TP-Link TL-SX3206HPP Installation Manual page 11

LED Indication
Green On: Running at 1000 Mbps, but no activity.
Green Flashing: Running at 1000 Mbps and transmitting or receiving data.
1000Base-X/ Yellow On: Running at 100 Mbps, but no activity.
100Base-FX Yellow Flashing: Running at 100 Mbps and transmitting or receiving data.
Off: No device is linked to the corresponding port.
Note: For TL-SG3452P
Green On: Running at 10 Gbps, but no activity.
Green Flashing: Running at 10 Gbps and transmitting or receiving data.
Yellow On: Running at 1 Gbps, but no activity.
SFP+
Yellow Flashing: Running at 1 Gbps and transmitting or receiving data.
Off: No device is linked to the corresponding port.
Note: For TL-SG3428XMP
Console Port
Designed to connect with a computer for monitoring and configuring the switch. When the switch has an
RJ45 console port and a micro-USB console port, console input is active on only one console port at a
time. By default, the micro-USB connector takes precedence over the RJ45 connector.
100 Mbps/1 Gbps/2.5 Gbps/5 Gbps/10 Gbps RJ45 Port
Designed to connect to the device with a bandwidth of 100 Mbps,1 Gbps, 2.5 Gbps, 5 Gbps or 10 Gbps.
For PoE switches, the port can also provide power for PDs.
100 Mbps/1000 Mbps/2.5 Gbps RJ45 Port
Designed to connect to the device with a bandwidth of 100 Mbps,1000 Mbps, 2.5 Gbps. For PoE
switches, the port can also provide power for PDs.
10/100/1000 Mbps RJ45 Port
Designed to connect to the device with a bandwidth of 10 Mbps, 100 Mbps or 1000 Mbps. For PoE
switches, the port can also provide power for PDs.
SFP/SFP+ Slot
SFP slot is designed to install the 1 Gbps SFP module. SFP+ slot is designed to install the 10 Gbps SFP+
module.
Port Feature
Model
TL-SX3206HPP
TL-SX3008F
TL-SG3210
TL-SG3210XHP-M2
TL-SG3428 V2.0
100M/1G/2.5G/
100M/1000M/2.5Gbps
5G/10Gbps RJ45
RJ45 Port
Port
4
/
/
/
/
JetStream L2/L2+ Managed Switch
10/100/1000 Mbps
RJ45 Port
/ /
/ /
/ 8
8 /
/ 24
Console
SFP+ Slot SFP Slot
Port
2 /
8 /
/ 2
2 /
/ 4
Introduction
2
2
2
2
2
08
