Hillsdale Furniture Clarion Quick Manual

Examine all packaging material for small parts that may have come loose during shipment. Periodic checks are recommended to insure that all components are
in proper position, tight and free from damage. Keep this assembly instruction for future reference. Adult assembly is required. The product of Hillsdale Furniture,
LLC is designed for residential use only. Customer Service Phone Number: 502-562-0000
CODE QTY
1 4 Ø5/16" x 2½" Hex Nuts
2 4 Ø5/16" Spring Washers
3 4 Ø5/16" Flat Washers
4 8 M6 x 40mm Allen Bolts
5 12 M6 x 60mm Allen Bolts
6 20 M6 Spring Washers
7 1 Open Wrench
8 1 Allen Wrench
9 4 Adjustable Feet
10 8 Wood Button
• Do not let any sharp objects touch or rub the surface of the product.
• When assembling, do not let children play around the working area.
• Please confirm all parts are correct before starting the assembly process.
• Do not tighten all bolts and screws completely until the entire unit has been assembled and set up.
• Be careful if using power tools as they can over tighten screws and strip threads.
CARE & MAINTENANCE: The touch of a soft cloth is all the maintenance the finish will ever need. Please do not use harsh or abrasive cleaners for polishing, as they may
cause damage to the finish. Periodic checks are recommended to make sure that all hardware is securely tightened.
Clarion
Model #103680-110784 (4541-810) - Dining Table - Top
Model #103681-110786 (4541-811) - Dining Table - Base
Round
Model #103680-110806 (4542-835) - Counter Table - Top
Table
Model #103687-110807 (4542-836) - Counter Table - Base
HARDWARE
A
E
C
CODE QTY COMPONENTS
A 1 Table Top
C 1 Leg 1
E 4 Bottom Supports
B
F
E
E
E
D
WARNING
Date: 05-17-2017
Page 1 of 2
CODE QTY COMPONENTS
B 1 Pedestal
D 1 Leg 2
F 4 Top Supports
HDFKC
