www.osram.com
DALI PRO 2 IoT
Quick Start Guide
Please read this guide in full before using our Remote Access service!

Table of Contents

Introduction

Remote Access
is all about making adaptations to a Lighting System without the need to visit the site.
Adaptations are made by changing the configuration file as stored onto the controller.
In general, the configuration file is created during commissioning while being on-site.
To make adaptations to this configuration while not physically on-site, you can use our
OSRAM Web Application Remote Access to change the configuration file from remote.
The Web Application Remote Access allows you to download the configuration file from the
controller, make changes via the PC TOOL and then upload the file back onto the controller.
Customization project version 1.0 Tue 2/11/2020 HL
"Remote Access"
page 01
page 02
page 04
page 05
page 07
page 07
page 09
page 11
page 11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DALI PRO 2 IoT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Osram DALI PRO 2 IoT

Summary of Contents for Osram DALI PRO 2 IoT

  • Page 1: Table Of Contents

    To make adaptations to this configuration while not physically on-site, you can use our OSRAM Web Application Remote Access to change the configuration file from remote. The Web Application Remote Access allows you to download the configuration file from the controller, make changes via the PC TOOL and then upload the file back onto the controller.

  • Page 2: Web Application Remote Access

    The start page will give you two options: 1) Leave the Web Application by the logout button [upper-right corner] 2) Continue with the Web Application by the “Devices” [upper-left corner] DALI PRO 2 IoT Remote Access QUICK START GUIDE V1.2, Fri 1/28/2022 Page 2 of 11...
  • Page 3 To continue, please click on the “Devices” in the left-upper corner. Next, you will see a list of DALI PRO 2 IoT’s which are enabled for remote access feature. DALI PRO 2 IoT’s Devices are identified by their Serial Number. [Header: SN] DALI PRO 2 IoT Remote Access QUICK START GUIDE V1.2, Fri 1/28/2022...

  • Page 4: Enable Remote Access Feature

    To link a particular controller to your account, you must enable the remote access feature and activate the remote-access service on the DALI PRO 2 IoT controller. Enable remote-access feature and activate the service can be done via the built-in WebUI.

  • Page 5: Activate Remote Access Service

    Reload the page, go back to Feature Keys. It will show that Remote Access is now enabled. Activate Remote Access Service In the main menu of the WebUI, click on Remote Access and see Activation status. DALI PRO 2 IoT Remote Access QUICK START GUIDE V1.2, Fri 1/28/2022 Page 5 of 11...
  • Page 6 The “Go to account page” will link you directly to your Web Application Remote Access Please Note: click the “Refresh Data” button to make sure the status is correctly displayed. DALI PRO 2 IoT Remote Access QUICK START GUIDE V1.2, Fri 1/28/2022 Page 6 of 11...

  • Page 7: Download File

    Start the PC TOOL program and open the file. [for example, DALIPro-86000011.osrrd] Select “Project and last device search” and click on the button “Open” DALI PRO 2 IoT Remote Access QUICK START GUIDE V1.2, Fri 1/28/2022 Page 7 of 11...
  • Page 8 Make changes to the configuration as you normally do with the PC TOOL. Use the upload button to save a configuration file on your computer. After saving, a pop-up window appears called “Upload over cloud” DALI PRO 2 IoT Remote Access QUICK START GUIDE V1.2, Fri 1/28/2022 Page 8 of 11...

  • Page 9: Upload File

    Click on the button “Upload File”. [Note: pay attention to select the correct controller] Select the file you want to upload and click on the button “Upload” DALI PRO 2 IoT Remote Access QUICK START GUIDE V1.2, Fri 1/28/2022 Page 9 of 11...
  • Page 10 A pop-up window will confirm a successful uploading of the file. “YOU ARE DONE“ Close the Web Application. DALI PRO 2 IoT Remote Access QUICK START GUIDE V1.2, Fri 1/28/2022 Page 10 of 11...

  • Page 11: Summary

    Initial set up of the lighting system i.e. programming and mapping of Commissioning devices Configuration File Program stored in the memory of the DALI PRO 2 IoT controller A component of a lighting system, controllers, luminaires, buttons or Devices sensors...
