- Page 1 - Built Under Double Ovens Manual for Installation, Use and Maintenance Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu...
-
Page 2: Appliance Information
The CDA Group Ltd cannot be held responsible for injuries or losses caused by incorrect use or installation of this product. Please note that CDA reserve the right to invalidate the guarantee supplied with this product following incorrect installation or misuse of the appliance. -
Page 3: Before Using For The First Time
The manufacturer cannot be held responsible for any damages caused by improper, incorrect or unreasonable use of the appliance. Using the Double Oven for the First Time You are advised to carry out the following operations: – Assemble the interior of the top and the lower ovens as described under the heading “Cleaning and maintenance”... - Page 4 – Always stand back from the double oven when opening the oven doors to allow steam and hot air to escape before removing the food. – Do not hang towels, dishcloths or other items on the double oven or its handles – as this could be a fire hazard.
-
Page 5: Control Panel
Control Panel Fig. 1 Controls Description 1. Oven temperature knob (Top oven) 2. Function selector knob (Top oven) 3. Function selector knob (Lower main oven) 4. Oven temperature knob (Lower main oven) 5. Digital electronic programmer (Lower main oven only) Warning Lights: 6. -
Page 6: How To Use The Top Oven
Top Natural Convection Oven General Features This oven features 2 different thermostatic control functions to satisfy all cooking requirements, provided by 3 heating elements: – Upper element, 700 W – Lower element, 1000 W – Grill element, 2000 W Note: When using for the first time, you are advised to operate the oven at maximum temperature (thermostat knob on the maximum position) for approximately one hour in the... -
Page 7: Oven Light
Thermostat Knob (Fig. 2) This only sets the cooking temperature and does not switch the oven on. Rotate clockwise until the required temperature is reached (from 50 °C to 250 °C). The thermostat indicator light will illuminate when the oven is switched on and turns off when the oven reaches the correct temperature. -
Page 8: Oven Cooking
Oven Cooking Before introducing the food, preheat the oven to the desired temperature. For a correct preheating operation, it is advisable to remove the tray from the oven and introduce it together with the food, when the oven has reached the desired temperature. Check the cooking time and turn off the oven 5 minutes before the theoretical time to recuperate the stored heat. - Page 9 Lower Main Fan Oven General Features The heating and cooking in electrical hot air ovens take place by forced convection. The element which make this process take place is: – Circular element 1900 W Note: Upon first use, it is advisable to operate the oven at the maximum temperature (thermostat knob on the maximum position) for 60 minutes in the position to eliminate possible traces of grease on the heating element.
-
Page 10: Hot Air Cooking
How to Use the Lower Oven WARNING: The door is hot, use the handle. ATTENTION - MOST IMPORTANT Pay special attention not to touch the hot heating element inside the oven cavity. Thermostat Knob (Fig. 5) This only sets the cooking temperature and does not switch the oven on. - Page 11 Lower Oven Cooking Advice Cooking with Forced Air Fan cooking is more economical and quicker than cooking in a conventional oven. The moving hot air surrounds the food and penetrates it more quickly than in a conventional oven. The oven can be filled with different dishes all requiring the same cooking temperature. Subtract 10 minutes per hour for every dish requiring a cooking time of more than 1 hour and reduce the heat by 10- 20°C;...
-
Page 12: Electronic Programmer
Electronic Programmer The electronic programmer is a device that groups together the following functions: – 24 hour clock with illuminated display – Timer (up to 23 hours and 59 minutes) – Programme for automatic oven cooking – Programme for semi-automatic oven cooking. Description of the Buttons: Symbols Description... -
Page 13: Manual Operation
Setting Time of Day (fig. 7) The programmer is provided with an electronic clock with luminous figures showing the hour and minutes. The first time the oven is connected up to the electricity supply and after a power cut, three zeroes will flash on the programmer display. -
Page 14: Minute Minder
Minute Minder The minute counter function consists simply of an acoustic signal which can be set for a maximum of 23 hours 59 minutes. If the letter A is flashing, press the two buttons simultaneously. To set the time, press button and then button until the required time appears on the display (Fig. -
Page 15: Semi - Automatic Cooking
Semi - Automatic Cooking This automatically switches the oven off after the required cooking time. There are two methods of semi- automatic cooking: 1. METHOD: Programming the cooking time (Fig. 11) – Set the cooking time by pressing button if you have gone beyond the required time. The letter A and the symbol 2. -
Page 16: Automatic Cooking
Automatic Cooking To cook in the oven in automatic mode follow the instructions below: 1. Set the cooking time 2. Set the end of cooking time 3. Set the cooking temperature and function These operations are carried out as follows: 1. -
Page 17: Do's And Do Not's
– Do read the user instructions carefully before using the double oven for the first time. – Do allow the double oven to heat for one and a half hours, before using for the first time, in order to expel any smell from the new oven insulation, without the introduction of food. -
Page 18: Care And Maintenance
Care and Maintenance It is advisable to clean when the appliance is cold and especially for cleaning the enamelled parts. Avoid leaving alkaline or acidic substances (lemon juice, vinegar, etc.) on the surfaces. Avoid using cleaning products with a chlorine or acidic base. WARNING When correctly installed, your product meets all safety requirements laid down for this type of product category. -
Page 19: Replacing The Oven Lights
Replacing the Oven Lights WARNING: Ensure the appliance is switched off before replacing the lamp to avoid the possibility of electric shock. – Let the oven cavity and the heating elements to cool down; – Switch off the electrical supply; –... - Page 20 Assembling and Dismantling of the Side Runner Frames – Assemble the wire racks to the oven walls using the 2 screws (Figs. 16-18). – Slide the tray and rack into the runners (Figs. 17-19). The rack must be fitted so that the safety catch, which stops it sliding out, faces the inside of the oven.
-
Page 21: Removing The Oven Doors
Oven Doors Removing the Oven Doors The oven doors can easily be removed as follows: – Open the door to the full extent (fig. 20a). – Open the lever A completely on the left and right hinges (fig. 20b). – Hold the door as shown in fig. 20. –... - Page 22 Oven Doors - Removable Inner Pane of Glass Cleaning the Panes of Glass The oven doors are fitted with no. 2 panes: - no. 1 outside; - no. 1 inner; To clean the panes on both sides it is necessary to remove the inner pane as follows.
- Page 23 Replacing the Inner Pane of Glass 1. Make sure the door is locked open (see fig. 23). 2. Replace the inner pane: – Check that the four rubber pads are in place (D in Fig. 26). – Insert the pane in the left E and right F slide guides (fig. 27), and gently slide it to the retainers H (fig.
-
Page 24: Advice For The Installer
ADVICE FOR THE INSTALLER Important Appliance installation and maintenance must only be carried out by QUALIFIED TECHNICIANS and in compliance with the local safety standards. • Failure to observe this rule will invalidate the warranty. • Always disconnect the appliance from the electrical supply before carrying out any maintenance operations or repairs. - Page 25 The appliance must be installed in compliance with regulations in force. The built under double oven shall be fitted under the working surface into a kitchen base unit (width and depth 60 cm) but you must ensure that it is properly ventilated.
- Page 26 18 mm, length 650 mm); mount the 2 wood uprights “A” to the cabinet walls as indicated in figure. – Build in the double oven making it slide on the metal supports “B”. Installation "B" between Side Cabinets by Removing Provious Housing (figs.
- Page 27 Installation “A” 600 mm Gap Fig. 34 600 mm Gap Fig. 36 Installation “B” Fig. 35 (*) Measure calculated from the underneath of the worktop to the top support base of the “B” supports. Pre existing 600 mm cabinetry WARNING ! VERY IMPORTANT The underside of the cabinet shall be...
- Page 28 Otherwise the cabinet may have to be removed as in INSTALLATION TYPE "B". • Mount the 2 (two) metal supports “B” (supplied with the appliance in a separate kit) as indicated in Figs. 39). • Build in the double oven making it slide on the metal supports “B”.
- Page 29 Installation “C” Cabinet for installing the oven Remove single oven shelf, if fitted. Fig. 37 15 15 Fig. 39 Fig. 8.3b Measure calculated from the underneath of the worktop to the top support base of the “B” supports. Fig. 38 Support base...
- Page 30 Fixing the Double Oven The double oven should then be secured by 6 screws (not supplied) fitted into the holes provided at the sides of the oven (Fig. 40). If you open the oven doors, you will see some screw holes.
- Page 31 IMPORTANT: – To avoid damage to the lower trim please note the following instructions. – The lower trim is designed to allow for good air circulation and the correct opening of the oven door. – To ensure the trim is not damaged due to the appliance being placed on the floor, the appliance should be suitably supported as in below illustrations.
-
Page 32: Electrical Installation
– Once the appliance has been installed, the switch must always be accessible. – If the power supply cable is damaged it must be substituted by a suitable cable. IMPORTANT: this double oven must be connected to a suitable double pole control unit adjacent to the oven. - Page 33 Connection the Double Oven Mains Cable Important! This oven must be connected to the mains power supply only by a suitably qualified person. Unscrew the screws A securing the cover plate B behind the oven (fig. 44). – Remove the cover plate B.
-
Page 34: Appliance Servicing
Appliance Servicing CDA provide a quality and effective after-sales service to cover all your servicing needs. Please attach your receipt to this page for safekeeping. Please help us to help you by having the following information available when booking a service-call: 1. - Page 35 After the first year and within five years, the parts will be supplied free of charge provided that the repair is carried out by an agent authorised by CDA and the labour will be charged at the commercial rate applicable at the time of repair.
- Page 36 Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu...
