GAS BURNERS
BLU 5000.1 PR
BLU 6000.1 PR
Technical data
Operating instructions
Electric diagrams
Spare parts list
Gas train manual is separate
www.ecoflam­burners.com
BLU 5000.1 PR TC SGT 230-400-50
BLU 5000.1 PR TL SGT 230-400-50
BLU 6000.1 PR TC SGT 230-400-50
BLU 6000.1 PR TL SGT 230-400-50
BLU 5000.1 PR TC SGT 230-400-50 NS
BLU 5000.1 PR TL SGT 230-400-50 NS
BLU 6000.1 PR TC SGT 230-400-50 NS
BLU 6000.1 PR TL SGT 230-400-50 NS
EN
3140410
3140411
3140413
3140414
3141758
3141759
3141761
3141762

Advertisement

Table of Contents
loading

Summary of Contents for Ecoflam 3140410

  • Page 1 Technical data Operating instructions Electric diagrams Spare parts list Gas train manual is separate BLU 5000.1 PR TC SGT 230-400-50 3140410 BLU 5000.1 PR TL SGT 230-400-50 3140411 BLU 6000.1 PR TC SGT 230-400-50 3140413 BLU 6000.1 PR TL SGT 230-400-50 3140414 BLU 5000.1 PR TC SGT 230-400-50 NS...
  • Page 2 Adjusting the max air flow rate Firing head setting Servomotor pre-setting Adjusting the intermediate burner capacity Pressure switch adjustment Servomotor: final setting Maintenance program Troubleshooting instructions Operating troubles Appendix Control box - Damper actuators Electrical diagrams Spare parts list 420010461400 www.ecoflam-burners.com...
  • Page 3: General Warnings - Conformity Declaration

    Ecoflam burners have been designed and built in compliance with all current regulations and directives. All burners comply to the safety and energy saving operation regulations within the standard of their respective performance range.
  • Page 4: Burner Designation

    For burners over 1700 kW gas train connection pipe must be ordered. Kits and accessories are managed and delivered separately. Component type BBCH Burner Body with Combustion Head (without gas train) GTCP Gas Train Connection pipe Gas Train (delivered separately) 420010461400 www.ecoflam-burners.com...
  • Page 5: Burner Description

    1 = operation on maximum capacity 2 = operation on minimum capacity 3 = automatic operation B - working lamp C - termal lock-out lamp D - fuse E - main switch I / O F - reset key 420010461400 www.ecoflam-burners.com...
  • Page 6 Gas governor / Filter Tightness control Modulation Kit Max Pressure switch Other accessories FGDR - FILTER KITTC- Model KITMD-RWF40 KITPRES50 Compulsory EN676 Compulsory > 1200 kW Probe-... KITPRES150 420010461400 www.ecoflam-burners.com...
  • Page 7: Technical Data

    Sound pressure level with silencer 85,7 86,7 Ambient temperature storage -20°…+70° C Min/Max Ambient temperature use -10°…+60° C GAS CATEGORY BY COUNTRY Gas category Country BE CH CZ DE DK ES FR GB GR HU NO PL 3P/B CY MT 420010461400 www.ecoflam-burners.com...
  • Page 8: Working Fields

    12000 13000 1000 2000 3000 4000 5000 6000 7000 8000 9000 10000 11000 14000 15000 16000 17000 adapt it to some special boiler Nm 3 /h 1000 1100 1200 1300 1400 1500 1600 1700 or application. 420010461400 www.ecoflam-burners.com...
  • Page 9: Overall Dimensions

    WARNING: Please follow the suggested dimension for the hole on the boiler flange in order to fit the burner. Make sure that between the boiler and the blast tube proper insulation is fitted. Packaging (only burner) BLU 5000.1 1580 1630 1090 BLU 6000.1 1580 1630 1090 420010461400 www.ecoflam-burners.com...
  • Page 10 Any failure of the flame signal at the end of position and proceed with the restart of the the safety period and a flame signal during burner. 420010461400 www.ecoflam-burners.com...
  • Page 11: Installation

    The setting of the mixing and ignition unit according to the boiler output will be performed during commissioning procedure. Ionization Probe Elettrodo di rivelazione 3. Check that the head is preset at 50%. MAIN SWITCH 0 - OFF 1 - ON 420010461400 www.ecoflam-burners.com...
  • Page 12 (furnace) and allow the boiler door to be GAS VALVES AND INSTRUMENTS GROUP must be duly certified. swivelled out if required. The gas valves and instruments group can be connected directly to the gas feed line. 420010461400 www.ecoflam-burners.com...
  • Page 13 WARNING: BLU 5000.1 Note that the head loss diagram is only indicative and does vary depending on the setting of the head. OUTPUT - Stm3/h 420010461400 www.ecoflam-burners.com...
  • Page 14 VGD 40.080 VGD 40.100 + F- DN100 VGD 40.100 VGD 40.125 + F- DN125 VGD 40.125 flow m LEGENDA Pf: Back pressure of furnace Pb: Pressure of burner (combustion head + complete gas train) Pin: Minimum inlet pressure 420010461400 www.ecoflam-burners.com...
  • Page 15 VGD 40.080 VGD 40.100 + F- DN100 VGD 40.100 VGD 40.100 + F- DN125 VGD 40.125 flow m LEGENDA Pf: Back pressure of furnace Pb: Pressure of burner (combustion head + complete gas train) Pin: Minimum inlet pressure 420010461400 www.ecoflam-burners.com...
  • Page 16 7.5 kW. the electrical scheme. For more information, please contact the LEGENDA Adapters, multiple plugs and extension Ecoflam staff. HLB: lock-out lamp cables may not be used for the STAB: two stages thermostat equipment’s power supply. HLF: burner on flame lamp...
  • Page 17 • Check that automatic furnace controller is unlocked and in its original position. • A standard-compliant measuring point must be available, the exhaust gas duct up to the measuring point must be free of leaks to prevent anomalies in the measurement results. 420010461400 www.ecoflam-burners.com...
  • Page 18: Exhaust Gas Test

    - and CO 2500 for heavy oil S (CO max = 15,60%) 2000 1500 = 21 CO max - CO gem = % 1000 gem = % CO measured on dry flue gases Fan capacity reduced by [%] 420010461400 www.ecoflam-burners.com...
  • Page 19 I. High flame position 90° II. Air flap position in standby 0° III. Ignition position gas 10° IV. Low flame position gas 15° (can be modified depending on the minimum output of the boiler) V. To VIII not used 420010461400 www.ecoflam-burners.com...
  • Page 20 Turn the burner off and start it again in order to check if the burner start properly otherwise adjust the ignition gas cam number III. GAS SETTING ENDED: switch the selector to automatic position. WARNING: Do not use the button cam drum release button. 420010461400 www.ecoflam-burners.com...
  • Page 21: Maintenance Program

    The exhaust gas loss can be calculated as follows: as follows: = exhaust gas temperature [°C] = combustion air temperature [°C] 0,37 0,49 = volumetric content of carbon = (195-22)( + 0,009) = 7,48% = (195-22)( + 0,007) = 7,83% dioxide [%] 10,8 12,8 420010461400 www.ecoflam-burners.com...
  • Page 22 In this case, check the position of the LANDIS LFL1.622 electrode, its electric connection and the earthing of the burner. LANDIS LFL1.333 Microammeter The ionization current is normally > 20 μA. 50 μA end of scale GAS FILTER CLEANING 420010461400 www.ecoflam-burners.com...
  • Page 23: Troubleshooting Instructions

    Capacity reduction due to lower Check gas pressure, clean filter, gas supply pressure replace cartridge if necessary Gas pressure regulator Replace regulating valve not regulating Check load control, Load control device does not close replace if necessary 420010461400 www.ecoflam-burners.com...
  • Page 24: Operating Trouble

    2 Shut-off on trouble because the flame signal has not occurred on the expiry of the (2nd) safety time (flame signal of main flame with burners having an ignition gas valve). 420010461400 www.ecoflam-burners.com...
  • Page 25 This will allow any desired position of the controller plate to be selected by hand. Drive and output will be coupled in the vertical position of the rocker arm. The fuel-air curve should be set over the full range of the cam plate so that operating safety will be retained also when the limit switch is overrun. 420010461400 www.ecoflam-burners.com...
  • Page 26 APPENDIX Electrical diagrams 420010461400 www.ecoflam-burners.com...
  • Page 27 APPENDIX Electrical diagrams 420010461400 www.ecoflam-burners.com...
  • Page 28 APPENDIX Spare parts 420010461400 www.ecoflam-burners.com...
  • Page 29 65325361 65325362 65325362 BLAST TUBE 65320433 65320433 65324435 65324435 GASKET 65321128 65321128 ANTIJAMMING FILTER 65323170 65323170 AIR DAMPER MOTOR SQM50.481A2 65322902 65322902 SILENCER 65074538 65074538 GAS CAM GROUP 65322355 65322355 TC = SHORT HEAD TL = LONG HEAD 420010461400 www.ecoflam-burners.com...
  • Page 30 420010461400 www.ecoflam-burners.com...
  • Page 31 420010461400 www.ecoflam-burners.com...
  • Page 32 Ecoflam Bruciatori S.p.A. reserves the right to make any adjustments, without prior notice, which is considered necessary or useful to its products, without affecting their main features Ecoflam Bruciatori S.p.A. si riserva il diritto di apportare ai prodotti le modifiche che riterrà necessarie o utili, senza pregiudicarne le caratteristiche principali.
