OPL PROGRAMMING V-SERIES

TWO WAYS TO MODIFY PROGRAMMING OF THE V-SERIES

PREPROGRAMMED FORMULAS
#1
Programming can be accomplished manually using the machine controls or by connecting to
the machine control using a PDA (personal digital assistant). For instructions on using a PDA
with this washer control, please contact your local Dexter distributor.
The keypad layout for the washer control is shown above.
#2

Manual Wash Cycle Programming Instructions

1.
Turn on the power to the washer.
2.
Turn the Run/Program key to the Program position. Display will show "C O" and the
"ADD BLEACH" will blink and will continue to blink during the programming mode.
3.
Press the "DOWN" or "UP" buttons to select which cycle to alter. When the desired
cycle number is displayed, press "START".
4.
The display should now show a "b". The "b" and the cycle indicator lights indicate
which bath is being selected to alter. Press the "UP" and "DOWN" buttons to select a
bath to change and then press "START". The indicator lights are shown below.
FLUSH
When "RINSE" is selected, "b r1" through "b r4" may be selected. There may be
multiple rinses that are indicated by r1, r2, r3 and r4.
PRE
WASH
WASH
OPL
SIX (6)
FINAL
RINSE
RINSE
SPIN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T1450 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dexter Laundry T1450

Summary of Contents for Dexter Laundry T1450

  • Page 1 OPL PROGRAMMING V-SERIES TWO WAYS TO MODIFY PROGRAMMING OF THE V-SERIES SIX (6) PREPROGRAMMED FORMULAS Programming can be accomplished manually using the machine controls or by connecting to the machine control using a PDA (personal digital assistant). For instructions on using a PDA with this washer control, please contact your local Dexter distributor.
  • Page 2 5.Each bath can be programmed with the following options. Use the “DOWN” and “UP” keys to select the desired setting and the “START” key to move to the next option. DISPLAY FUNCTION OPTIONS Ct ** Tumble Time Two-digit amount of time in minutes. Water Temperature HH for hot, CH for warm, CC for cold and EE for no water.
  • Page 3 Cycle 1 Sheets & Pillowcases (Health Care) Bath Bath Cycle Water Water Delay Spin Injection Source Time Temp. Level Fill Time (min.) (min.) Flush Prewash Wash 1 (Detergent) Rinse 1 2 (Bleach) Rinse 2 Rinse 3 Rinse 4 Final 4 (Sour/Soft) Rinse Cycle 2 Towels / Pads / Diapers (Health Care)
  • Page 4 Cycle 3 White Towels (Hotel / Motel) Bath Bath Cycle Water Water Delay Spin Injection Source Time Temp. Level Fill Time (min.) (min.) Flush Prewash Wash 1 (Detergent) Rinse 1 Rinse 2 2 (Bleach) Rinse 3 Rinse 4 Final 4 (Sour/Soft) Rinse Cycle 4 Guest Laundry (Hotel / Motel or Health Care)
  • Page 5 Cycle 5 Rags & Mops (Hotel / Motel) Bath Bath Cycle Water Water Delay Spin Injection Source Time Temp. Level Fill Time (min.) (min.) Flush Prewash Wash Rinse 1 1 (Detergent) Rinse 2 Rinse 3 2 (Bleach) Rinse 4 Final Rinse Cycle 6 Colored Cotton Linen (Food &...
  • Page 6 RAPID ADVANCE MODE To enter the Rapid Advance mode, turn the key CCW. The Rapid Advance setting is not marked next to the key, but turning the CCW until it stops selects this mode. The Rapid Advance mode can be entered from either the Idle mode or during the cycle. If the cycle has not yet started, press the “START”...
