This manual assumes that you have and know how to use the tools and equipment necessary
to safely perform service operations on your vehicle. This manual assumes that you are familiar
with typical automotive systems and basic service and repair procedures. Do not attempt to
carry out the operations shown in this manual unless these assumptions are correct. Always
have access to a factory repair manual. To avoid injury, follow the safety precautions contained
in the factory repair manual.

SAFETY PRECAUTIONS

To prevent electrical damage/burns/fires, always:
-
Disconnect the negative terminal of the battery before beginning installation.
-
When disconnecting wires/connectors, take extra care to avoid breaking/snapping the
connectors.
Do not misuse this product.
Misuse of this product may lead to engine damage.
-
Misuse of this product may lead to loss of original function.
-
Prior to installation, make sure the engine bay temperature has cooled to approximately
40℃/104°F
-
Failure to let the engine cool down properly can lead to severe burns.
Insert clean rags into open piping to prevent contaminants from entering the pipes.
-
If neglected, contaminants in the piping can lead to engine damage.
Make sure that all of the parts listed in the Parts List are included in the kit.
-
-
Reference the factory service manual for the vehicle when removing factory parts.
Be careful when handling this product; avoid dropping or subjecting it to excessive impact.
-
Failure to do so may result in product damage or improper installation.
Use the proper tools when tightening nuts and bolts. If over tightened, the bolts may
-
become damaged.
-
Keep the removed factory parts in a safe place for ease of re-installation at a later date (if
necessary).
Replace the air filter element at regular intervals:
-
(Recommended) Replace every 6,000~10,000km/4,000-6,400miles or every 6~12 months.
Replacement air filters are sold separately.
*Do not wash the air filters as the filtration properties will be degraded.
- There are certain conditions where, depending on dirt buildup, the filter may need to be
replaced earlier than the above recommended intervals .
- If the vehicle and the product are not maintained properly as mentioned above, the product
may not perform properly and the airflow meter sensor may not be able to detect the intake
air volume accurately; it can lead to engine damage or faulty conditions.

SUPER POWER FLOW Reloaded
70019-AF011
SUBARU LEGACY
Engine Type: EJ25 TURBO / Chassis Type: BM9.BR9
Model Year: 2009/5-
NOTICE
WARNING
CAUTION
- 1 -
Intake Kit
Ver. 20100310
E04511-F45020-00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 70019-AF011 and is the answer not in the manual?

Questions and answers

Summary of Contents for HKS 70019-AF011

  • Page 1 SUPER POWER FLOW Reloaded Intake Kit 70019-AF011 SUBARU LEGACY Engine Type: EJ25 TURBO / Chassis Type: BM9.BR9 Model Year: 2009/5- Ver. 20100310 NOTICE This manual assumes that you have and know how to use the tools and equipment necessary to safely perform service operations on your vehicle. This manual assumes that you are familiar with typical automotive systems and basic service and repair procedures.
  • Page 2 ADVICE ●  This product was designed based on and for a factory vehicle; however, additional fuel settings may be necessary depending on the vehicles specifications. ●  If the airflow meter intake air temperature sensor is dirty (dirt/oil build-up or no visible shine) it can be assumed that the sensor itself is also dirty. Using automotive parts cleaner, carefully clean the sensors.
  • Page 3 INSTALLATION OF THE KIT 1)Assemble the components as illustrated in Diagram 4. Ensure that the factory airflow meter sensor’s factory O-Ring is seated correctly, while making sure it does not get pinched in the airflow adapter pipe. Tighten with the supplied M4 screws. Do not over-tighten. Tightening torque: 2.0~3.0 N-m (0.2~0.3 kg-m).
  • Page 4 2) Temporarily install the air cleaner bracket to section B. (Dia.5, 6) 3)Temporarily assemble the kit parts. (Dia.6, 7) 4)Position the assembly to the vehicle, avoiding unnecessary contact with other parts of the vehicle. Once the position is determined, secure the assembly to the vehicle using the supplied hose clamps and bolts.
  • Page 5 5)Drill a 7mm hole on the air intake duct referring to diagram 9.(Dia.9) 6)Install the air intake duct. (Dia.10, 11)                                                          E04511-F45020-00 - 5 -...
  • Page 6 7)Reconnect the airflow meter sensor connector. 8)Reconnect the negative terminal to the vehicle’s battery. CONFIRMATION AFTER INSTALLATION: Check the following after the installation process is complete. (1)Check the following before starting the engine: Make sure pipes and hoses are routed and connected correctly. Make sure hose clamps are tightened.
  • Page 7 PARTS LIST No. Description QT Image Remarks No. Description QT Image Remarks 200- Filter Assy Flange Nut 80mm Airflow Adapter Bolt M6-15 Pipe 80mm Spring Joint Hose L=55 Washer Air Cleaner Flat Bracket Washer Air Duct Flange Nut Bracket Universal 80mm Screw M4-6...
