Options - Icom IC-F3023T/S Instruction Manual

7

OPTIONS

D BATTERY PACK
Battery pack Voltage
BP-231
BP-232
Battery case for AAA
BP-240
(LR03) × 6 alkaline
1
* Operating periods are calculated under the following conditions;
TX : RX : standby = 5 : 5 : 90
2
* Operating period depends on the alkaline cells used.
D CHARGERS
•BC-119N
DESKTOP CHARGER
+ BC-145
AC ADAPTER
For rapid charging of battery packs. An AC adapter is sup-
plied with the charger depending on versions. Charging
time: approx. 2 hours when BP-231 is attached.
•BC-121N -
MULTI CHARGER
+ BC-157
AC ADAPTER
For rapid charging of up to 6 battery packs (six AD-106's are
required) simultaneously. An AC adapter should be pur-
chased separately. Charging time: approx. 2 hours when
BP-231 is attached.
•BC-160
DESKTOP CHARGER
For rapid charging of battery packs. An AC adapter is sup-
plied with the charger depending on versions. Charging
time: approx. 2 hours when BP-231 is attached.
24
Capacity Battery life*
7.4 V 1150 mAh 9 hrs.
7.4 V 2000 mAh 15.5 hrs.
+ AD-106
CHARGER ADAPTER
+ AD-106
CHARGER ADAPTER
+ BC-145
AC ADAPTER
D BELT CLIPS
• MB-93
SWIVEL BELT CLIP
1
• MB-94
BELT CLIP
Exclusive alligator-type belt clip. The same as supplied with
the transceiver.
• MB-96N/96F
D OPTIONAL UNITS
• UT-96R
2/5
TONE UNIT
• UT-108R
DTMF DECODER UNIT
Provides 6.25 kHz narrow bandwidth digital mode operation.
• UT-109R /UT-110R
Non-rolling type (UT-109R)/Rolling type (UT-110R) voice
scrambler unit provides higher communication security.
D DC CABLES
• CP-17L
CIGARETTE LIGHTER CABLE
Allows charging of the battery pack through a 12 V cigarette
lighter socket. (For BC-119N)
(6 pcs.)
• OPC-515L/OPC-656
Allows charging of the battery pack using a 13.8 V power
source instead of the AC adapter.
OPC-515L: For BC-119N
OPC-656 : For BC-121N
LEATHER BELT HANGER
SCRAMBLER UNITS
DC POWER CABLES
