- Page 1 V33 Plus User Manual The information in this manual is subject to change without notice. www.rexingusa.com...
-
Page 2: About This Manual
Content may differ from the final product or from software provided by service providers and is subject to change without prior notice. • For the latest version of this manual, refer to the Rexing /rexingusa website at www.rexingusa.com. •... -
Page 3: Table Of Contents
Table of Contents About This Manual 5. Device Settings Table of Contents Video Settings 1. What’s in the box System Settings Photo Settings 2. Camera Overview 6. Troubleshooting Device Layout Buttons Update Firmware Status Icons 7. Product Specifications 3. Get Started 8. -
Page 4: What's In The Box
For more information about available accessories, refer to www.rexingusa.com. Quick Start Guide Safety Guide 3M Adhesive Mount Cable Adhesive Spacer Cable Management Tool Rexing V33 Plus Dash Camera 64GB Micro SD Card Car Power Connector (12ft) V33 Rear Camera with Extension Cable (22ft) -
Page 5: Camera Overview
2. Camera Overview Buttons Device Layout Button Function Press: Display on or off Hold: Turn the device on or off manually Menus: Confirm a selection Video Mode: Start/stop recording; Hold to lock current recording Photo Mode: Take photos Playback Mode: Start/stop playback 4. -
Page 6: Status Icons
Status Icons Memory Card (Inserted) Exposure Icon Indication QHD+QHD+QHD Video Resolution GPS Signal Acquired Currently Recording (Blinking) GPS Searching for Signal Wide Dynamic Range Enabled Current Recording Locked Connected to Power Source IT Lights Auto Audio Recording Enabled G-Sensor Level Audio Recording Disabled Video Recording Mode QHD+QHD+QHD... -
Page 7: Get Started
Removing the Memory Card Orient the mount as shown Before removing a memory card from your V33 Plus, you must first dismount it for safe removal. Step 2: Inserting the Memory Card With the device powered down, press down the memory The V33 Plus accepts Micro SD memory cards (class 10 or card until you hear a click. - Page 8 Connecting the charger improperly may cause serious damage to the device. Any damage caused by misuse is not covered by the warranty. Use only Rexing-approved chargers. Using unapproved chargers or cables can damage the device. If the device receives an unstable power supply, the screen may not function properly.
-
Page 9: Mount The Rear Camera
Step 5: Installing the Camera onto the Windshield Mount the rear camera as shown below. Use rear camera cable to connect the rear camera to the V33 Plus camera. Place the camera on the mount and carefully route the power cable around the windscreen and tuck in under the trim. -
Page 10: Basic Operation
Doing the same to manually turn off the device and a goodbye message will be displayed. The camera automatically starts recording when it is powered on The V33 Plus will switch on or off automatically if you keep it connected using charger. -
Page 11: Playback
also lock videos after recording by using the Protect function in 4.2.1 Camera Playback Mode the Playback Menu. Locked videos can be found on the memory card under "\CARDV\MOVIE\RO". To play recordings on your device: Automatic Shutdown Switch to Playback Mode by holding the MENU button. Use the UP and DOWN buttons to browse your videos. -
Page 12: Computer Playback
When prompted with "Erase All Recordings?" press the Installing the application: DOWN button to scroll down to "OK" and press OK to delete all recordings. Locate your dash cam at support.rexingusa.com to access the GPS Playback software. Download the zip folder containing the software installer. Unzip the folder to access the installer file contained 4.2.2 Computer Playback within. -
Page 13: Wi-Fi Connect
4.3 Wi-Fi Connect Additional Controls Snip: Save the current frame of video as an image (PNG). Step 1 Full Screen: View the video in full screen (double-click the video With your dash cam powered on, hold the UP navigation to exit). button to enable the Wi-Fi function. - Page 14 In the app, hit the "Connect" button to connect to your dash cam, allowing you to access live view and view/download If you bring up the Rexing connect app and cannot connect your recordings. your phone to the dash cam please go to https://www.rexingusa.com/wifi-connect/...
-
Page 15: Parking Monitor
Rexing Smart Hardwire Kit (sold separately). Option 2: Motion Detection To use this feature, you need to connect it with a Rexing Intelligent Hardwire Kit (sold separately). Make sure that the Parking Mode is turned off on your dash cam. -
Page 16: Device Settings
5. Device Settings 128GB 14 hours 20 hours 256GB 28 hours 40 hours 5.1 Video Settings Note: Choosing a single-channel resolution such as UHD, QHD, etc. will disable recording with the cabin and rear camera. Mode, press OK to stop recording, then press MENU once to Loop Recording open the Video Menu. - Page 17 Exposure G Sensing Default setting: +0.0 Default setting: Low Manually adjust the camera’s If a change in gravitational exposure value to brighten or forces is detected, such as darken recordings. Positive in the event of a vehicular values brighten recordings accident, the G-sensor will while negative values darken signal to the camera, and an...
- Page 18 IR Light Parking Monitor Default setting: Auto Connect the dash cam to a smart hardwire kit or an Auto handle light intelligent hardwire kit (both conditions and ensures flawless sold separately) to activate video footage even when the the parking monitor passenger cabin is dark.
-
Page 19: System Settings
5.2 System Settings Beep Sound Press MENU twice to open the Setup Menu (in Video Recording Default setting: On mode, you must first stop recording which is done by pressing Enable or disable the device’s UP). sound effects. Wi-Fi Default setting: Off Turn this feature... -
Page 20: Photo Settings
Screen Saver Version Default setting: Off Displays the current device firmware information. M3TA00.670.453.220526.01 Specifies duration which the display will stay on after the device is powered on. Having this setting disabled Photo Settings (default) will keep the display on constantly. You can press These settings affect your still photo captures. - Page 21 Quality Default setting: Normal Default setting: Auto Set the quality level of captured Adjust the camera’s sensitivity images. Lower quality images to light when taking photos. will take up less space on the The higher the ISO, the better memory card, but they are the camera operates in low more visually compressed than light, although images are...
-
Page 22: Troubleshooting
Quick Review Watch out video tutorial on Default setting: Off https://youtu.be/0hRcKo0Bmko Upon capturing an image, the image will be previewed on the display for a few seconds before returning to Photo Mode. To update your camera’s firmware: Date Stamp Format the memory card using the Format function (See Page 16). - Page 23 Specifications Loop Recording 1 min / 2 mins / 3 mins / Off Screen Saver 15 secs / 1 min / Off Audio Recording On / Offff Front - Sony Starvis 307, Image Sensor GPS Logger Built-in Cabin - OV2053 Wi-Fi Built-in Fixed-focus with full-glass...
-
Page 24: Warranty & Support
8. Warranty & Support Warranty The Rexing V33 Plus Dash Cam comes with a full 12- month warranty. If you register your product on our official site https://www.rexingusa.com/support/registration, extend the warranty to 18 months. Support If you have any questions regarding your product, please do not hesitate to contact us at care@rexingusa.com, or call us at... - Page 25 FCC Warnning: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection againstharmful interference in a residential installation. This equipment generates, uses and can radiateradio frequency energy and, if not installed and used in accordance with the instructions, maycause harmful interference to radio communications.
- Page 26 FCC ID:2AW5W-V33 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment.
