LED Indication
Flashing: The switch works properly.
SYS
On or Off: The switch works improperly.
Green On: Running at 1000 Mbps, but no activity.
Green Flashing: Running at 1000 Mbps and transmitting or receiving data.
10/100/1000M Yellow On: Running at 10/100 Mbps, but no activity.
Yellow Flashing: Running at 10/100 Mbps and transmitting or receiving data.
Off: No device is linked to the corresponding port.
Green On: Running at 1000 Mbps, but no activity.
Green Flashing: Running at 1000 Mbps and transmitting or receiving data.
Yellow On: Running at 100 Mbps, but no activity.
Port 49–52/
SFP
Yellow Flashing: Running at 100 Mbps and transmitting or receiving data.
Off: No device is linked to the corresponding port.
Note: Port 49–52 for TL-SG3452, SFP for TL-SG3210.
For TL-SG3428 V2.0
LED Indication
On: The switch is powered on.
PWR Off: The switch is powered off or power supply is abnormal.
Flashing: Power supply is abnormal.
Flashing: The switch works properly.
SYS
On or Off: The switch works improperly.
On: A device is linked to the port but no activity.
Link/Act Off: No device is linked to the corresponding port.
Flashing: Transmitting or receiving data.
On: Running at 1000 Mbps.
1000Mbps
Off: Running at 10/100 Mbps or no device is linked to the port.
On: Running at 1 Gbps, but no activity.
Port 25–28 Flashing: Running at 1 Gbps and transmitting or receiving data.
Off: No device is linked to the corresponding port.
For TL-SG3428X
LED Indication
On: The switch is powered on.
PWR Off: The switch is powered off or power supply is abnormal.
Flashing: Power supply is abnormal.
Flashing: The switch works properly.
SYS
On or Off: The switch works improperly.
