GAS/LIGHT OIL BURNERS
MULTICALOR 500.1 PR
MULTICALOR 600.1 PR
Technical data
Operating instructions
Electric diagrams
Spare parts list
Gas train manual is
separate
22-11-2021
www.ecoflam­burners.com
MULTICALOR 500.1 PR TC SGT 230-400-50
MULTICALOR 500.1 PR TL SGT 230-400-50
MULTICALOR 600.1 PR TC SGT 230-400-50
MULTICALOR 600.1 PR TL SGT 230-400-50
MULTICALOR 500.1 PR TC SGT 230-400-50 NS 3143769
MULTICALOR 500.1 PR TC SGT 400-50 NS
MULTICALOR 500.1 PR TL SGT 230-400-50 NS
MULTICALOR 500.1 PR TL SGT 230-400-50 NS
MULTICALOR 500.1 PR TL S
MULTICALOR 600.1 PR TC SGT 230-400-50 NS 3143771
MULTICALOR 600.1 PR TL SGT 230-400-50 NS
MULTICALOR 600.1 PR TL S
EN
3142646
3142647
3142648
3142649
3143292
3142132
3143770
3148241
3143772
3145773
