CAN Output

Output Data Rate
Data available
RS232 Output
Output Data Rate
Data available
Analogue
Output data rate
Data available
Digital
Output data rate
Data available
Inputs
Input Voltage range
https://en.racelogic.support//Product_Info/Sensors/Single_and_Dual_Antenna_Speed_Sensors/VBOX_Speed_Sensor_User_Guide/
125 kbit/s, 250 kbit/s, 500 kbit/s and 1 Mbit/s selectable
baud rate. Software controlled CAN termination.
Position, vehicle speed, heading, lateral acceleration,
longitudinal acceleration, satellite count, time, radius of
turn, altitude, Distance from Trigger, Trigger Time,
Trigger Velocity, True Heading.
Dependent on unit type and mode
NMEA and RL Serial, dependent on unit type
0 – 5 V DC
Either Speed, Lateral Acceleration, Longitudinal
Acceleration, or Lap Beacon
Low = 0 V, High = 5 V, Max. frequency 4.4 kHz
Speed or Lap Beacon
7 – 30 V DC
