CARRUCA L-SHAPE

Assembly Instructions

Thank you for your purchase!

Iron Age Office furniture is uniquely and individually

fabricated. For this reason, your furniture is pre-assembled

and labeled before shipping. Labels are marked on the

underside of the furniture. The furniture is then

deconstructed prior to shipping. Pieces that uniquely

correspond can typically be found on the same pallet.

Assembly is best completed by keeping the pieces that

correspond together. Clear your work area of anything that

could scratch furniture surfaces. If possible, cover your

work area with a clean, soft blanket. Carefully flip

any wooden tops over and inspect the bottom sides

for markings. Match legs, flat brackets, etc.

to the appropriate labels.

If you need further assistance of any kind,

please contact:

Iron Age Office Operations Manager

678-725-1473 (c)

hd@ironageoffice.com

Henry Dover

Table of Contents

Need help?

Do you have a question about the CARRUCA L-SHAPE and is the answer not in the manual?

Page 1 CARRUCA L-SHAPE Assembly Instructions Thank you for your purchase! Iron Age Office furniture is uniquely and individually fabricated. For this reason, your furniture is pre-assembled and labeled before shipping. Labels are marked on the underside of the furniture. The furniture is then deconstructed prior to shipping.
Page 2 HARDWARE Screws are shown actual size. You may receive extra hardware with your unit. Tools Required 14-10 LAG BOLT #3 Square Drive QTY: 21 SCREEN BOLT 3/8 Hex Drive QTY: 4 15/16 Crescent Wrench SCREEN NUT QTY: 4 LEVELING FOOT 9/16 Crescent Wrench QTY: 6...
Page 3 PARTS MAIN TOP LEFT TABBED LEG RETURN TOP RIGHT TABBED LEG STANDARD LEG MAIN SCREEN SPLICE PLATE...
Page 4 ASSEMBLY STEP 1 Place wood top face down on a clean surface. STEP 2 Align legs to wood top using markings on the underside of main top. Tabbed legs should be placed so that tabs are facing each other. Screw in all legs with (5) 14-10 lag bolts per leg.
Page 5 ASSEMBLY STEP 4 Align splice top to main top. Attach splice plate at connection with (3) 14-10 lag bolts using a #3 square drive. STEP 5 Screw in (2) leveling foot in each leg. Screw in leveling foot into each leg with 9/16 crescent wrench.
Page 6 STEP 7 Enjoy your desk! CARE INSTRUCTIONS To care for either wooden or metal surfaces of Iron Age Office products, gently wipe with a soft cloth dampened with water and a mild dishwashing liquid. Once satisfied, dry with a soft cloth.
