the call volume. b.
  • Page 23 Most settings do not require interaction with the end-user. Changing some settings could cause issues with the Total Control system. Only do so when instructed by certified URC integrator and/or URC’s Technical Support Team. Below are the available options: •...
  • Page 24 TKP-8600 Total Control Owner’s Manual Sleep Settings Below are the selectable choices available in this menu: 1. LCD Screen is Always On: When selected the TKP-8600’s display never turns off. 2. LCD Screen will Turn Off: When selected the Turn Off After section is selectable.
  • Page 25 Owner’s Manual General These values are already configured by your URC integrator. Only enter this menu if instructed by your URC integrator and/or URC’s Technical Support Team. 1. Date: Using the left and right arrows; month, day, and year can be configured manually.
  • Page 26 LCD: 8” Capacitive Touch Display (800 x 1280) (2) years from the date of purchase by the end-user, but no longer than forty- eight (48) months from the date of shipment of the URC equipment by URC to an Camera: 5MP authorized URC dealer or distributor.
  • Page 27 HEREIN. In the event of any warranty claim, URC will, at its sole option, repair the CERTAIN IMPLIED WARRANTIES, INCLUDING AN IMPLIED WARRANTY OF URC equipment using new or comparable rebuilt parts, or exchange the URC MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, MAY BE equipment for new or rebuilt equipment.
