- Page 1 MANLEY LABORATORIES, INC. OWNER'S MANUAL LANGEVIN 150 WATT DUALMONOBLOCK AMPLIFIER MANUFACTURED BY: MANLEY LABORATORIES, INC. 13880 MAGNOLIA AVE. CHINO, CA. 91710 TEL (909) 627-4256 FAX: (909) 628-2482...
-
Page 2: Table Of Contents
CONTENTS SECTION PAGE INTRODUCTION MAINS CONNECTIONS CONNECTING YOUR AMPLIFIER REAR PANEL OPERATIONAL NOTES SPECIFICATIONS WARRANTY WARRANTY REGISTRATION NOTES... -
Page 3: Introduction
Manley Laboratories' Langevin 150 Watt Solid State Amplifier. Designed around the concept that less is more, the Langevin 150 Watt Solid State Amplifier uses the best available parts with the shortest, cleanest, signal path possible. With the use of our own C.N.C. milling machine, we can provide you with a superb sounding machine with elegant packaging. -
Page 4: Mains Connections
MAINS CONNECTIONS The Manley Laboratories' Langevin 150 Watt Solid State Amplifier requires a significant amount of AC current to operate properly. For best operation, plug the amplifier directly into the wall outlet, avoiding extension cords and other devices which restrict the current supply to amplifier. If extension cables are required, be certain that they are high quality, heavy duty (14-12 guage) cables. -
Page 5: Connecting Your Amplifier
CONNECTING YOUR AMPLIFIER Setting up your amplifier is rather easy. 1. Connect all source components (turntable, CD, Tuner, Tape DAT, etc.) to your preamplifier. 2. Connect the interconnects from the output of the preamplifier or switching center to RCA input. 3. -
Page 6: Rear Panel
REAR PANEL IEC MAINS CONNECTOR Standard mains connector. Connect an IEC mains cable to a 50/60 Hz AC receptacle. MAINS FUSE Use a 3 amp (110, 120 mains voltage) or a 2 amp (220, 240 voltage) SLO-BLO fuse. GROUND BINDING POSTS Use to connect Chassis ground (Black) to Circuit Ground (Green) RAIL FUSES Use only a 5 Amp FAST BLOW fuse in each voltage rail. -
Page 7: Operational Notes
OPERATIONAL NOTES SWITCHING ON With monoblocks we suggest that you turn on one amplifier first allowing about thirty seconds to pass before powering the other. Also, ALWAYS turn ON your preamplifier or console FIRST and let this settle before turning on the amplifiers. RUNNING It is not recommended that you leave your amplifier permanently switched on. -
Page 8: Specifications
SPECIFICATIONS Output Power 20 Hz - 20 KHz, 8 Ohm Load 130 Watts .15% T.H.D. 4 Ohm Load 225 Watts .15% T.H.D. Input Sensitivity 1 Volt Input Impedance 49 Kohm Output Impedance < 1 Ohm Power Consumption 50 W Quiescent 360 W Peak (4 ohm) 250 W Peak (8 ohm) Mains Fuse... -
Page 9: Warranty
If you believe this to be a new unit then please contact the factory with the details of purchase. This warranty is provided by the dealer where the unit was purchased, and by Manley Laboratories, Inc. Under the terms of the warranty defective parts will be repaired or replaced without charge, excepting the cost of tubes. -
Page 10: Warranty Registration
Registration entitles you to product support, full warranty benefits, and notice of product enhancements and upgrades. You MUST complete and return the following to validate your warranty and registration. Thank you again for choosing to use Manley Laboratories. MODEL ____________________ SERIAL No.
