marley
DUAL-DRIVE CLASS-A HEADPHONE AMPLIFIER / PREAMP
REVISION 1.0 – NOVEMBER 2013

8. Technical Specifications

Inputs: ............................................... 2 line level on gold-flashed RCA sockets
Outputs: ............................................ 2 6,35mm (1/4") stereo jacks
Supply input: ..................................... 5.5/2.1mm jack with positive on tip
Output voltage: ................................. 8Vrms max (single-ended)
Output power: ................................... 4Wrms p.c. @ 8 Ohm (single-ended)
Input impedance: .............................. 40kOhm
Gain: ................................................. 12dB (single-ended)
SNR: ................................................. 120dB (8Vrms, 1kHz, "A" weighted)
THD+N:............................................. 0,003% (2Vrms, 1kHz)
Volume range ................................... 0dB to -78dB with 1dB steps
Muting ............................................... -20dB
Balance range................................... +/-6dB with 1dB steps
Auto switch-off .................................. 30 to 240 minutes with 30 minutes steps,
Power supply: ................................... 15V
Power consumption: ......................... 30VA
Size:.................................................. 200x50x200mm (w x h x d)
Weight............................................... 2kg (unit only)
For technical support please contact your retail dealer or e-mail to:
support@m2tech.biz
1 4-pin female XLR socket
Preamp out on gold-flashed RCA sockets
Tape out on gold-flashed RCA sockets
4-pin male XLR socket for +15V/-15V/+5V
16Vrms max (balanced)
18dB (balanced)
or disabled
2A
DC
3kg (with packaging)
31
