IN-LINE series
UNDERSINK FILTERS
INSTALLATION, USE AND MAINTENANCE MANUAL
Dear Customer, thank you for having chosen the "Made in Italy" IN-LINE system.
The IN-LINE system comes complete with all the components you need to install the drinking water filter system quickly and
easily under your kitchen sink.
INSTALLATION
NB: Use the diagram to identify the numbered components
KEY (numbered components)
1.
Dedicated tap
2.
ON/OFF lever
3.
Chrome base
4.
Flat seal
5.
Flange
6.
Washer
7.
Nut
8.
Hose lock nut
9.
Plastic ring
INSTALLATION AND START-UP PROCEDURE
1.
Turn the cold water tap (24) OFF.
2.
Position a basin (25) (N.B.: not included) under the filter (14) to collect water from the filter during the IN-LINE start-up
procedure (or during maintenance).
3.
Use a normal drill to make a 12 mm hole in the sink top, preferably in the position marked "H". If the sink top is porcelain,
use a suitable drill though you are advised to have a professional do this.
4.
Fit the dedicated tap (1) to the sink top at "H". Components (1), (2) and (3) go above the sink top while (5), (6), and (7) fit
below as shown in the diagram. Tighten the nut (7) to fix the tap to the sink.
5.
Insert the hose (10) in the hose lock nut (8) then insert the hose (10) inside the plastic ring (9).
6.
Insert the hose (10) in the threaded part of the tap (1) then tighten the hose lock nut (8).
7.
Connect the main body of the by-pass unit (21) to the cold water piping (23) keeping the female threads facing up and
the male down: screw the by-pass unit to the piping applying one turn of tape around the joint (NB: included) to make a
good seal. Screw the part of the by-pass unit with the lever (20) to the by-pass unit main body (21) using tape keeping
the lever in the OFF position.
8.
Fit the hose (10) to the by-pass unit: insert the hose in the by-pass unit body (20) through the hose lock nut (22) then
tighten the nut.
9.
Position the filter (14) vertically or horizontally on the base under the sink, preferably on the same side as the dedicated
Manufacturer's identification:
ATLAS FILTRI s.r.l.
Headquarter: via Pierobon, 32
Production site: via del Santo, 227
I-35010 Limena, Italy
Tel. +39.049.76.90.55 Fax +39.049.76.99.94
www.atlasfiltri.com
10. Hoses
11. Quick-fit couplings
12. Arrow indicating - IN
13. Arrow indicating - OUT
14. Filter
15. Filter housing
16. O-ring
17. Cartridge
18. Clamps
19. Clamp screws
20. By-pass unit with lever
21. Main body of by-pass unit
22. By-pass hose lock nut
23. Cold water piping
24. Cold water tap
25. Water basin
GB
