Summary of Contents for Tormax iMotion 1301.FIRE
- Page 1 T-1540 e 13.12.21 Translation of the original instructions for use Instructions for Use For Automatic Swing Doors in hold-open systems for fire doors with drive: iMotion 1301.FIRE Swing Door Drive ® iMotion 1401.FIRE Swing Door Drive ® Please follow the safety instructions in chapter 2!
-
Page 2: Table Of Contents
Functional Check of the Swing Door System Maintenance and Testing Appendix Fault Table Check-List for Functional Checks Declaration of Conformity First edition: 2.17, update: 4.21, 12.21 We reserve the right to make technical changes. Instructions for Use iMotion 1301.FIRE /1401.FIRE T-1540 e... -
Page 3: General Information
Manufactured Max Muster AG DD.MM.YYYY Hauptstrasse 43 – 8049 Zürich Initial SERVICE: 043 827 33 55 Commissioning DIBT (German Building Technology Institute) technical approval: approval number Z-6.510-2569: see document T-1570, download www.tormax.com Instructions for Use iMotion 1301.FIRE /1401.FIRE T-1540 e... -
Page 4: Explanation Of The Symbols
IP 20 iMotion 1401.FIRE IP 68 Ambient temperature –20 °C to +50 °C Noise emission level < 70 db (A) Electromagnetic IEC 61000-6-2, IEC 61000-6-3 compatibility (EMV) Service life Tested to 1’000’000 cycles Instructions for Use iMotion 1301.FIRE /1401.FIRE T-1540 e... -
Page 5: Safety
• Children must be supervised to ensure that they do not play close to the system and do not operate any available operating controls. Instructions for Use iMotion 1301.FIRE /1401.FIRE T-1540 e... -
Page 6: Improper Use
(section 7). • Arrange to have any faults rectified immediately by a skilled person. • Fire or smoke detectors must not be removed or rendered ineffective, e.g. by covering them. Instructions for Use iMotion 1301.FIRE /1401.FIRE T-1540 e... -
Page 7: Hazards And Risks
Danger for body and life, danger of injury • Have system repaired by a qualified person 2.6 Checks The regular checks and examinations set out in Chapter 7 must be carried out as instructed by the manufacturer. Instructions for Use iMotion 1301.FIRE /1401.FIRE T-1540 e... -
Page 8: Decommissioning The System In The Event Of A Fault
(iMotion 1301.FIRE: W = 0) iMotion 1301.FIRE iMotion 1401.FIRE Warning Broken glass Risk of injury when dismantling the door leaves. • Take care when transporting the door leaves. Instructions for Use iMotion 1301.FIRE /1401.FIRE T-1540 e... -
Page 9: System Overview
£ Depending on the system’s equipment * Provided by the installation company. The company installing the system must select and install suitable components in accordance with the prod- EN16005 / DIN18650 uct standard Instructions for Use iMotion 1301.FIRE /1401.FIRE T-1540 e... - Page 10 Opening activator opposite drive side Manual release Operating mode switch Safety sensor 3 operating modes button drive side Safety sensor Manual reset User interface opposite drive side button 6 operating modes T1540_16e Instructions for Use iMotion 1301.FIRE /1401.FIRE T-1540 e...
-
Page 11: System Function
When a person moves into the danger area, the door leaf stops or slows down to a very low speed depending upon the settings performed by the fitter at the time of commis- sioning. Instructions for Use iMotion 1301.FIRE /1401.FIRE T-1540 e... -
Page 12: Semi-Automatic Operation With "Push-And-Go
The door then closes again in a controlled manner using the integral spring. 4.8 Operating Modes The automatic door system can be operated with the TORMAX user interface u (6 operating modes and status display) or with an operating mode switch u (3 operating modes). - Page 13 The system is reset after leaving this operating mode. In this operating mode the electric door opener can also be permanently unlocked depending on the setting programmed at the time of commissioning. Instructions for Use iMotion 1301.FIRE /1401.FIRE T-1540 e...
-
Page 14: Operation
Access will be automatically blocked again for 60 s after the button has been pressed for the last time. Selection of Operating Modes • Press selector keys 1 or 2 briefly. The corresponding operating mode symbol is illuminated. Instructions for Use iMotion 1301.FIRE /1401.FIRE T-1540 e... -
Page 15: Operation With An Operating Mode Switch
To reset the system to automatic operation press the reset button for 1 second. The red LED on the reset button goes out and the door drive returns to its normal operating mode after the search run. Instructions for Use iMotion 1301.FIRE /1401.FIRE T-1540 e... -
Page 16: Procedure In The Event Of A Fault
If this does not reset the fault or if it re-occurs after a short time, you must arrange for the fault to be rectified by a skilled person from your TORMAX dealer. In this case note the fault number and inform the dealer. -
Page 17: Maintenance
Only genuine TORMAX spare part should be used. The manufacturer accepts no liability if you fail to observe this requirement. Original spare parts and original accessories guarantee the safety of use in accordance with norm EN 16005. -
Page 18: Functional Check Of The Swing Door System
See section 8.2 “Check-list for Functional Checks” for items to be checked. You should arrange for any defects detected during the routine checks to be rectified immediately by a TORMAX dealer (see the last page of this manual for the address). Warning Potential switching malfunction in the automatic swing door. -
Page 19: Appendix
The door stands still. Control system shut down for safety Perform a software-reset. E8.. reasons. The door collides with – Safety device or setting inadequate. Shut down the system. people. (see section 2.7). Instructions for Use iMotion 1301.FIRE /1401.FIRE T-1540 e... -
Page 20: Check-List For Functional Checks
The side parts and the door seals are in place and undamaged. T1540_10 Drive/Control box • Check screws and cover Screws and cover plate are firmly plate. mounted. T1540_14 Instructions for Use iMotion 1301.FIRE /1401.FIRE T-1540 e... - Page 21 50 cm of the movement area. Mains Power Cable • Check if the mains power • If damaged, get the mains pow- cable is damaged. er cable replaced by a skilled person. Instructions for Use iMotion 1301.FIRE /1401.FIRE T-1540 e...
-
Page 22: Declaration Of Conformity
- 2014/30/EU (electro-magnetic-compatibility) and the following harmonised standards have been adhered to: - EN 16005 Base document: - Declaration of incorporation by TORMAX | LANDERT Group AG - Risk evaluation for automatic swing doors | T-1186 Person responsible for documents Name/address:... - Page 24 TORMAX Revolving Door Drives installation repairs Producer Installation company ( , maintenance) TORMAX Unterweg 14 CH-8180 Bülach-Zürich Phone +41 58 500 5000 +41 58 500 5099 www.tormax.com info@tormax.com TORMAX is a division and a registered trademark of LANDERT Group AG...
