- Page 1 OUTSIDE LIFTS OWNER’S MANUAL 18MAR2022 | 630-00105 B...
- Page 2 THANK YOU From all of us at Harmar, thank you for placing your trust in our products and allowing us to be a part of your journey. For more than 20 years we have been committed to building products that help you maintain independence. With a drive to empower people to live as they choose, Harmar Lifts Lives.
-
Page 3: Table Of Contents
OUTSIDE VEHICLE LIFT TABLE OF CONTENTS TABLE OF CONTENTS INTRODUCTION ..............4 Device Name: Harmar Outside Vehicle Lifts ..... 4 Read and Understand ..........4 Purchasing Information ..........4 Technical Specifications ..........4 General Information ..........4 SAFETY ..................6 Safety Definitions ............6 OPERATION ................ -
Page 4: Introduction
OUTSIDE VEHICLE LIFT: SECTION 1 INTRODUCTION SECTION 1 INTRODUCTION DEVICE NAME: HARMAR TECHNICAL SPECIFICATIONS OUTSIDE VEHICLE LIFTS Visit harmar.com for specifications on your lift model. Indications of Use: The intended use of the Outside Vehicle Lift is to lift a mobility device for patients or GENERAL INFORMATION mobility-impaired persons on and off the vehicle lift. - Page 5 OUTSIDE VEHICLE LIFT: SECTION 1 INTRODUCTOIN Consider the following general information when using your lift. Specifics may vary based on your chair model and lift combination. • Always make certain your lift is fully deployed and flush with the ground prior to loading your mobility device.
-
Page 6: Safety
OUTSIDE VEHICLE LIFT: SECTION 2 SAFETY SECTION 2 SAFETY SAFETY DEFINITIONS This safety alert symbol appears with safety statements. It means attention, become alert, your safety is involved! Please read and abide by the message that follows the safety alert symbol. WARNING Indicates a hazardous situation that, if not avoided, could result in death or serious injury. -
Page 7: Operation
OUTSIDE VEHICLE LIFT: SECTION 3 OPERATION SECTION 3 OPERATION WARNING • Walk the mobility device onto the lifts platform. Driving onto the lifts platform may This lift is NOT meant for human transportation. present complications and/or hazards when stepping off of the mobility device. Any use other than the intended use identified will •... -
Page 8: Lowering The Lift
OUTSIDE VEHICLE LIFT: SECTION 3 OPERATION LOWERING THE LIFT POSITIONING THE MOBILITY DEVICE ONTO THE PLATFORM Insert the key and turn the switch to the ON position. Slowly walk the mobility device onto the platform. Press DOWN on the toggle switch. The platform will unfold automatically, as the lift is lowered. -
Page 9: Securing The Mobility Device
Remove the key. See Figure 3-5. Straps Figure 3-4 NOTES FOR AL015, AL100, AL100HD, Figure 3-5 AL100-DE, AL160 AND AL300-FULL MODELS NOTICE Ensure that the securement system (whether it’s a hold-down arm, hold-down foot or straps) has enough tension to secure the device. -
Page 10: Unloading The Mobility Device
OUTSIDE VEHICLE LIFT: SECTION 3 OPERATION UNLOADING THE SWING-AWAY MOBILITY DEVICE The Swing-Away allows the lift to be swung away from the back of the vehicle for convenient access Insert the key and turn the switch to the ON to the trunk/cargo area. If the lift does not have a position. -
Page 11: Opening The Swing-Away
OUTSIDE VEHICLE LIFT: SECTION 3 OPERATION Pull the T-handle. Grasp the lift firmly and WARNING swing it out, away from the vehicle. See Figure 3-10 ONLY open the Swing-Away on level ground. Failure to open the Swing-Away on level ground may result in losing control of the lift, resulting in personal injury or damage to property. -
Page 12: Closing The Swing-Away
OUTSIDE VEHICLE LIFT: SECTION 3 OPERATION CLOSING THE SWING-AWAY Close the Swing-Away by returning it to the When the Swing-Away is fully closed, the stowed position. See Figure 3-12. T-handle will be fully retracted. See Figure 3-13. Figure 3-13 Install the safety pin. See Figure 3-14. WARNING Figure 3-12 Be sure to stay clear of the latching mechanism to... -
Page 13: Maintenance
OUTSIDE VEHICLE LIFT: SECTION 4 MAINTENANCE SECTION 4 MAINTENANCE This Outside Vehicle Lift is designed to be as trouble • Check for paint chips and touch up bare metal. free as possible. However, some basic maintenance Use a good black enamel or lacquer to inhibit will ensure that it continues to offer reliable use for rust. -
Page 14: Troubleshooting
OUTSIDE VEHICLE LIFT: SECTION 5 TROUBLESHOOTING SECTION 5 TROUBLESHOOTING If the lift does not have power when the key is turned on: • Make sure the lift harness and vehicle harness are connected. Figure 5-1 • Make sure the self-resettable circuit breaker on the red wire by the battery is good. -
Page 15: Motor Covering Wiring Schematic
OUTSIDE VEHICLE LIFT: SECTION 6 MOTOR COVER WIRING SCHEMATIC SECTION 6 MOTOR COVER WIRING SCHEMATIC POLE REVERSING SWITCH KEY SWITCH ACTUATOR LIFT CIRCUIT LIGHT BREAKER BATTERY VEHICLE HARNESS MOTOR COVER TRAILER PLUG LIGHT OUTSIDE VEHICLE LIFT: Owner’s Manual 18MAR2022 | 630-00105 B... -
Page 16: Warranty
SECTION 7 3-YEAR TRANSFERABLE WARRANTY The lift came with a separate warranty form on page Harmar Mobility warrants its lift products against 17. To register the lift, the warranty form must be defects in material, mechanical and electrical returned within ten (10) days of installation. This component (parts), excluding labor costs, batteries, warranty policy page must remain in the owner’s... - Page 17 OUTSIDE VEHICLE LIFT: SECTION 7 WARRANTY PLEASE FILL OUT ALL FIELDS AND RETURN WITHIN TEN (10) DAYS OF PRODUCT INSTALLATION. Fax completed form to 1-866-234-5680 or mail to: Harmar, ATTN Warranty Department, 1500 Independence Blvd., Suite 220, Sarasota FL 34234. PRODUCT INFORMATION PURCHASER INFORMATION Model:...
- Page 18 OUTSIDE VEHICLE LIFT: SECTION 7 WARRANTY This page intentionally left blank OUTSIDE VEHICLE LIFT: Owner’s Manual 18MAR2022 | 630-00105 B...
- Page 19 NOTES OUTSIDE VEHICLE LIFT: Owner’s Manual 18MAR2022 | 630-00105 B...
- Page 20 1500 Independence Blvd. Suite 220 Sarasota, FL 34234 800-833-0478 www.harmar.com...
