Vivotek AP-FEX-0105-R Quick Installation Manual page 3

Distance/Power Chart
AP-FEX-0105-T
Length of Coaxial Cable AA-420 65W
300m 26.4W
500m 17.48W
800m 12.63W
1000m 8.84W
1200m 8.48W
1200m ~ 2400m Data only (100Mbps)
AP-FEX-0200-T
Length of Coaxial Cable AA-420 65W
100m 20W per port
300m 12W per port
500m 8W per port
500m ~ 2400m Data only (100Mbps)
NOTE:
1. The numberts comply using RG6 coaxial cables.
2. The length of network cable for camera connection is 100m CAT5e cable.
3. The power delivery will vary on the quality of coaxial cable due to resistance.
LEDs
RJ45 Yellow ON
Green flash
OFF
PWR Green ON
LINK Green ON
DIP Switch
NOTE:The PoE On/Off switch is only available on AP-FEX-0105-T/AP-FEX-0200-T
DIP# On Delivery PoE output to PD device
Off No PoE output to PD device
All specifications are subject to change without noice.
Copyright © 2018 VIVOTEK INC. All rights reserved.
VIVOTEK INC.
6F, No.192, Lien-Cheng Rd., Chung-Ho, New Taipei City, 235, Taiwan, R.O.C.
|T: +886-2-82455282| F: +886-2-82455532| E: sales@vivotek.com
All manuals and user guides at all-guides.com
AP-GIC-011A-095 95W
26.4W
17.48W
12.63W
8.84W
8.48W
Data only (100Mbps)
AP-GIC-011A-095 95W
20W per port
12W per port
8W per port
Data only (100Mbps)
PoE: port is suppling power to PD
LAN: Data is being transmitted or received.
No connection
Power is supplied
Rx and Tx EPoC module is connected.
