2.4. C
ONNECTIOSN TO THE
When used with an AC Interface, the fixture requires the additional input of the test signal from 'External
Source Output to Fixture' sockets of the AC Interface.
These connections will provide the power for testing. Sense connections to nodes on the fixture must
also be made, so that the AT3600/AT5600 can measure and trim the voltage at the terminals of the winding
under test.
The power connection will also be made to the same nodes, so that the AT3600/AT5600 can conduct tests
that are stored in the same program but that do not use power from an external source, for example the
more traditional R, LS RLS tests.
Once wired, the nodes can be selected for program use in the PC Editor.
Node 13 P
AC From
Interface
Node 11 P
V AC I U
OLTECH NTERFACE SER
T F
EST IXTURE
S 4mm Sockets
Fixture Wiring or
Kelvin Leads
S
M 98-072 7
ANUAL ISS
Winding
Under Test
