  • Page 1 Adjustable Gain Avalanche Photodetectors APD410x Operation Manual 2020...
  • Page 2 Version: Date: 18-Feb-2020 Item No.: M0009-510-951 Copyright © 2020 Thorlabs...
  • Page 3: Table Of Contents

    5.5 Drawings 5.6 Fiber Coupling onto Small Detector Area 5.7 Certifications and Compliances 5.8 Manufacturer Address 5.9 Return of Devices 5.10 Warranty 5.11 Copyright and Exclusion of Liability 5.12 List of Acronyms and References 5.13 Thorlabs Worldwide Contacts and WEEE policy...
  • Page 4: Foreword

    Paragraphs preceded by this symbol explain hazards that could damage the instrument and the connected equipment or may cause loss of data. Note This manual also contains "NOTES" and "HINTS" written in this form. Please read this advice carefully! © 2020 Thorlabs...
  • Page 5: General Information

    If necessary, ask for replacement pack- aging. Refer servicing to qualified personnel! Only with written consent from Thorlabs may changes to single components be made or components not supplied by Thorlabs be used. All modules must only be operated with duly shielded connection cables.
  • Page 6: Ordering Codes And Accessories

    APD, 900 - 1700 nm, 8-32 mounting holes APD410C/M Temperature Compensated, Adjustable Gain Avalanche Photodetector, InGaAs APD, 900 - 1700 nm, M4 mounting holes AC-coupled versions as well as open detector versions (detector cover glass removed) of each model can be ordered on request. © 2020 Thorlabs...
  • Page 7: Getting Started

    Note If you want to use your own power supply, you can ask Thorlabs for an appropriate power con- nector cable. · Carefully unpack the unit and accessories. If any damage is noticed, do not use the unit.
  • Page 8: Operating Instruction

    An open beam should be carefully aligned to the detector. Additional focusing lenses can be easily attached to the Avalanche Photodetectors. The housing is compatible with any number of Thorlabs 1” and ½” threaded accessories. This allows convenient mounting of external op- tics, filters, apertures or fiber adapters.
  • Page 9: Electrical Output

    Attention The optical damage threshold is 1 mW. Exceeding this value will permanently destroy the Avalanche Photodetector! 3.1.2 Electrical Output Thorlabs APD410x Avalanche Photodetectors deliver an OUTPUT voltage, which is a function  of incident light power , detector's responsivity...
  • Page 10: Mounting

    Thorlabs 1” and ½” threaded accessories. This allows convenient mounting of external op- tics, filters, apertures or fiber adapters, as well as providing an easy mounting mechanism using the Thorlabs cage assembly accessories.
  • Page 11: Operation

    Note Avoid saturating the amplifier! Therefore, make sure that the optical input power does not ex- ceed the saturation power level listed in specifications Attention Exceeding the optical damage threshold input power will permanently destroy the detector! © 2020 Thorlabs...
  • Page 12: Recommendations

    Another critical point can be electrostatic coupling of electrical noise associated with ground loops. In most cases an electrically isolated post (see Thorlabs parts TRE or TRE/M) will sup- press electrical noise coupling. You should always try to identify the electrical noise sources and increase the distance to the Avalanche Photodetector.
  • Page 13: Maintenance And Service

    The unit does not need a regular maintenance by the user. It does not contain any modules and/or components that could be repaired by the user himself. If a malfunction occurs, please contact Thorlabs for return instructions. Do not remove covers! High voltage!
  • Page 14: Appendix

    Weight < 0.1 kg ) Ambient temperature within (23 ± 5)°C ) At maximum gain setting. ) Non-condensing All technical data are valid at (23 ± 5) °C and (45 ± 15) % rel. humidity (non condensing) © 2020 Thorlabs...
  • Page 15: Typical Detector Responsivity Curves

    5 Appendix 5.2 Typical Detector Responsivity Curves Typical Detector Responsivity APD410A; M = 100 Typical Detector Responsivity APD410A2; M = 50 © 2020 Thorlabs...
  • Page 16 APD410x Typical Detector Responsivity APD410C; M = 20 © 2020 Thorlabs...
  • Page 17: Typical Output Frequency Response

    For this measurement a test signal, generated by an optical transmitter, was fiber-coupled to the Avalanche Photodetector. The OUTPUT frequency response was measured using a optical network analyzer. Typical Output Frequency Response APD410A Typical Output Frequency Response APD410A2 © 2020 Thorlabs...
  • Page 18 APD410x Typical Output Frequency Response APD410C © 2020 Thorlabs...
  • Page 19: Typical Spectral Noise

    10 kHz, video bandwidth 10 kHz). The optical input of the detector was blocked. The black curve ("Reference") was measured with the same setup and the detector switched off , i.e., it represents the measurement system’s noise floor. Typical Spectral Noise APD410A Typical Spectral Noise APD410A2 © 2020 Thorlabs...
  • Page 20 APD410x Typical Spectral Noise APD410C © 2020 Thorlabs...
  • Page 21: Drawings

    5 Appendix 5.5 Drawings Distance between the surface of the active detector area and the front of the flange Distance A Type A2 Type C Type (2.2 ± 0.3) mm (2.2 ± 0.3) mm (2.1 ± 0.3) mm © 2020 Thorlabs...
  • Page 22 APD410x Dimensions APD410X Series (Imperial) © 2020 Thorlabs...
  • Page 23 5 Appendix Dimensions APD410X/M Series (Metric) © 2020 Thorlabs...
  • Page 24: Fiber Coupling Onto Small Detector Area

    The beam out of the fiber is collimated (transferred into a nearly parallel beam) and afterwards focused by the aspheric lens onto the detector. The X-Y translation mount allows the focused beam to be aligned with the center of the sensor. © 2020 Thorlabs...
  • Page 25: Certifications And Compliances

    5 Appendix 5.7 Certifications and Compliances © 2020 Thorlabs...
  • Page 26: Manufacturer Address

    This precision device is only serviceable if returned and properly packed into the complete ori- ginal packaging including the complete shipment plus the cardboard insert that holds the en- closed devices. If necessary, ask for replacement packaging. Refer servicing to qualified per- sonnel. © 2020 Thorlabs...
  • Page 27: Warranty

    Thorlabs warrants material and production of the APD410x for a period of 24 months starting with the date of shipment. During this warranty period Thorlabs will see to defaults by repair or by exchange if these are entitled to warranty.
  • Page 28: List Of Acronyms And References

    APD410x 5.12 List of Acronyms and References Acronyms Alternating Current Avalanche Photo Diode Continuous Wave Direct Current Light Emitting Diode Noise Equivalent Power Radio Frequencies Silicon Signal-to-Noise Ratio Ultraviolet References Hamamatsu - Technical Information SD-28 © 2020 Thorlabs...
  • Page 29: Thorlabs Worldwide Contacts And Weee Policy

    Contact Thorlabs for more information. Waste treat- ment is your own responsibility. “End of life” units must be returned to Thorlabs or handed to a company specializing in waste recovery. Do not dispose of the unit in a litter bin or at a public waste disposal site.
