Parameter
dddddddd
eeee
s
cc
Notes:
• The 32-bit floats are in Little endian format (low byte first or Intel format)
• The Brake distance number is in Big endian format (high byte first or motorola format)
https://en.racelogic.support//Product_Info/Sensors/Single_and_Dual_Antenna_Speed_Sensors/VBOX_Speed_Sensor_User_Guide/
Number of bytes
8 (MSB first)
4 (MSB first)
1 (MSB first)
2 (MSB first)
Description
IEEE float
Brake Distance
Distance since brake event (m), 64
bit IEEE double precision floating
point number
Event Time
Time of event from midnight
(seconds)
Status Flag
0x01 for brake trigger, 0x02 for
brake trigger active
See CRC Calculation
example below
