DC-E
Series
Installation Manual
DC-E4212WR
Powered by

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DC-E Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Idis DC-E Series

Summary of Contents for Idis DC-E Series

  • Page 1 DC-E Series Installation Manual DC-E4212WR Powered by...
  • Page 2 Before reading this manual This is a basic installation manual for use of an IDIS network camera. Users who are using this product for the first time, as well as users with experience using comparable products, must read this operation manual carefully before use and heed to the warnings and precautions contained herein while using the product.
  • Page 3 Safety Precautions WARNING RISK OF ELECTRIC SHOCK DO NOT OPEN WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Important Safeguards 1. Read Instructions 10. Overloading All the safety and operating instructions should be read before the Do not overload wall outlets and extension cords as this can result in appliance is operated.
  • Page 4 IDIS Co., Ltd. reserves all rights concerning this operation manual. Use or duplication of this operation manual in part or whole without the prior consent of IDIS Co., Ltd. is strictly prohibited. Contents of this operation manual are subject to change without prior notice for reasons such as functionality enhancements.

  • Page 5: Table Of Contents

    Table of Contents Part 1 – Introduction ......... 6 Product Features .

  • Page 6: Part 1 - Introduction

    Web) lets you remotely view live video using a web browser. In addition, you can use the IDIS Solution Suite • Slow shutter support for improved low-lighting video Compact to manage network cameras and view/record capture performance video.

  • Page 7: Accessories

    Part 1 – Introduction Accessories Upon purchasing the product, check inside the box to make sure all the following accessories are included. External appearances and colors of the accessories may vary depending on the model. RJ45 moduler jack, RJ45 waterproof rubber ring, RJ45 Network Camera connector protect cover, cable waterproof rubber ring, RJ45 connector back cover...

  • Page 8: Overview

    You can configure, manage, and upgrade this camera and monitor its images from a remote computer over the network. For more information on network connection setup, Lens refer to the IDIS Discovery operation manual. IR LED Body Bracket Installation Cable •...

  • Page 9: Waterproof Cable Installation

    Part 1 – Introduction Waterproof Cable Installation RJ45 waterproof rubber ring RJ45 modular jack RJ45 waterproof rubber ring RJ45 modular jack RJ45 waterproof rubber ring RJ45 connector protect cover RJ45 modular jack cable waterproof rubber ring (The waterproof rubber ring is fastened to the connector protect cover.) Connect the plug terminal to the RJ45 jack.

  • Page 10: Installation

    Part 1 – Introduction Installation Dimensions • Check the wall or ceiling to see if it needs to be 186.8mm reinforced. The camera may fall off if the wall or ceiling is not strong enough to support its weight. • Install the camera in a shaded area. If the camera is installed in direct sunlight, it may be affected adversely.

  • Page 11: Part 2 - Camera Connection

    Part 2 - Camera Connection Use the camera by connecting to DirectIP™ NVR or non DirectIP™ NVR, VMS such as IDIS Solution Suite Compact. With DirectIP™ NVR-based Layout Power Network Camera Monitor Out Power Network Remote Monitoring DirectIP™ NVR makes it easy to use cameras without extra network configurations.

  • Page 12: With Non Directip™ Nvr-Based Layout

    Ideal for using the camera over the network from a remote location. The contents in the camera operation manual are only for users using the camera with non DirectIP™ NVR connection or VMS connection such as IDIS Solution Suite Compact.

  • Page 13: Part 3 - Appendix

    ID and password as a safety precaution. camera. Unable to launch IDIS Web. If the IDIS Web login screen is not loading, check which version of Microsoft Internet Explorer you are using. IDIS Web may not launch properly on versions 8.0 or below.

  • Page 14: Specifications

    Part 3 - Appendix Specifications These product specifications may change without prior notice. Video Image Sensor 1/2.9" CMOS Max. Resolution 1920 x 1080 Scanning Mode Progressive Scan Lens type Fixed-focal Focal Length f=4.0mm / f=2.8mm Aperture F2.15 / F2.0 Angular Field of View 83°...
  • Page 15 Part 3 - Appendix General Vandal Resistance Out-door Ready IP66 Operating Temperature -20°C ~ +55°C (-4°F ~ +131°F) Boot Up Temperature 0°C ~ +55°C (32°F ~ +131°F) Operating Humidity 0% ~ 90% Power Source PoE(IEEE 802.3af class 2) Power Consumption Max.
  • Page 16 IDIS Co., Ltd. For more information, please visit at www.idisglobal.com...
