7.3. E M
RROR ESSAGES
There are three error messages relating to faults within the AC Interface Fixture:
For AT3600 only
1. Open Circuit Compensation Error:
The external source is not connected to the Open Circuit Fixture.
2. Internal fault condition:
Safety interlock open (also shows "Safety Interlock Open" message on the AT3600 display). The error
message displayed in the PC Editor is shown below.
A fault has occurred with the external source.
Please check the status of the external source interface and refer to user manual.
Should this error occur, check the operation and installation of the safety light curtain (see AT3600 user
manual).
3. When the AT detects a residual voltage level >40V preceding a test, the error message shown below
is displayed on the AT3600's front panel.
DANGER
Switch OFF and re-start the AT36
Should this occur.
a. DO NOT TOUCH THE PART UNDER TEST OR THE FIXTURE.
b. Switch off the AC source.
c. Switch off the AT3600.
d. Check to make sure the part under test is safe to touch before removing it and powering on
the AT3600 and AC source.
