Manley 100 WATT STEREO AMPLIFIER Owner's Manual

100 watt stereo amplifier

Advertisement

Quick Links

MANLEY
LABORATORIES, INC.
OWNER'S MANUAL
MANLEY 100 WATT
STEREO AMPLIFIER
MANLEY LABORATORIES, INC.
13880 MAGNOLIA AVE.
CHINO, CA. 91710
TEL: (909) 627-4256
FAX: (909)628-2482

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 100 WATT STEREO AMPLIFIER and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Manley 100 WATT STEREO AMPLIFIER

  • Page 1 MANLEY LABORATORIES, INC. OWNER'S MANUAL MANLEY 100 WATT STEREO AMPLIFIER MANLEY LABORATORIES, INC. 13880 MAGNOLIA AVE. CHINO, CA. 91710 TEL: (909) 627-4256 FAX: (909)628-2482...
  • Page 2: Table Of Contents

    SECTION INTRODUCTION MAINS CONNECTIONS CONNECTING YOUR AMPLIFIER BIAS PROCEDURES OPERATIONAL NOTES SPECIFICATIONS WARRANTY WARRANTY REGISTRATION CONTENTS PAGE...
  • Page 3: Introduction

    THANK YOU!... for choosing the Manley Euro 100 Stereo Amplifier. Designed by David Manley, the Manley Euro 100 Stereo Amplifier uses only the best available components, with the shortest and cleanest signal path possible, and with the use of our own milling equipment we can provide you with a amplifier that looks as good as it sounds. For this amplifier design, we have chosen an interesting Russian military tube, the GammaY50.
  • Page 4: Mains Connections

    MAINS CONNECTIONS Your amplifier has been factory set to the correct mains voltage for your country. The voltage setting is marked on the serial badge, located on the rear panel. Check that this complies with your local supply. Export units for certain markets have a moulded mains plug fitted to comply with local require- ments.
  • Page 5: Connecting Your Amplifier

    CONNECTING YOUR AMPLIFIER Setting up your amplifier is rather easy. 1. Connect all source components (turntable, CD, Tuner, Tape DAT, etc.) to your preamplifier. 2. Connect the interconnects from the output of the preamplifier or switching center to the RCA input on the top rear of the amplifier. 3.
  • Page 6: Bias Procedures

    Should you have any questions, or wish to purchase approved tubes from us here at Manley Labs, please do not hestitate to call. BIAS PROCEDURES...
  • Page 7: Operational Notes

    OPERATIONAL NOTES SWITCHING ON The power switch is located on the lower left hand corner of the front panel. Push the top of the rocker switch (1) to turn on the amplifier and the bottom of the rocker to turn off the amplifier. The LED on the right side of the front panel will illuminate indicating that the amplifier is operating.
  • Page 8: Specifications

    Vacuum Tubes: Output Power Frequency Response, +/- .5 dB Input Sensitivity Input Impedance Load Impedance S/N Ratio @350W Power Consumption Mains Fuse B+ Fuse Dimensions Weight SPECIFICATIONS 4 x Y50 (Output), 2 x 6350 (Driver), 2 x 12AT7 (Input) 88 Watts @1Khz 1.5%THD, into 5 ohms 10 Hz - 35 KHz 800 mV 100 KOhm...
  • Page 9: Warranty

    WARRANTY All Manley Laboratories equipment is covered by a limited warranty against defects in materials and workmanship for a period of 90 days from date of purchase to the original purchaser only. A further optional limited 5 year warranty is available to the original purchaser upon proper registration of ownership within 30 days of date of first purchase.
  • Page 10: Warranty Registration

    WARRANTY REGISTRATION We ask that you please fill out this registration form and send the bottom half to: Registration entitles you to product support, full warranty benefits, and notice of product enhancements and upgrades. You MUST complete and return the following to validate your warranty and registration.
