NRS Healthcare M48805 User Instructions

M48805
M48817
General Safety Warning
Please make sure that you read and follow
these instructions carefully. Keep these
instructions in a safe place for future reference.
1.

INTENDED USE

The Mowbray toilet frame and seat is designed to assist those who have diffi culty in lowering onto and rising
from a standard toilet. The plastic moulded seat off ers support in a natural position and the frame is height
adjustable.
2.

SPECIFICATION

1. One piece moulded plastic seat.
2. White epoxy coated frame.
3. Non-slip ferrules (free standing versions)
3.

SAFETY

WARNING: The maximum user weight must not be
more than 254Kg (40st).
DO NOT: attempt to stand or climb on the product.
MAKE SURE: all legs are set at equal height to
avoid rocking.
4.

UNPACKING

Remove the packaging and check all parts carefully.
Contact your supplier immediately if parts are
missing or damaged and do not try and assemble.
MOWBRAY TOILET SEAT & FRAME RANGE
Mowbray Frame & Seat Extra Wide
Mowbray Frame & Seat Extra Wide – Floor Fixed
USER INSTRUCTIONS
EXTRA WIDE
5.

INSTALLATION

Note: The free standing versions of this product are
delivered ready assembled. If your product is not
assembled, please follow instructions.
Fit the moulded toilet seat to the frame by clipping
onto the front and back cross tubes as shown in the
picture above.
To adjust the height:
1. Remove the 'e-clips', slide the legs to the
desired height, align the holes and re-insert the
'e-clips'.
2. Position frame around toilet.
3. Model M48817 only, secure the frame to the
fl oor by screwing down the fi xing legs.
Note: It is important to set all four legs to the same
height to prevent the frame from rocking. Height
adjustment is not possible once the legs are secured
to the fl oor
1
Maximum User Weight
40st
254kg
