Ltech LT-858-CC Quick Start Manual

LT-858-CC
DMX/RDM 4CH CC DECODER
LT-858-CC w ith the standard RDM remote device management protocol, supports DMX512 signal
bi-directional communication, achieves remote management of reading and writing DMX address
(DMX master controller must recognize the RDM protocol). Realize
lighting effect; workable with single color, bi-color, RGB or RGBW LED lamps.

1. Product Parameter:

LT-858-CC
Input Signal: DMX512, RDM
Input Voltage:
12~48Vdc
Output Voltage:
3-46Vdc
Max Current Load: CC 350( /700/1050mA×4CH
Default)
(if need the other two current, please specify when make orders)
Max Output Power:
(0~1.05W~48.3W)×4CH Max. 193.2W

2. Product Size:

175mm
163mm
LT-858 CC DMX/RDM 4CH CC Decoder -
warranty
5 years
0-100% dimming or different
RJ45
DMX512 Socket:
Dimming Range: 0~100%
Working Temp.: -30℃~65℃
Dimensions: L175×W42×H33(mm)
Package Size: L183×W48×H41(mm)
Weight (G.W.):
310g
1
Dip Switch Operation:
3.
0
OFF
RDM Mode: The dip switch 1-10 are OFF.
1 2 3 4 5 6 7 8 9 10
1
DIP 4 ON ON
0 OFF
DMX Mode:
1 2 3 4 5 6 7 8 9 10
1 ON
DIP 4 ON
0 OFF
Self-testing Mode:
1 2 3 4 5 6 7 8 9 10
1 ON
DIP 4 ON

3.1 How to set DMX address via dip switch:

FUN=OFF ( the 10th dip switch =OFF ) DMX
DMX address value = the total value of (1-9), to get the place value when in "on" position,
otherwise will be 0.
E.g.1: Set Initial Address To 32. E.g.2: Set Initial Address To 37.
OFF
1 2 3 4 5 6 7 8 9 10
1 2 3
DIP ON ON DIP
001+004+032=37

3.2 Self-testing Mode:

FUN=ON (the 10th dip switch=ON )
Dip Switch 1=ON 2=ON 3=ON
1-9=OFF
Self-testing Static Static Static Static
Function Black Red Green Blue
1 2 3 4 5 6 7 8 9 10
Static Static Static 7 Colors
Green Yellow Cyan Jumping
Static Static Static 7 Colors
Static
Red Blue Purple Smooth
White
[Attn] When several dip switches are ON, subjected to the highest switch value.
As the figure above shows, the effect will be 7 colors smooth at 7 speed level.

3.3 DMX Dimming Instruction:

Each LT-858 CC DMX decoder occupied 4 DMX -
addresses when connecting the DMX console.
e.g., the defaulted initial address is 1, please find
their corresponding relationships in the form.
LT-858 CC DMX/RDM 4CH CC Decoder -
FUN=OFF (the 10th dip switch=OFF)
Setting DMX addresses with dip switch 1-9
FUN=ON (the 10th dip switch=ON)
Mode
E.g.3: Set Initial Address To 178.
OFF
1 2 3 4 5 6 7 8
4 5 6 7 8 9 10
ON ON DIP ON
002+016+032+128=178
Self-testing Mode
4=ON 5=ON 6=ON 7=ON 8=ON
Static Static Static Static 7 Colors
Yellow Purple Cyan White Jumping
OFF
ON
For changing effects (Dip Switch 8 9=ON): /
DIP switch 1-7 is used to realize 7 speed levels.
(7=ON, the fastest level)
DMX Decoder output channel
DMX Console
CH1
CH1 0-255 PWM 0-100% (LED R)
CH2 0-255 CH2 PWM 0-100% (
CH3 0-255 CH3 PWM 0-100% (
CH4 0-255 CH4 PWM 0-100% (
2
www.ltech-led.com
OFF
9 10
ON
9=ON
7 Colors
Smooth
LED G)
LED B)
LED W/Y)
