PRODUCT SPECIFICATIONS:

Input Voltage:
Power consumption:
Reverse current*:
Nominal output voltage:
Nominal output current:
Charging voltage:
Charging current:
Battery type:
Housing protection type:
Safety class:
*Reverse current is the current used by the charging station battery, when
no mains current is connected.

BOX CONTENTS:

Check the appliance and all accessories for damage immediately after
unpacking. Do not put a defective appliance or parts into operation.
• MB3906 Charger
• Clamps Cable
• Eyelet M6 Cable
• Instruction Manual
220 - 240 V ~ 50 Hz 0.6A
65 W
< 5 mA (no AC input)
6 V DC / 12 V DC / 12.8V DC
0.9 A / 4.0 A / 3.0 A
3 V / 7.4V for 6V battery, 14.5 V / 14.7V
for 12V battery, 14.5V for Lithium (12.8V
4-cells LiFePO4)
0.9 A ± 10 %, 4.0 A ± 10 %, 3.0 A ± 10 %
6V/12V lead-acid battery 12Ah - 120Ah
Lithium (12.8V 4-cells LiFePO4): with a
capacity of 8 - 50Ah
IP 65 (dust-proof, water-proof)
II
