Power Factor Controller APFC 06
General & IO
PASSWORD
Enable : 1
CHANGE PASSWORD
: 0001
LOAD DEFAULT
No : 0
THD TO DISPLAY
F-THD : 1
UNIT ID
:0000
AUX I/P FUNCTION
None : 0
AUX 0/P FUNCTION
None : 0
Note: Total Harmonic Distortion (THD) can be distinguished as THDF (for "fundamental"), and THDR (for
"Root Mean Square"). THDR cannot exceed 100%. At low distortion levels, the difference between the two
calculation methods is negligible. For instance, a signal with THDF of 10% has a very similar THDR of 9.95%.
However, at higher distortion levels the discrepancy becomes large. For instance, a signal with THDF 266%
has a THDR of 94%.
System
Meas. Voltage Meas. Voltage
: 415
CUR CT Primary
Mains : 1000
PF Up Lim : Mains
[Ind :1] 0.999
PF Up Lim: Mains
Ind : 1 [0.999]
PF Low Lim: Mains
[Ind :1] 0.970
PF Low Lim: Mains
Ind :1 [0.970]
Freq 50 or 60 Hz
0 : 50 Hz
CT Polarity Chk
Disable : 0
Password: Enable or disable password.
Value: 0=Disable, 1=Enable.
Change Password: Set new value of password (4
digit). Factory default password is "0000"
Load Default: Loads factory set default parameters.
0=No, 1=Yes.
THD to Display: Type of THD to be displayed for V, I.
UNIT ID : APFC System / Panel ID no. can be set .
AUX IP FUNCTION : Set an action through auxiliary
.
input as per following – None : 0, O/P En Di (output
enable disable):1, Reset Bank Flt :2.
AUX OP FUNCTION :Program the auxiliary output to
become NC due to any of the following – None :0,
TripFlt:1, Sys Flt :2 , Out Of Step :3., Fan On-Off:4.
Measurement Voltage: Settable voltage from 110 V to
480 V, in step of 1 Vac. Factory Default = Nom. 415 V. 480 V, in step of 1 Vac. Factory Default = Nom. 415 V.
Cur CT Primary (Mains): Load Current Feedback
primary current , Limits: Lower: 0001 Upper: 6500.
Power Factor Limits: APFC-06 has one set point for Mains.
Upper & Lower limits can be defined as Upper PF and
Lower PF. PF limits can be set as inductive or capacitive.
Freq 50 or 60 Hz: User can select supply frequency 50 Hz
or 60 Hz according to measurement (feedback) supply.
The Over / Under Frequency limits are automatic.
CT Polarity:
accordingly Active Power Sign is changed. If it is enabled,
APFC controller work in two-quadrant mode, by way of
internally considering Active Power (kW) as always
"Positive". Disabled Mode is for four-quadrant mode where
sign of kW can be +Ve or -Ve.
This feature detects
- 21 -
C.T.
CT polarity and
