- Page 1 T-1929 e 30.3.22 Translation of the original instructions for use Instructions for use Drive for Automatic TORMAX Sliding Door TORMAX 2203 Sliding Door Drive TORMAX 2203.HB Sliding Door Drive Safety instructions in chapter 2 must be observed!
-
Page 2: Table Of Contents
Operation in the event of a power failure Operating modes Operation Commissioning Operation with the TORMAX user interface Setting customer parameters with the TORMAX user interface Operation with an operating mode switch Operation on power failure Procedure in the event of a fault Maintenance... -
Page 3: General Information
1.3 Area of Application Product name, door system: Automatic sliding door Product name, door drive: TORMAX 2203 Sliding Door Drive TORMAX 2203.HB Sliding Door Drive The drive name is indicated in an abbreviated form in the Instructions. The door drives are defined in more detail by a 4-figure number:... -
Page 4: Explanation Of The Symbols
1.4 Explanation of the Symbols Warning (signal word) Source of hazard (designates a possibly hazardous situation) Possible consequences of non-observance • Measures for averting danger. Text which is highlighted in grey MUST be observed to ensure that the system operates perfectly. Failure to observe these chapters can cause damage to equipment. -
Page 5: Safety
It is important to comply with these Instructions to ensure the safety of persons. These Instructions must be kept in a safe place. 2.1 Responsibilities Installation of the system: A qualified person from a TORMAX sales partner For instructing the operator: A qualified person from a TORMAX sales partner For operating the system:... -
Page 6: Pre-Conditions For The Operation Of The System
Other improper uses (examples) • Automatic doors with leaves moving vertically. • Automatic doors with leaves moving in an inclined plane. • Door systems incorporating a wicket door must not be automated. • The drive must not be used as a drive for a wicket door. •... -
Page 7: Checks
2.6 Checks Regular checks and inspections are to be carried out in accordance with chapter 7. 2.7 Decommissioning the System in the Event of a Fault If there is a fault the automatic door may only be taken out of service by a qualified person, the opera- tor or a person who is instructed to do so by the operator. -
Page 8: System Overview
System Overview Drive side Opposite drive side T1929_2e Drive Cladding Motor unit MCU42 control system with monitoring system, power limitation and permanent diagnosis Guide system with noise-absorbent guide rail Drive accessories a) £ Mains switch * b) £ Lock with: c) £... - Page 9 Block diagram All work on the mains power supply cable and the system's cabling must only be undertaken by an authorised and properly trained person who must refer to all necessary documents. 230 V / 115 V Combined sensor Mains filter IEC plug drive side Combined sensor...
-
Page 10: System Functions
System Functions It is the responsibility of the system operator to ensure that the automatic sliding door can be freely used at all times and particularly that access to the sliding door is not blocked. T1321_12 4.1 Automatic Door Operation with Sensors When operating automatically (AUTOMATIC operating mode) the door is automatically opened from both sides by sensors when a person approaches. -
Page 11: Operation In The Event Of A Power Failure
4.7 Operation in the Event of a Power Failure Depending on the equipment installed, the following functions are possible: With 6 V battery module u – In operating mode AUTO: The door opens immediately and remains open. – In operating mode OFF: The door remains closed if it was locked mechanically at the moment of power failure. -
Page 12: Operating Modes
4.8 Operating Modes By using the TORMAX user interface u it is possible to operate the automatic door system in 6 operat- ing modes and with status displays or to use a simple operating mode switch u to operate the door in 3 operating modes. -
Page 13: Operation
The control system is checking the door leaf’s travel distance and defining the end position. The door is now ready for operation. 5.2 Operation with the TORMAX User Interface TORMAX User Interface Lock u for User Interface Operating mode:... -
Page 14: Setting Customer Parameters With The Tormax User Interface
The software is restarted. The control system then conducts a calibration run, checks the travel distance and looks for the end position again. Displayed as H61 and H62. 5.3 Setting Customer Parameters with the TORMAX User Interface The company undertaking the installation reserves the right to restrict access to all or some of the customer parameter settings. - Page 15 Code Parameter Parameters for displays 0 1 3 Drive type (TORMAX 2203) 0 4 2 Firmware version 0 4 3 Number of cycles 0 4 4 Number of operating hours Parameters for settings 1 0 … Hold open time for activator in AUTOMATIC 1 1 1 …...
-
Page 16: Operation With An Operating Mode Switch
• Push the door closed by hand until the latch engages. • Switch the operating mode switch to operating mode OFF . If a TORMAX user interface is used, operating mode OFF is automatically set when power is reconnected as the lock is engaged. -
Page 17: Procedure In The Event Of A Fault
If this does not reset the fault or if it re-occurs after a short time, you must arrange for the fault to be rectified by a qualified person from your TORMAX dealer. In this case note the fault number and inform the dealer. -
Page 18: Maintenance
Only genuine TORMAX spare part should be used. The manufacturer accepts no liability if you fail to observe this requirement. Original spare parts and original accessories guarantee the safety of use in accordance with norm EN 16005. -
Page 19: Appendix
Appendix 8.1 Hint and Fault Table System behaviour Cause Remedy/ rectification The door reverses when Electronic obstacle recognition on Remove the obstruction. opening. opening by a person, wind pressure, Clean the floor guide. ventilation or dirt in the floor guide. Door reverses when Electronic obstacle recognition on Remove the obstruction. - Page 20 System behaviour Cause Remedy/ rectification The door does not open Lock is jammed or defective.. Switch on with the key switch and in OFF when the key then push the door leaves briefly switch is used. The lock against the closed position. Have makes switching noises.
-
Page 21: Check-List For Functional Checks
8.2 Check-list for Functional Checks Item to be checked Procedure Result Activating sensors • Walk through the door direct- The door opens at the right time ly from the front and from dif- and with sufficient speed so that ferent directions at normal passage through the door Is not speed, starting both from the hindered. - Page 22 Item to be Checked Procedure Result System vicinity • Check access to the door Access to the door is free from and the movement area of objects and items likely to cause the door leaves. the user to trip. There are no objects such as shelves, plant containers and umbrella stands within a radius of 50 cm of the...
-
Page 23: Declaration Of Conformity
- 2014/30/EU (electro-magnetic-compatibility) and the following harmonised standards have been adhered to: - EN 16005 Base document: - Declaration of incorporation by TORMAX | LANDERT Group AG - Risk evaluation for automatic sliding doors | T-1178 Person responsible for documents Name/address:... - Page 24 TORMAX Folding Door Drives TORMAX Revolving Door Drives Manufacturer Installation company installation repairs , maintenance) TORMAX Unterweg 14 CH-8180 Bülach-Zürich Phone +41 58 500 5000 +41 58 500 5099 www.tormax.com info@tormax.com TORMAX is a division and a registered trademark of LANDERT Group AG...
