These are typically single miked or multi-miked where each mic might be a different type and different distance from the source. So the TNT might be the ideal cost-effective solution for these situations – maximum choices & minimum cost and rack space and where you need to know you are using the one of the best.
Normally this switch should be in the “+4 BAL” or Center position. Some PRO gear may prefer the “+4 unbalanced” position but this style of input is becoming increasingly rare, however because the TNT loses 6 dB of headroom in this mode, it can be used for crea- tive “drive”...
14) GAIN TRIM POT: This pot is typically used to fi nely adjust the gain as needed for the recording device or converter. The two top LEDs are associated with this knob, and are intended to help set optimal levels, which are well (about 10dB) below when the TNT clips.
“just” impedance controls without baggage. Some users may expect bigger sonic changes from huge im- The initial concept of the TNT was to put two very dif- pedance changes or major audible effects from vary- ferent mic preamp technologies in the same box, and ing the IRON content, but the folklore surrounding that each were to be as simple as “plug in a mic and...
Page 7
FET / op-amp circuits and the TNT requires a pair of those hybrids for bal- Maybe the TNT might be viewed as a bit of a myth- ancing (8 discrete matched FETs). There are a few buster in regards to “variable impedance”. Yes, it is interesting twists here too.
It also resembles or EQ gain controls, if you’re not. The TNT has quite the 50 ohm or 75 ohm terminated lines used for video a bit of headroom (except in 60’s / 70’s mode) so there...
Page 9
We touched on using the impedance switch by ear At very low impedance settings with dynamic and rib- and how the low impedance settings may be tighter bon mics another effect can come into play. Damping in the lows, the medium impedance settings might be is a term normally associated with speakers that refers to the fact that a dynamic speaker comes to rest faster the ticket for the advantages of blended preamp those...
The Tube Channel Are there any tricks to using it, anything in particular The left side (T) or channel one, is almost an exact rep- to be concerned about or suggestions about its care lica of the SLAM! Mic Preamplifier and audio path. and feeding? Practically none.
Page 11
$300 tubes on ebay, and that’s OK, but most we occasionally made great sounding records. Back of us (and Manley Labs) tend to just use the $15 to $30 then, we weren’t looking for ‘air’, ‘warmth’ or ‘loud’,...
Page 12
On the other hand, we might suggest avoiding the dry technical literature that seems to be the majority of As a matter of fact, one can view the TNT as a single the recent texts on recording technology. Those might...
The IRON control may also be subtle in many situ- ations because it uses the actual output transformer The No Tubes side of the TNT gives you a range of (which starts off pretty good) rather than a fake simu- colors and might even be considered a contrast to the lation just labeled to suggest a sound.
Page 14
TNT. In that situation the of a transformer in the next piece of gear following IMPEDANCE switch becomes very dramatic and TNT, such as a compressor – kind of like “cleaner the high impedance settings like “3 meg” and “10 than clean”.
Page 15
You might path. And keeping it clean, you may want to leave the use the 4 LEDs on the TNT. The first or bottom is a “IRON” knob set at 12:00 or straight up. Turning the “signal present indicator”...
Page 16
EQ “absolute clean” use the ¼” output, and the IRON at the TNT output, and you might try feeding a real knob set to 1 (12 o-clock, straight up) to avoid any speaker/room/mic or convolution reverb so that it transformer coloration.
Page 17
This is how we should approach the Hysteresis shapes the waveform for low level, low controls on the TNT, and maybe what should become frequency signals, putting a couple of bends around the criteria for choosing it against other preamps.
Page 18
CMRR problems for the sake of idiot-proofing and people using funky cables and adapters. The TNT just uses a switch. Transformers have traditionally been great at the idi- ot-proofing aspect and are very “forgiving” and solve more practical connection issues than they create.
Check the cables carefully because occasionally a cable gets modified to work with a certain unit and it seems to work but its wrong in other situations. If only one side of the TNT exhibits this problem, it may be a problem in the TNT.
Page 23
You might be accustomed to that preamp’s design flaws. With the TNT, changing the Impedance switch tends to be subtle. Worst case would be very low source impedance which corresponds with 4 dB gain change acrosss the five Impedance switch settings.
MAINS CONNECTIONS Your TNT has been factory set to the correct mains voltage for your country. The voltage setting is marked on the serial badge, located on the rear panel. Check that this complies with your local supply. Export units for certain markets have a moulded mains plug fi tted to comply with local requirements. If your unit does not have a plug fi...
SPECIFICATIONS TUBE CHANNEL (Left Channel) GAIN RANGE +10 dB to +80 dB (20-70dB in 5 dB steps) MIC INPUT IMPEDANCE 600, 2400, 10,000 Ohms INSTRUMENT INPUT IMPEDANCE 300K,1Meg, 3 Meg Ohms FREQUENCY RESPONSE (-1 dB) 10 Hz to 30 kHz (-3dB) 5 Hz to 45 kHz THD &...
