Operating Instructions
inVENTer Connect
Controller platform
www.inventer.eu

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Connect. and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for inVENTer Connect.

Summary of Contents for inVENTer Connect.

  • Page 1 Operating Instructions inVENTer Connect Controller platform www.inventer.eu...
  • Page 2 GmbH. ® The copyright to this document remains with the manufacturer. Rights to all content and images: © inVENTer GmbH 2021. All trademarks used in this document are the property of their respective manufacturers and are hereby acknowledged.

  • Page 3: Table Of Contents

    Sensor technology ......................90 Accessories and spare parts ....................93 Troubleshooting and disposal ....................94 Warranty and guarantee......................97 Service ............................97 10 Annex ............................98 10.1 Ventilation profiles (time intervals of the factory setting) ..........98 10.2 Automatic ventilation profiles ..................101 inVENTer Connect controller platform | Operating instructions...

  • Page 4: User And Safety Instructions

    Book: refers to another section in this documentation.  Action focus: To be taken into account in the corresponding step. Scroll: Operating option within the "inVENTer Mobile" app. By swiping across the screen (horizontally: or vertically: ), you can scroll through various selection and setting screens, e.g.

  • Page 5: Safety Instructions

    Specifically, the following must be used: • The Easy Connect e16 controller to control the devices included in the system. • The Connect inner cover controlled by the controller to control the inVENTer ventilation units with heat recovery. • The sensor system is paired to the controller (FTS19-Connect Indoor/Outdoor humidity/temper-...
  • Page 6 Before the closing flap is (re-)fitted, the locking arm must be swivelled to the right. This is done exclusively using the Easy Connect e16 controller or the "inVENTer Mobile" app. To do this, switch all devices to pause ( 3.6: Boost/Pause or when operating via app  4.2 | 4.8: Set ventilation mode and level).

  • Page 7: System Overview

    In order to be able to use the full range of functions of all devices in the system in the best possi- ble way, we recommend operating and configuring the controller via the "inVENTer Mobile" app. The capacitive sensor keys available on the programming unit can be used to make quick settings for the ventilation system.
  • Page 8 If a device is paired with the controller but is in error mode, the controller updates the device status to mark that device as offline or not present. The user is notified via the display screen or app and can correct the error. inVENTer Connect controller platform | Operating instructions...

  • Page 9: Connect Inner Cover

    If an inner cover is paired to the controller, it controls the associated ventilation unit (one ventila- tion unit per inner cover) using the information received from the controller. It controls 4 ventilation modes with different speed levels in which the respective inVENTer ventilation unit then operates: • Heat recovery In heat recovery mode, each ventilation unit changes direction (supply air / extract air) every 70 seconds.

  • Page 10: Sensor Technology

    SYSTEM OVERVIEW Sensor technology Different sensors are available in the inVENTer Connect controller platform. These are required to monitor the relevant parameters in the various ventilation zones and to ensure automated ventilation control according to the set profiles. Demand-controlled ventilation is enabled in the ventilation zone assigned to the sensor on the basis of the respective reference variable.
  • Page 11 The Outdoor humidity/temperature sensor measures the relative air humidity in the range 20 – 90% and the temperature in the range -20 – 60 °C. inVENTer Connect controller platform | Operating instructions...
  • Page 12 Sensor hierarchy Sensor type Component example Priority 1 Sensor - mains connection CS2-Connect CO2 sensor Priority 2 Sensor - battery-operated FTS19-Connect Indoor Priority 3 Sensor - controller-integrated Easy Connect e16 Table 1: Sensor hierarchy inVENTer Connect controller platform | Operating instructions...

  • Page 13: Inventer Mobile" App

    SYSTEM OVERVIEW "inVENTer Mobile" app The "inVENTer Mobile" app (in the following text "app") is the free app from inVENTer for Android and iOS operating systems for controlling and programming the system. For a more in-depth setup and full functionality access, a mobile device with the "inVENTer Mobile" app installed is required.

  • Page 14: Operation And Set-Up On The Controller

    • Select key This confirms the settings that have been made. • Auto / Boost / Pause key This key is used to set the ventilation modes Auto/Pause/Boost globally or for each zone. inVENTer Connect controller platform | Operating instructions...
  • Page 15 Bluetooth connection is being established BLUE Solid Bluetooth connection established RED / Alternate Error is displayed WHITE flashing YELLOW Flashing An update is being transferred to the controller Table 2: Status LED display inVENTer Connect controller platform | Operating instructions...
  • Page 16 System operating according to 13 Ventilation levels (factory setting) set ventilation profile 25 % 35 % Pause = System is paused Flow rate 50 % Boost = System operating with 100 % maximum air volume flow inVENTer Connect controller platform | Operating instructions...
  • Page 17 The following displays are possible and uniform for all devices to be paired: LED colour LED state Status of the controller TURQUOISE Solid Device not paired GREEN Flashing Devices are paired GREEN Solid Device pairing completed Table 3: Status LED display of paired devices inVENTer Connect controller platform | Operating instructions...

  • Page 18: Initial Setup Of The Controller

    We recommend using the automatically assigned channel. Different channels can be selected for adjacent residential units. The best radio channel is indicated on the control-  ler's display. The LED flashes alternately GREEN and TURQUOISE. inVENTer Connect controller platform | Operating instructions...
  • Page 19 Setting the time Requirements: • Setup by means of the controller. • Firmware and hardware check successful. • The channel for the RF868-MHZ radio connection is selected. The hour setting is active and flashing.  inVENTer Connect controller platform | Operating instructions...
  • Page 20 Press the mode key to complete the time ► setting and go to the date setting. Setting the date The year display is active and flashes.  inVENTer Connect controller platform | Operating instructions...
  • Page 21 Press the navigation keys (up and down ► arrow key) until the current month is set. The current month is set.  Press the mode key and confirm the set ► day and month. inVENTer Connect controller platform | Operating instructions...
  • Page 22 Up to 16 system components (ventilation devices [Connect inner covers], sensors, switching contact) can be paired with the Easy Connect e16 controller. The controller system can then be set up via the "inVENTer Mobile" app or on the controller, e.g. setting ventilation profiles. We recommend setting it up via the app.

  • Page 23: Pairing Of System Components

    To pair system components with the Easy Connect e16 controller and thus integrate them into the inVENTer Connect controller platform, component pairing must first be activated on the controller. Then all system components to be integrated must be activated so that they can be recognised and paired by the controller.
  • Page 24 GREEN during component pairing and lights up solid GREEN when pairing has been completed. On the controller's display screen, after successful  pairing, the displayed number increases by the paired component to "01". inVENTer Connect controller platform | Operating instructions...
  • Page 25 (sensors, switching contact) are paired to the controller, this step can also be performed at the end of the pairing process. Press the mode key to confirm the paired ► components. The display screen shows the information that the  paired Connect inner covers send to the controller. inVENTer Connect controller platform | Operating instructions...
  • Page 26 ► Exit the pause function: Press the Boost / Pause button on the controller several times again until the symbol flashes. Confirm with the select key You have refitted the closing flap.  inVENTer Connect controller platform | Operating instructions...
  • Page 27 The LED on the sensor lights up permanently GREEN. (2) ► Continue numbering the paired components.     • CS2-Connect CO2 sensor/ SK19-Connect switching contact     inVENTer Connect controller platform | Operating instructions...
  • Page 28 It is possible to define up to four ventilation zones. Different ventilation units, sensors and profiles can be assigned to the individual ventilation zones. Please note: additional ventilation zones can only be set up via the app ( 4: Operation and set-up with the app). inVENTer Connect controller platform | Operating instructions...

  • Page 29: Selecting Ventilation Zones / Showing The Status Of Ventilation Zones

    (default profile) and displays the status of ventilation zone 1. Additional ventilation zones can only be set up via the "inVENTer-Mobile" app. If additional ventilation zones (max. 4) have been set up ( 4: Operation and set-up with the app) and each newly set up ventilation zone is assigned a corresponding profile, the status information can also be displayed on the display screen.
  • Page 30 The status incl. all relevant measured values of the  selected ventilation zone is displayed. The displayed number of the ventilation zone  changes with the time display at the top left-hand edge of the screen. inVENTer Connect controller platform | Operating instructions...

  • Page 31: Changing The Fan Settings

    The air flow for each of these 4 levels can be changed via the app. If the default value was changed via the app, the changed air flow is also effective on the controller. inVENTer Connect controller platform | Operating instructions...
  • Page 32 A changed ventilation level is effective for 1 hour as standard and overrides the stored ventilation profile. This duration can be changed via the app. The system then returns to the values stored in the ventilation profile. inVENTer Connect controller platform | Operating instructions...
  • Page 33 Your change is active. The changed ventilation mode is effective for 1 hour by default. This duration can be changed via the app. The system then returns to the values stored in the ventilation profile. inVENTer Connect controller platform | Operating instructions...
  • Page 34 If these sensors are removed or are not paired with the controller, this ventilation zone is reset to the default ventilation profile and a notification is sent to the user. inVENTer Connect controller platform | Operating instructions...
  • Page 35 (ventilation level) again. Your change is active. The icon for the selected ventilation profile appears  on the display screen. The symbol for the first setting option (ventilation  level) starts to flash. inVENTer Connect controller platform | Operating instructions...

  • Page 36: Activating The Boost / Pause Function Globally

    (timer) appears on the display screen. Press the up and down arrow keys to set ► the desired time for pause mode. When setting the pause time, you can choose between 1, 2, 4 and 8 hours. inVENTer Connect controller platform | Operating instructions...
  • Page 37 Here it is ventilation zone 1 (standard zone). Alternating with the zone status, the remaining  pause time is displayed. The set pause time is displayed alternately with the zone status until it expires. inVENTer Connect controller platform | Operating instructions...
  • Page 38 (timer) appears. Press the up and down arrow keys to set ► the desired time for boost mode. When setting the boost time, you can choose between 1, 2, 4 and 8 hours. inVENTer Connect controller platform | Operating instructions...
  • Page 39 Here it is ventilation zone 1 (standard zone). Alternating with the zone status, the remaining  boost time is displayed. The set boost time is displayed alternately with the zone status until it expires. inVENTer Connect controller platform | Operating instructions...

  • Page 40: Activating The Boost / Pause Function By Zone

    Here it is ventilation zone 2, for example. You have selected the zone for which the pause  function is to be set. Press the Boost / Pause key 3 times in ► succession. inVENTer Connect controller platform | Operating instructions...
  • Page 41 2. Alternating with the zone status, the remaining  pause time is displayed. The set pause time is displayed alternately with the zone status until it expires. inVENTer Connect controller platform | Operating instructions...
  • Page 42 Here it is ventilation zone 2, for example. You have selected the zone for which the boost  function is to be set. Press the Boost / Pause key 3 times in ► succession. inVENTer Connect controller platform | Operating instructions...
  • Page 43 2. Alternating with the zone status, the remaining  boost time is displayed. The set boost time is displayed alternately with the zone status until it expires. inVENTer Connect controller platform | Operating instructions...

  • Page 44: Acknowledging Warnings / Notifications

    (e.g. battery replacement) or occur automatically (e.g. limit value exceeded). It expires after the event has been rectified. ► If necessary, remove the reason for notification. The message symbol goes out.  inVENTer Connect controller platform | Operating instructions...
  • Page 45 (until the error has been eliminated). The error can then only be read with the "inVENTer Mobile" app, no longer on the controller. • Each error code is displayed only once, even if the error occurs in the system on more than one component.

  • Page 46: Resetting The Controller And Devices

    ► During these 10 seconds, press the button on the inner cover again to confirm the reset procedure. The LED lights up permanently RED.  The complete start routine then runs as described    for commissioning. inVENTer Connect controller platform | Operating instructions...
  • Page 47 • SK19-Connect switching contact The system is now ready for reconfiguration.  The reset devices must then be re-paired with the Easy Connect e16 controller to be included in the system again ( 3.3: Pairing sensors). inVENTer Connect controller platform | Operating instructions...

  • Page 48: Operation And Setup With The App

    OPERATION AND SETUP WITH THE APP Operation and setup with the app The most convenient way to operate the inVENTer Connect system is with the "inVENTer Mobile" app. This is why mainly this form of operation is described here. To connect the app to the controller, Bluetooth must be enabled and the app must be given loca- tion access.
  • Page 49 A message appears when the connection is completed.  CONGRATULATIONS! You have just completed the setup of your inVENTer. The app allows you to set the unit’s ► Press "Complete setup". ventilator speed and automatic functions. A new window opens.

  • Page 50: The Screen Of The App

    ► Enter a name. This is freely selectable and can consist of a CANCEL maximum of 20 characters. Enter the new product name Keep the inVENTer product name for the controller. Easy Connect e16 ABBRECHEN ► Press "OK". The controller appears on the display screen to indicate that ...

  • Page 51: Device Overview" Menu

    Lorem ipsum Ventilation zone 1 Device symbol the system) Device 5 Device status 25,4°C Ventilation zone 1 22,1% Availability Device identification Device 6 20,4°C 44,1% Ventilation zone 1 inVENTer Connect controller platform | Operating instructions...
  • Page 52 "Radio signal weak": It is recommended to use a signal amplifier (repeater,  4.10) for the paired device. Device acts as a signal amplifier (repeater) for another device in the system Device identification inVENTer Connect controller platform | Operating instructions...

  • Page 53: Device Identification

    Software version: 5.23.0 Device 4 Lorem ipsum Ventilation zone 1 Radio signal Device 5 25,4°C Ventilation zone 1 22,1% Edit device name Device 6 Ventilation device rotation 20,4°C direction (V) 44,1% Ventilation zone 1 inVENTer Connect controller platform | Operating instructions...

  • Page 54: Changing The Direction Of Rotation Of The Fan

    The system automatically ensures that a balance is main- 25,4°C Ventilation zone 1 tained between supply and extract air. 22,1% Edit device name Device 6 20,4°C Ventilation device rotation 44,1% Ventilation zone 1 direction (V) inVENTer Connect controller platform | Operating instructions...

  • Page 55: Assigning Devices To The Ventilation Zones

    Once all devices have been assigned to the desired zones,  Ventilation zone 4 they are displayed in the "Device overview" with the respec- tive new ventilation zone. Device 2 Ventilation zone 1 Device 3 inVENTer Connect controller platform | Operating instructions Ventilation zone 1...

  • Page 56: Defining Ventilation Zones And Their Properties

     Easy Connect e16 Ventilation zone overview Ventilation zone 1 ► Press the tile of the ventilation zone. 25,8°C 24,9% A dot indicates that only one ventilation zone has been defined so far. inVENTer Connect controller platform | Operating instructions...
  • Page 57 Enter new name for zone. This is freely selectable ventilation zone zone 1 Ventilation Default and can consist of a maximum CANCEL of 16 characters. Press "OK" and confirm the new name. inVENTer Connect controller platform | Operating instructions...
  • Page 58 ► Press a ventilation profile to select it. Bedroom The window for ventilation zone 1 appears, to which another  ventilation profile is now assigned. Current ventilator power level 1 Override 25,8°C 24,9% inVENTer Connect controller platform | Operating instructions...
  • Page 59 Default Current ventilator power level 1 Current ventilator power level 3 Current ventilator power level 4 Current ventilator power level 1 Override Override Override Override 18,4°C 39,2% 22,8°C 33,7% 24,3°C 55,4% 25,8°C 24,9% inVENTer Connect controller platform | Operating instructions...
  • Page 60 The boost symbol is displayed in red. 00:59:34 A countdown appears on the screen to show how long the  ventilation zone is still in boost mode. Current ventilator power level 4 Übersteuerung inVENTer Connect controller platform | Operating instructions...
  • Page 61 Current ventilator power level 3 Current ventilator power level 2 Choose ventilation time Choose ventilation time Choose ventilation time Ventilation time: 1 hour Ventilation time: 1 hour Ventilation time: 1 hour Save Cancel Save Cancel Save Cancel inVENTer Connect controller platform | Operating instructions...
  • Page 62 You return to the "Ventilation zone summary" window.  ► Press the "Back" button again to return to the Start menu. Ventilation zone overview Other settings can be made, such as advanced settings.  Device overview Advanced settings inVENTer Connect controller platform | Operating instructions...

  • Page 63: Advanced Settings

    Radio Performance • Restoring factory settings  p. 80 Change system name System reset Restore factory settings By tapping on a menu item, the corresponding menu opens and you can make advanced settings. inVENTer Connect controller platform | Operating instructions...
  • Page 64 Device software 22,1% version 5.20.0 Device 6 20,4°C If you want to update your system, install the new 44,1% Ventilation zone 1 software version. To do this: Install ► Press the "Install" button. inVENTer Connect controller platform | Operating instructions...
  • Page 65 On the app screen, the next circle turns red and the progress  bar shows the transfer status for this device. The software is automatically transferred until the new software version for all components in the system has been transferred to the controller. inVENTer Connect controller platform | Operating instructions...
  • Page 66 An error has occurred and the software update could not be version 5.20.0 successfully performed or completed. The system will try the update again at a later time. Device 4 Lorem ipsum inVENTer Connect controller platform | Operating instructions Device 5...
  • Page 67 Mon, Tue, Wed, Thur, Fri 00:00 - 13:59 lvl.: 2 Mo, Di, Mi, Do, Fr Livng room Living room Save Save Start time Start time Mon, Tue, Wed, 11:00 Thur, Fri 00:00 lvl.: 2 lvl.: 1 inVENTer Connect controller platform | Operating instructions...
  • Page 68 Living room Save ► Press the next button to select the day(s) of the week on Start time which the settings are to take effect. Mon, Tue, Wed, 14:00 Thur, Fri St.: 1 inVENTer Connect controller platform | Operating instructions 13:00...
  • Page 69 Select ventilation mode Startzeit Startzeit Startzeit 14:00 Mo, Di 14:00 Mo, Di 14:00 Mo, Di Save Cancel Save Cancel Save Cancel St.: 3 St.: 3 St.: 3 ► Press "Save" on the desired ventilation mode. inVENTer Connect controller platform | Operating instructions...
  • Page 70 The previous interval takes over the period of the deleted 11:00 - 13:59 lvl.:2 interval. Mon, Tue, Wed, Thur, Fri 14:00 - 21:59 lvl.:1 Mon, Tue, Wed, Thur, Fri 22:00 - 23:59 lvl.:2 Mon, Tue, Wed, Thur, Fri inVENTer Connect controller platform | Operating instructions 00:00 - 13:59 lvl.:2...
  • Page 71 The adjacent window opens.  Maintenance manager Radio Performance The factory setting is displayed.  Change system name System reset Level 1 Restore factory settings Level 2 Level 3 Level 4 100% Save inVENTer Connect controller platform | Operating instructions...
  • Page 72 Select pause duration Select boost duration ► Press "Save". 4 hour 1 hour Your settings for the  duration of boost and pause are used for the Save Save cross-zone boost and pause function. inVENTer Connect controller platform | Operating instructions...
  • Page 73 "NO" to cancel. Reset interval Filterwechselanzeige zurücksetzen Reset indicator for filter change After "OK", the interval  until the filter change is reset to the factory setting (6 months) or your person- al setting. inVENTer Connect controller platform | Operating instructions...
  • Page 74 "OK". TIP: Filter manager ist disabled The following filter maintenance and replacement inter- vals are recommended: Dust filter: 3 months Pollen filter: 1 month Activated carbon filter: 6 months inVENTer Connect controller platform | Operating instructions...
  • Page 75 Device maintenance carried out Intervall zurücksetzen Reset interval "NO" to cancel. After "OK", the remaining  time is reset and the speci- fied interval (factory setting or your personal setting) starts again. inVENTer Connect controller platform | Operating instructions...
  • Page 76 By pressing the "gear symbol" (see above), you can can- cel the deactivation by selecting a maintenance interval again and confirming the selection with "OK". Refer to the instructions of the respective ventilation unit Maintenance manager disabled for the required maintenance interval. inVENTer Connect controller platform | Operating instructions...
  • Page 77 The menu allows you to set a paired device as a signal amplifier for other Connect devices that Device 6 are/will be integrated into the system. The exact procedure can be found in  4.10: Setting up the component as a signal amplifier Signal strength: -36 dB (repeater). inVENTer Connect controller platform | Operating instructions...
  • Page 78 OPERATION AND SETUP WITH THE APP Hours run meter Ventilation levels Changing the system name Boost and pause (cross-zone) Here you can change the name of your inVENTer Connect controller platform (factory setting: Filter manager "Easy Connect e16"). Maintenance manager Radio Performance ►...
  • Page 79 Change system name Sysem reset The system is reset.  Restore factory settings ► Reset all units and sensors and commission the system again as described ( 3.2: Initial set-up and 3.3: Device pairing). inVENTer Connect controller platform | Operating instructions...
  • Page 80 Boost and pause (cross-zone) Filter manager Restoring factory settings Maintenance manager Radio Performance Here you can reset the individual settings of your inVENTer Connect controller platform to the factory settings. Change system name Device pairings remain in place. System reset Restore factory settings ►...

  • Page 81: Setting The Device As A Signal Amplifier (Repeater Function)

    An internal search is made for devices that are available as  signal amplifiers for the device. Device 5 Search for repeater 25,4°C Ventilation zone 1 22,1% Device 6 20,4°C 44,1% Ventilation zone 1 inVENTer Connect controller platform | Operating instructions...
  • Page 82 We recommend keeping the number of repeaters in the Device 3 system low. Ventilation zone 1 Device 4 Lorem ipsum Ventilation zone 1 inVENTer Connect controller platform | Operating instructions Device 5...
  • Page 83 Device 4 We recommend keeping the number of repeaters in the Signal strength: -36 dB system low. Use as repeater Device 5 Signal strength: -86 dB Device 6 Signal strength: -36 dB inVENTer Connect controller platform | Operating instructions...
  • Page 84 The selected device is deactivated as a signal amplifier  (repeater). Device 5 Signal strength: -86 dB Next to the device, the symbol disappears and is replaced  by the button "Use as repeater". Device 6 Signal strength: -36 dB inVENTer Connect controller platform | Operating instructions...

  • Page 85: Cleaning And Care

    • lint-free, soft cloth • soft brush Service recommendations The servicing tasks and intervals listed here are recommended by inVENTer GmbH to maintain the functionality and performance of your controller. Depending on requirements, your personal schedule may deviate from these recommendations.

  • Page 86: Connect Inner Cover

    • soft brush • vacuum cleaner Service recommendations The servicing tasks and intervals listed here are recommended by inVENTer GmbH to maintain the functionality and performance of your inner cover. Depending on requirements, your personal schedule may deviate from these recommendations.
  • Page 87 ► Lift the lower lugs out of the guide ( ► Remove the closing flap from the front. You have removed closing flap on the inner  cover. inVENTer Connect controller platform | Operating instructions...
  • Page 88 CLEANING AND CARE The inVENTer ISO Coarse 45 % dust filters are highly durable and can be rinsed repeatedly. We recommend cleaning the dust filter regularly and replacing worn filters. Pollen and activated carbon filters are available as accessories for special requirements.
  • Page 89 You have attached the closing flap.  ► After all the closing flaps have been fitted, put the system back into operation using the controller or app. ► Reset the filter change interval/service interval in the app. inVENTer Connect controller platform | Operating instructions...

  • Page 90: Sensor Technology

    • lint-free, soft cloth • soft brush Service recommendations The servicing tasks and intervals listed here are recommended by inVENTer GmbH to maintain the functionality and performance of your sensor technology. Depending on requirements, your personal schedule may deviate from these recommendations.
  • Page 91 ► At the bottom, slide the housing over the locking hook and press it gently onto the base plate until it clicks into place ( The batteries have been replaced and the Indoor  humidity/temperature sensor has been reinstalled. CLICK inVENTer Connect controller platform | Operating instructions...
  • Page 92 ► Slide the cover onto the housing. ► Screw the 4 screws back in to fix the cover to the housing. The batteries have been replaced and the Outdoor  humidity/temperature sensor has been reinstalled. inVENTer Connect controller platform | Operating instructions...

  • Page 93: Accessories And Spare Parts

    Easy Connect e16 controller (white) 1003-0123 IB Connect closing flap, BG, RAL9010 3006-0395 IB Connect flush-mounted/surface-mounted housing, R-D160 2003-0245 IB Connect flush-mounted/surface-mounted housing, R-D200 2003-0246 Table 9: inVENTer Connect spare parts IB = Inner cover inVENTer Connect controller platform | Operating instructions...

  • Page 94: Troubleshooting And Disposal

    Firmware and hardware tests of Disconnect the power supply to all devices the controller during the controller were not successful. in the system. Restore the power supply commissioning after a short break. The controller restarts commissioning. inVENTer Connect controller platform | Operating instructions...
  • Page 95 Table 11: Troubleshooting components If you cannot eliminate the fault, please contact our technical customer service. You can find information on how to do this in the following section ( 9: Service). inVENTer Connect controller platform | Operating instructions...
  • Page 96 Printed circuit boards Electronics Collection point for electrical appliances Housing and inner cover PS-SZ / PC Plastic recycling closing flap Batteries (ex works) Alkali-manganese Trade collection points Table 12: Disposal recommendations for components inVENTer Connect controller platform | Operating instructions...

  • Page 97: Warranty And Guarantee

    Outside Germany, the national warranty provisions of the country in which the system is sold apply. Please contact the distributor for your country. Manufacturer guarantee inVENTer GmbH provides a five-year guarantee for electronic components. This covers premature product wear. Further information about the guarantee is available at www.inventer.de/garantie.

  • Page 98: Annex

    Mon, Tue, Wed, Thur, Fri 00:00 - 05:59 lvl.:3 Sat, Sun 06:00 - 13:59 lvl.:1 Sat, Sun 14:00 - 15:59 lvl.:3 Sat, Sun 16:00 - 22:59 lvl.:1 Sat, Sun 23:00 - 23:59 lvl.:3 Sat, Sun inVENTer Connect controller platform | Operating instructions...
  • Page 99 12:00 - 13:59 lvl.:3 23:00 - 23:59 lvl.:1 Sat, Sun Sat, Sun 14:00 - 16:59 lvl.:2 Sat, Sun 17:00 - 18:59 lvl.:3 Sat, Sun 19:00 - 21:59 lvl.:1 Sat, Sun 22:00 - 23:59 Sat, Sun inVENTer Connect controller platform | Operating instructions...
  • Page 100 23:00 - 23:59 lvl.:3 Mon, Tue, Wed, Thur, Fri 00:00 - 07:59 lvl.:3 Sat, Sun 08:00 - 11:59 lvl.:1 Sat, Sun 12:00 - 17:59 lvl.:2 Sat, Sun 18:00 - 23:59 lvl.:1 Sat, Sun inVENTer Connect controller platform | Operating instructions...

  • Page 101: Automatic Ventilation Profiles

    If there is a risk of moisture ingress from the outside, the system pauses and closes the automatic closing flaps. The closed flaps prevent a passive inflow of moisture-laden outdoor air. inVENTer Connect controller platform | Operating instructions...
  • Page 102 ANNEX inVENTer Connect controller platform | Operating instructions...
  • Page 103 ANNEX inVENTer Connect controller platform | Operating instructions...
  • Page 104 GmbH Ortsstraße 4a D-07751 Löberschütz Germany www.inventer.eu Subject to modifications. We accept no liability for printing errors. Item number: 5022-0009 Version: 1.1 – 08/2021...
