- Page 1 Dual-spectrum PT2 Network Thermal Camera Quick Start Guide V1.0.0...
- Page 2 Please keep the manual properly after reading. Overviews This manual is suitable for dual-spectrum PT2 network thermal cameras. This manual describes the installation steps, installation precautions and basic operations of dual-spectrum PT2 network thermal cameras.
- Page 3 Dual-spectrum PT2 Network Thermal Camera Quick Start Guide ⚫ Please use power adapter which is produced by regular companies. Please check whether the power is normal or not before starting the camera. (Power supply requirements should comply with that on the product labels.) ⚫...
- Page 4 Dual-spectrum PT2 Network Thermal Camera Quick Start Guide detergent, otherwise the camera coating would be damaged and also the camera performance could be degraded. ⚫ The lens cover is optical device, so please do not touch directly or wipe the cover.
-
Page 5: Table Of Contents
Dual-spectrum PT2 Network Thermal Camera Quick Start Guide Table of Contents 1. Camera Introduction ................- 5 - 1.1 Camera Description ................- 5 - 1.2 Camera Features ................- 5 - 1.3 Camera Appearance ................. - 6 - 1.4 Cable Introductions ................- 6 - 1.5 Alarm Interface Connection ............. -
Page 6: Camera Introduction
1.2 Camera Features ⚫ With the latest InfiRay® 12μm IR thermal imaging detector, the thermal camera can make farther and clearer images. ⚫ With a maximum thermal imaging resolution of 1.3 megapixels and a 20x 4 megapixel visible light camera，high-definition dual-spectrum... -
Page 7: Camera Appearance
⚫ Single IP ⚫ With ±2℃ high temperature measurement accuracy 1.3 Camera Appearance Figure 1.1 Appearance of Dual-spectrum PT2 Network Thermal Camera 1.4 Cable Introductions The cable includes interfaces for power, alarm, audio, RS-485, and network, etc. Please see the following figure for interface introductions. - Page 8 Dual-spectrum PT2 Network Thermal Camera Quick Start Guide ⚫ P3 audio output（AUDIO OUT）：Output audio signal to speakers and other equipment for sound output. ⚫ P4 audio input（AUDIO IN）：Input audio signal and connect microphone for receiving linear analog audio signal to collect sounds.
-
Page 9: Alarm Interface Connection
Dual-spectrum PT2 Network Thermal Camera Quick Start Guide 1.5 Alarm Interface Connection The camera can be connected with alarm signal (0～DC5V) input and switch output (no voltage). An external power supply is required when connecting the alarm apparatus. The specific wiring method is shown in the figure below. -
Page 10: Mounting Bracket
Dual-spectrum PT2 Network Thermal Camera Quick Start Guide ⚫ Before performing cable wiring operations, familiarize yourself with the installation environment, including wiring distance, wiring environment, and whether it is far away from magnetic field interference and other factors. ⚫ Please select a wire with a rated voltage greater than the actual line voltage for the PT to ensure the normal operation of the PT under the condition of unstable voltage. -
Page 11: Tf Card Installation
Dual-spectrum PT2 Network Thermal Camera Quick Start Guide 2.4 TF Card Installation Step 1: The TF card slot is located inside the device. Unfold the protection cover with the middle-sized cross screwdriver. After opening the shield, slowly insert the TF card into the TF Step 2: card slot in the direction indicated by the arrow. -
Page 12: Install Network Port Protective Cover
Dual-spectrum PT2 Network Thermal Camera Quick Start Guide Figure 2.2 Installation Illustrations 2.6 Install Network Port Protective Cover When using the camera, install the matching network port waterproof cover to prevent water from entering the network cable. Please install it if necessary. The... -
Page 13: Operation Guide
Dual-spectrum PT2 Network Thermal Camera Quick Start Guide Figure 2.3 Network Cable Installation Step 4: Align the notch of the network port with the buckle of the main body of the waterproof cover, put the main body of the waterproof cover into the end of the network port, and tighten it clockwise. -
Page 14: Login System
Dual-spectrum PT2 Network Thermal Camera Quick Start Guide 3.2 Login System 1.Enter the IP address of the PT in the address bar of IE browser to log in, and the login page is as shown below. Figure 3.1 Login Interface 2. -
Page 15: Main Interface Description
Dual-spectrum PT2 Network Thermal Camera Quick Start Guide 3.3 Main Interface Description The main interface of the PT camera is divided into system menu, video window adjustment, video window function options, PT configuration, PT settings, etc. Please refer to the web operation manual for details. -
Page 16: Appendix A Camera Maintenance
Dual-spectrum PT2 Network Thermal Camera Quick Start Guide Appendix A Camera Maintenance Lens Maintenance The lens surface is coated with anti-reflective coating. When contaminated with dust, grease, and fingerprints, harmful substances will be produced and the degraded performance, cratches, or mold will be caused. Once dirt is found, please follow the following methods. -
Page 17: Appendix B Operating Distance
Dual-spectrum PT2 Network Thermal Camera Quick Start Guide Appendix B Operating Distance The recommended distance of detecting, recognizing and identifying for man (1.8× 0.5m) and vehicles (1.4× 4.0m) are as follows: Equipped Lens （Vehicles） （Human） （Vehicles） （Human） （Vehicles） （Human） 9.1mm 1.16km... -
Page 18: Appendix C Emissivity Of Common Materials
Dual-spectrum PT2 Network Thermal Camera Quick Start Guide Appendix C Emissivity of Common Materials Temperature（℃） Material Emissivity Water 0～100 0.95～0.98 Soil(dry) 0.92 Soil(wet) 0.95 Woods 0.962 Sand Sandstone 0.909～0.935 PVC plastic 0.93 Asphalt 0.967 Paint 0.92～0.94 Wallpaper 0.85～0.90 Cloth 0.98 Concrete 0.92...
