TP-Link TL-SX3206HPP Installation Manual page 6

JetStream L2/L2+ Managed Switch
The front panel of TL-SG3428X is shown as the following figure.
Figure 1-7 Front Panel of TL-SG3428X
LED
The front panel of TL-SG3428XMP is shown as the following figure.
Figure 1-8 Front Panel of TL-SG3428XMP
The front panel of TL-SG3452 is shown as the following figure.
Figure 1-9 Front Panel of TL-SG3452
Console Port
(USB/RJ45)
The front panel of TL-SG3452P is shown as the following figure.
Figure 1-10 Front Panel of TL-SG3452P
PWR PoE Max
TL-SG3452P
SYS FAN
Speed PoE
Managed PoE+ Switch
Console(RJ45) Console(USB)
Console Port
(RJ45/USB)
03 Introduction
Console Port
(USB/RJ45)
LED Console Port
(RJ45/USB)
LED
1000Mbps 10/100Mbps activity
Speed
LED
1G
RJ45 Port
1G
RJ45 Port
1G RJ45 Port
Delivering Power Over Budget Fault
PoE
1G RJ45 Port
24-Port Gigabit L2+ Managed Switch
with 4 10GE SFP+ Slots
SFP+ Slot
SFP+ Slot
F
SFP Slot
F
SFP Slot
