OPERATING AND DISPLAY ELEMENTS: OVERVIEW

3 Operating and display elements: Overview
3.1

Overview of operating unit

0 1 . 0 2 . 2 0 1 8
Figure 4: Front of operating unit
3.2

Output display in the 7-day timer menu

The 7-day timer submenu contains a 24-hour display of the output levels for the respective zone.
It serves as a guide for programming the 7-day timer.
If the menu for programming the 7-day timer is called up, the 24-hour display is in the fourth line.
It is adjusted immediately after a change to the 7-day timer. This makes it easy to check whether
the changed settings are effective.
The display consists of 12 bars. Each bar corresponds to an interval of 2 hours, starting with the
interval 0 – 2 o'clock (left bar), ascending in 2 hour steps.
The last bar (right bar) corresponds to the interval 22 - 24 hrs.
The height of the bar indicates the output level at which the controller is set at the time in
question.
> 7 - d a y t i m e r
S u n 0 0 - 0 2 h
V E N T
L V :
24-hour display
Figure 5: 7-day timer submenu - display unit line 4
14
14
i n V E N T e r
M Z - H o m e
1 5 : 0 8
> W o c h e n s c h a l t u h r
0 – 2 h
L E :
Display unit:
The display unit in the upper part of the
operating unit is a liquid crystal display with
backlighting. It consists of four lines of 20
characters each and displays functions and
parameters.
The screen display switches off automatically
after 20 seconds without operation.
Navigation arrows:
The 4 navigation arrows in the lower part of the
operating unit are capacitive buttons. Touching
any navigation arrow activates the display unit
in the upper area of the operating unit, the start
screen is displayed and the controller can be
operated.
S o
10 – 12 h
W R G
+ 2 h
Pause function Ventilation level 2
Ventilation level 1
0 0 - 0 2 h
22 – 24 h
Ventilation level 3
MZ-Home | Operating instructions
