NRS Healthcare M48805 User Instructions

M48805
M48817
General Safety Warning
Please make sure that you read and follow these
instructions carefully. Keep these instructions in a
safe place for future reference.
1.

INTENDED USE

The height adjustable Extra Wide Mowbray toilet frame and seat has been designed to assist those who have
diffi culty in lowering onto or rising from a standard toilet. The comfortable plastic moulded seat off ers support in a
natural position. An optional fl oor fi xing kit is also available (F11572).
2.

SAFETY

WARNING: The maximum user weight must not be more
than 254Kg (40st).
DO NOT: Attempt to stand or climb on the product.
MAKE SURE: All legs are set at equal height to avoid
rocking.
2.1 Floor Fixing Safety
It is recommended that a suitably qualifi ed, competent
person installs this product.
Always check for concealed electrical cables and water
pipes when installing; also check your legal requirements
relating to earth bonding of extraneous metal parts.
Inspect the product at regular intervals for wear and
damage.
CAUTION: Never drill through pre-stressed concrete.
CAUTION: Use appropriate sized rawl plugs if this
product is being fi tted onto a concrete fl oor.
3.

UNPACKING

Remove the packaging and check all parts carefully.
Contact your supplier immediately if parts are missing or
damaged and do not try and assemble.
MOWBRAY TOILET SEAT & FRAME RANGE
Mowbray Frame & Seat Extra Wide
Mowbray Frame & Seat Extra Wide – Floor Fixed
USER INSTRUCTIONS
EXTRA WIDE
3.1 Contents:
Toilet Seat
Seat Frame Assembly
Leg Extensions with Ferrules
Leg Extensions with Floor Fixings
E-clips
4.

ASSEMBLY

These products are supplied fully assembled apart from
the seat.
4.1 Fit the Seat
Remove the seat from the bag and snap into place on the
centre bars of the frame.
5.

INSTALLATION

Adjust the height for the toilet and user before installation.
Only instal the product in an area where the mounting
surface and
Strengthening modifi cations to the fi xing surface may be
required.
Also check the type of substrate you intend to fi x it to
e.g. brick/block, timber or concrete. Always check that
the type of fi xing you are going to use is compatible with
the substrate.
Note: As the substrate can vary considerably, we cannot
recommend any particular fi xings; if in any doubt; consult
a reputable fi xings supplier for advice.
5.1 Adjust the Height
1. Remove the 4 x leg extension E-clips.
2. Slide the leg extensions to the required height, align
the holes and replace the E-clips.
Note: Make sure the leg extensions have all been set to
the same height.
3. Lift the toilet seat and lid.
1
Maximum User Weight
40st
254kg
Item M48805 M48817
substrate are structurally
1 1
1 1
4 n/a
n/a 4
4 4
sound.
