1 1
Mount screw covers, paying attention to the marked numbers and locations
Pull screen cable over the unit into the opening
and install the unit cover
For SPH-EVO64DAB you need to use the center opening installed
to the top. For SPH-EVO62DAB you can use to preference
Completely inserted screen neck
12
12
14
14
Installation manual CA-HM-UNI-EVO.009 | Version 1.0
Slide the screen neck into the unit cover,
pay attention to the positioning of the tabs
Slide the screen support into the unit support
11
11
2 2
13
13
15
15
