DUAL-DRIVE CLASS-A HEADPHONE AMPLIFIER / PREAMP
REVISION 1.0 – NOVEMBER 2013 www.m2tech.biz
7) Output for single-ended headphone connections. Connect the jack of a
headphone set to each of these two outputs. It is possible to use one output or both
outputs at the same time. These two connectors should be used as alternative to the
balanced headphones connector (item 8). 6,35mm (1/4") stereo socket.
8) Output for balanced headphones connection. Connect the XLR connector of a
headphone set to this output. This connector should be used as alternative to the
single-ended headphones connectors (item 7). 4-pin female XLR socket.
9) Input for high-current, low-noise power supply. Connect the plug from the
dedicated high-current, low-noise power supply dedicated for the MARLEY. 4-pin, male
XLR socket (optional purchase).
10) Input for power from wall wart. Connect the jack from the supplied 15V-2A wall
wart included in the package. 5.5/2.1mm jack with positive on tip.
