- Page 1 SMART Board® 7000 and 7000 Pro series interactive displays USER’S GUIDE SBID-7075 SBID-7086 SBID-7275 SBID-7286 SBID-7375 SBID-7386 SBID-7075P SBID-7086P SBID-7275P SBID-7286P SBID-7375P SBID-7386P ID7075-1 ID7086-1 Was this document helpful? smarttech.com/docfeedback/171163...
- Page 2 Learn more This guide and other resources for SMART Board 7000 and 7000 Pro series interactive displays are available in the Support section of the SMART website (smarttech.com/support). Scan this QR code to view these resources on your mobile device. Licenses The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
-
Page 3: Important Information
Important information NOTE Refer to the installation and maintenance guide for important information about installing and maintaining the display (see More information on page 8). WARNING Do not open or disassemble the display. You risk electrical shock from the high voltage inside the casing. -
Page 4: Federal Communication Commission Interference Statement
IMPORTANT INFORMATION Federal Communication Commission interference statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. this device must accept any interference received, including interference that may cause undesired operation. NOTE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. -
Page 5: Eu Declaration Of Conformity
IMPORTANT INFORMATION EU declaration of conformity Hereby, SMART Technologies ULC declares that the radio equipment type Interactive Display SBID-7075, SBID-7075P, SBID-7086, SBID-7086P, ID7075-1, ID7086-1 and the interactive pen SBID-7000-PEN, SBID-7000P-PEN are in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following Internet address: smarttech.com/compliance WARNING This equipment is compliant with Class A of CISPR 32. -
Page 6: Microsoft Statement Regarding Windows 10 Operating System
IMPORTANT INFORMATION Microsoft® statement regarding Windows® 10 operating system Windows 10 is automatically updated, which is always enabled. ISP fees may apply. Additional requirements may apply over time for updates. smarttech.com/kb/171163... -
Page 7: Table Of Contents
Contents Important information Federal Communication Commission interference statement Innovation, Science and Economic Development Canada statement EU declaration of conformity Compliance to Malaysia specification United Arab Emirates – TRA registration details Microsoft statement regarding Windows 10 operating system Chapter 1: Welcome About this guide Identifying your specific model Features... -
Page 9: Chapter 1: Welcome
Chapter 1 Welcome About this guide Identifying your specific model Identifying your SMART Board 7000 or 7000 Pro series interactive display model Identifying your iQ appliance model Features Components Screen Presence detection sensors Home button Pens and eraser Convenience panel iQ appliance (and Intel Compute Card) Internal speakers Accessories SBA-100 projection audio system... -
Page 10: Identifying Your Specific Model
CHAPTER 1 WELCOME Identifying your specific model SMART offers several different models of the SMART Board 7000 and 7000 Pro series interactive display and iQ appliance. Identifying your SMART Board 7000 or 7000 Pro series interactive display model The following models of SMART Board 7000 and 7000 Pro series interactive display are available: Model Frame style Screen size... -
Page 11: Features
CHAPTER 1 WELCOME Features The SMART Board 7000 or 7000 Pro series interactive display is the hub of your classroom or meeting room. PC-free embedded computing provides one-touch access to collaborative tools, including a whiteboard, wireless screen sharing and a web browser. There’s no need for wires, cables or manual software and firmware updates. -
Page 12: Components
CHAPTER 1 WELCOME Components The display consists of the following components: Name More information Pictured Screen Page 5 Presence detection sensor (×2) Page 5 Home button Page 6 Eraser Page 6 Pen (×4) Page 6 Convenience panel Page 6 iQ appliance (and Intel Compute Card) Page 6 Connector panel Page 23 Not pictured... -
Page 13: Screen
CHAPTER 1 WELCOME Screen The following are the dimensions of the screen: Model Diagonal Width Height SBID-7075 75" (190.5 cm) 65" (165.2 cm) 38 5/8" (93 cm) SBID-7086 86" (218.4 cm) 74 7/8" (190.3 cm) 42" (107 cm) SBID-7275 75" (190.5 cm) 65"... -
Page 14: Home Button
CHAPTER 1 WELCOME Home button Tap the Home button to open the Home screen. From the Home screen, you can open the iQ appliance’s apps as well as the settings. For more information about the Home screen and the iQ experience, see Using the iQ experience on page 18. -
Page 15: Accessories
CHAPTER 1 WELCOME SBID-7386 SBID-7375P SBID-7386P Take advantage of iQ technology and access collaborative tools. The SBID-7375, SBID-7386, SBID-7375P and SBID-7386P models have an Intel Compute Card in the appliance to provide a fully functional Windows 10 solution at your fingertips, without the need for an external PC or cabling. -
Page 16: More Information
CHAPTER 1 WELCOME SMART Audio 400 classroom amplification system Available for education models, the SMART Audio 400 classroom amplification system provides high-quality audio amplification. The system comes with a teacher microphone and optional student microphone. Multiple speaker options are available, including wall- and ceiling-mounted speakers. The amplifier receives audio signals from the microphones and translates them into crystal-clear sound through the speakers. - Page 17 CHAPTER 1 WELCOME Document Link SBID-7275P smarttech.com/kb/171213 SBID-7286P smarttech.com/kb/171214 SBID-7375P smarttech.com/kb/171318 SBID-7386P smarttech.com/kb/171317 AM30 smarttech.com/kb/171097 AM40 smarttech.com/kb/171182 AM50 smarttech.com/kb/171263 Comparison smarttech.com/kb/171161 Installation instructions SBID-7075, 7275, 7375, 7075P, 7275P and 7375P smarttech.com/kb/171160 SBID-7086, 7286, 7386, 7086P, 7286P and 7386P smarttech.com/kb/171232 AM30 smarttech.com/kb/171090 AM40 smarttech.com/kb/171199...
-
Page 19: Chapter 2: Using The Display
Chapter 2 Using the display Waking up the display and putting it back to sleep Using the convenience panel Using the Power button to identify the display’s status Adjusting audio Freezing the screen Using touch Using the pens and eraser Using the pens Using the eraser Writing, drawing and erasing... -
Page 20: Waking Up The Display And Putting It Back To Sleep
CHAPTER 2 USING THE DISPLAY Waking up the display and putting it back to sleep The display’s presence detection sensors can detect people up to 16' (5 m) away when the display is in Standby mode (in other words, sleeping). When the sensors detect people, the display enters Ready mode and is ready to wake. -
Page 21: Using The Power Button To Identify The Display's Status
CHAPTER 2 USING THE DISPLAY Name Procedure Power Press to enter or exit Standby mode. Press and hold for four seconds to turn off the display. Press and hold for 10 seconds to reset the display. Volume increase Press to increase the volume. Volume Press to decrease the volume. -
Page 22: Using Touch
CHAPTER 2 USING THE DISPLAY Using touch You can do everything on the display that you can do at your computer—open and close applications, meet with others, create new documents or edit existing ones, visit websites, play and manipulate videos, and so on—by touching the display’s surface. You can use an array of gestures within applications, including panning, scaling, rotating and zooming in and out. -
Page 23: Using The Pens And Eraser
CHAPTER 2 USING THE DISPLAY Pinch to zoom in / scale (enlarge) Pinch to zoom out / scale (reduce) Rotate Flick Using the pens and eraser Using the pens The display comes with black, red, blue and green pens. Each pen has an attached eraser and an indicator light. - Page 24 This pairs the pens with the display and charges them for testing purposes. If you previously paired a pen with a SMART Board 7000 series interactive display, you must pair it with another display to use it with that display. When you do this, the pen’s firmware may be updated to align with the other display’s software.
-
Page 25: Using The Eraser
CHAPTER 2 USING THE DISPLAY To fully charge the pens, keep them in the holders for at least four hours before users start using the display. Using the eraser In addition to the pens, the display includes an eraser, which you can use when you want to erase a large area on the screen. -
Page 26: Using The Iq Experience
CHAPTER 2 USING THE DISPLAY To write or draw in digital ink 1. Pick up one of the display’s pens. 2. Use the pen to write or draw in digital ink. NOTE The Pen ID feature enables you to use the pens at the same time and customize their colors and other settings independently. -
Page 27: Using The Apps Library
CHAPTER 2 USING THE DISPLAY To show the Home screen Tap the Home button at the bottom of the screen. Using the Apps Library The Apps Library contains the Browser, SMART Notebook Player and Whiteboard apps. You can also add apps from the web and SMART’s app store. NOTE SMART Notebook Player is available on education models only. -
Page 28: Using Smart Notebook Player
CHAPTER 2 USING THE DISPLAY Using SMART Notebook Player Use SMART Notebook Player to open, view, and interact with SMART Notebook software files. Notebook Player makes it easy to present SMART Notebook files and play SMART lab™ activities on the display. You can also install the Notebook Player app on your iOS device to view and control SMART Notebook files from the device. -
Page 29: Connecting And Using The Intel Compute Card
CHAPTER 2 USING THE DISPLAY Cleaning up the display After you’ve finished using the display, open the launcher and tap Clean Up to clean up the display for the next user. Connecting and using the Intel Compute Card The SBID-7375, SBID-7386, SBID-7375P and SBID-7386P models have an Intel Compute Card. Insert the Intel Compute Card in the slot on the iQ appliance and then use the Input app to view the Intel Compute Card’s Windows 10 operating system on the display. -
Page 30: Setting The Resolutions And Refresh Rates Of Computers You Want To Connect To The Display
CHAPTER 2 USING THE DISPLAY The SBID-7075P, SBID-7086P, SBID-7275P, SBID-7286P, SBID-7375P and SBID-7386P models come with one room license and ten personal licenses of SMART Meeting Pro software. You can download SMART Meeting Pro software from smarttech.com/downloads and install the room license on the Intel Compute Card or a room computer and the personal licenses on up to ten users’... -
Page 31: Connecting Computers To The Display
CHAPTER 2 USING THE DISPLAY Connecting computers to the display You can connect computers with SMART software to the display as shown below. NOTES To interact with content, connect a USB cable to the appropriate USB Type-B receptacle on the connector panel or convenience panel (as shown in the above diagrams). Your organization’s installers might have connected cables to the connector panel or the convenience panel and run the cables behind a wall or under the floor to a desk or table where you can place your computer. -
Page 32: Using Smart Software On Connected Computers
CHAPTER 2 USING THE DISPLAY 3. Tap Input The display shows thumbnails of the devices that are connected to the display’s inputs: A gray thumbnail indicates no device is connected to an input. A blue thumbnail indicates a device is connected to an input but is in sleep mode. A thumbnail showing a preview screen indicates a device is connected to an input and is currently active. -
Page 33: Chapter 3: Troubleshooting
Chapter 3 Troubleshooting Resolving issues with power Resolving issues with presence detection Resolving issues with video Resolving issues with image quality Resolving issues with audio Resolving issues with touch and digital ink Resolving issues with the iQ experience Resolving issues with the Intel Compute Card Resolving issues with software Referring to the SMART knowledge base for additional troubleshooting information Contacting your reseller for additional support... -
Page 34: Resolving Issues With Power
CHAPTER 3 TROUBLESHOOTING Resolving issues with power Issue Solutions The display doesn’t turn on and its Make sure the power cable is securely fastened to the power outlet and the power light isn’t lit. display. NOTE If the power cable is connected to a power bar, make sure the power bar is securely fastened to the power outlet and turned on. -
Page 35: Resolving Issues With Video
CHAPTER 3 TROUBLESHOOTING Resolving issues with video Issue Solutions You’re experiencing the following Make sure any connected computers are on and not in Standby mode. or similar issues with video: Make sure the iQ appliance is securely installed in the accessory slot and its power light is on. - Page 36 CHAPTER 3 TROUBLESHOOTING Issue Solutions There are bright spots on the Open the on-screen display menu. If it appears correctly, the issue is with the screen. video input. Take a photograph of the screen and send it to SMART support. If SMART support determines that the issue is with the screen and the display is under warranty, you may be eligible for a replacement.
-
Page 37: Resolving Issues With Audio
CHAPTER 3 TROUBLESHOOTING Resolving issues with audio Issue Solutions You’re experiencing the following If you’re using external speakers, make sure the speakers are turned on. or similar issues with audio: Make sure the cables connecting the display to the computer are securely fastened. -
Page 38: Resolving Issues With Touch And Digital Ink
On Mac computers, open System Information and ensure there are no error messages in the display’s row. You’re experiencing issues with Use only SMART Board 7000 series interactive display pens with the display. one or more of the display’s pens. Pens from other interactive displays aren’t compatible. -
Page 39: Resolving Issues With The Intel Compute Card
CHAPTER 3 TROUBLESHOOTING Resolving issues with the Intel Compute Card For information on resolving issues with the Intel Compute Card, including the drivers, see Troubleshooting Windows 10 on Intel Compute Card. Resolving issues with software For information on resolving issues with SMART Learning Suite (including SMART Notebook software), see Troubleshooting SMART Notebook For information on resolving issues with SMART Meeting Pro software, see... - Page 40 CHAPTER 3 TROUBLESHOOTING NOTE You need to remove the iQ appliance from the display to find the serial number. smarttech.com/kb/171163...
- Page 42 SMART TECHNOLOGIES smarttech.com/support smarttech.com/contactsupport smarttech.com/kb/171163...
