5. S
PECIFICATION
5.1. T A
ESTS VAILABLE FOR
The following tests are available for use with an external AC source, when a Voltech AC Interface is used in
combination with an AT3600/AT5600:
Test
MAGX Magnetizing
Current
VOCX Open Circuit
Voltage
WATX Wattage
STRX Stress Wattage
Notes:
1) Specification using supplied CT10-20. Up to 1MHz possible with suitable current transducer.
2) 1.5kHz when using the AT3600/AT5600's internal source to power output transformer source
type.
3) A = basic relative accuracy
R
4) 650Vrms for AC measurements, or 900V for DC measurements.
5) Specification valid at 23 ± 5 °C.
V AC I U
OLTECH NTERFACE SER
U AC I
SE WITH THE
User Entered Test Data
Measurement Range
50mA to 10A
100µV to 650V
(4)
100mW to 6kW
100mW to 6kW
M
ANUAL
NTERFACE
Test Signal Test Frequency
5V to 600V 20Hz to 5kHz
1V to 600V 20Hz to 5kHz
5V to 600V 20Hz to 5kHz
5V to 600V 20Hz to 5kHz
45
PAGE
A
(3)
R
(1)(2)
0.1%
0.1%
1%
1%
