07 - VBOX Speed Sensor RS232/NMEA Output
The RS232 output is there to provide a connection to a computer so that you can configure the settings of the VBOX
Speed Sensor in the VBOX Setup
Racelogic Braketest format.
RS232 Racelogic Data Format
Protocol:
115200 Baud, no parity, 8 data bits, 1 stop bit
Message format:
$VB2100stttaaaaaaaaoooooooovvhhAAggGGcc
Parameter
$VB2100
S
ttt
aaaaaaaa
https://en.racelogic.support//Product_Info/Sensors/Single_and_Dual_Antenna_Speed_Sensors/VBOX_Speed_Sensor_User_Guide/
Software. The R232 output can also output NMEA format messages and the
Number of bytes
7
1
3 (MSB first)
8 (MSB first)
Description
Header
Sats
Number of satellites used
Time
Ticks since midnight UTC,
incrementing every 100 ms
Latitude
Double precision float 64 bit
(radians)
