Summary of Contents for Minolta MN40WP
- Page 2 About this Manual Congratulations on purchasing the Minolta MN40WP Waterproof Camera! The contents of this manual are subject to change without notice. Note that the example screens and product illustrations shown in this User’s Guide may differ somewhat from the screens and configuration of the actual camera.
- Page 3 FCC: SAR standard Value: 1.6 W/Kg, Maximal Measure: 0.4 W/kg CE Mark Warning This is a Class B product, in a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures.
- Page 4 immediately. USB Adaptor Information • Do not expose the adapter to high temperatures or moisture places. Otherwise, it may cause fire or electric shock. • Do not attempt to repair, disassemble, change or transform the adapter. • Avoid sudden changes in temperature, which may cause condensation on the adapter’s internal surfaces.
- Page 5 Before Using the Camera Underwater Check the items below before using the camera underwater. Make sure that there are no foreign substances inside the battery cover. Make sure that the waterproof packing of the battery cover is not cracked or deformed. Make sure that the battery door is firmly closed and the battery cover security lock is in the LOCK position.
- Page 6 Precautions When Cleaning Do not puncture the microphone or speaker openings with a sharp implement. If the inside of the camera is damaged, the waterproof performance will deteriorate. Do not use soap, natural detergents, or chemicals such as benzene for cleaning.
- Page 7 The Battery Precautions for Use Note that the battery may become hot after use. Do not use the battery at ambient temperatures below 0°C (32°F) or above 40°C (104°F) as this could cause damage or malfunction. If you notice any abnormalities such as excessive heat, smoke, or an unusual smell coming from the battery, immediately discontinue use and consult your retailer.
- Page 8 water. Immerse the camera in a shallow basin filled with fresh water for 10 minutes. Immerse the camera in fresh water and shake it sufficiently in the water to remove any foreign substances from the camera. When the cameras is immersed in the water, a few air bubbles may come out from the water drain holes of the camera such as openings in the microphone or speakers.
- Page 9 1.1 Camera Interface 1. Zoom Out / Left 10. Lens 2. Zoom In / Right 11. Speaker 3. Flash / Up 12. Microphone 4. Delete / Down 13. Front LCD Screen 5. Mode 14. Power 6. Settings / OK 15. Switch Screen 7.
- Page 10 1.2 Button Function Description Function Description Power Press for 3 seconds to power on or off. Tap to access the settings menu and to confirm Settings | OK selected setting. In Video or Photo: Press to zoom-out. In Settings: Press to select submenu. Zoom Out | Left In Playback: Press to view multiple images on the screen.
- Page 11 2. First Use 2.1 To Open the Battery Door Unlock the battery door by sliding the battery door notch away from the opening. Use a fingernail or other pointy object when sliding the latch to get a better grip. 2.2 Installing the Battery Insert the lithium-ion battery into the battery compartment with the metal contacts facing the inside of the camera.
- Page 12 3. Close the memory card door by pushing it down and sliding the lock back into place. 4. To remove the memory card, simply push in and the card will eject back out. NOTE: Please format the memory card before using the camera (Caution, this will erase all data on the card).
- Page 13 2.4 To Lock the Battery Door 1. Press the battery door down firmly until it is completely flat. 2. While the battery door is pressed down, slide the door latch into the locked position as shown in the figure below. Use a fingernail or other pointy object when sliding the latch to get a better grip.
- Page 14 the screen. 2.8 Connecting to a Computer Your camera can connect to a computer to transfer photo and video files for viewing and editing, as shown below. Once connected and powered on, the camera’s screen will enter “Mass Storage” mode automatically. 2.9 Using the Zoom Function This camera has a digital zoom function.
- Page 15 2.10 Photo Mode Press the MODE button to switch to Photo Mode. The meaning of each icon within Photo Mode is explained in the table below: 1) Photo Mode 7) Memory Card Inserted 13) Light Exposure 2) Image Size (Resolution) 8) Battery Level 14) Image Sharpness 3) Image Quality...
- Page 16 2.11Video Mode Press the MODE button to switch to Video Mode. The meaning of each icon within Video Mode is explained in the table below: 1) Video Mode 6) Battery Level 10) Light Exposure 2) Video Size (Resolution) 7) Current Date 11) Image Sharpness 3) Video Quality 8) Metering...
- Page 17 3. Using the Camera 3.1 Photo Shooting Power the camera on and it will be ready to take pictures right away. You may press the MODE button to switch to another mode. 1. Line up your shot by looking at the LCD screen to see what is in the shot. 2.
- Page 18 4. Press the MODE button to exit the settings menu. 3.1.2 Image Quality The Photo Quality function determines the level of compression the camera uses when saving photos to a memory card. 1. In Photo Mode press the SETTINGS button. 2.
- Page 19 4. Press the MODE button to exit the settings menu. 3.1.6 Multi Snapshots (Photo Burst) This function allows to you capture 6 consecutive photos with one click of the PHOTO button. 1. In Photo Mode press the SETTINGS button. 2. Select ‘Multi Snapshots’ using the LEFT or RIGHT buttons. 3.
- Page 20 2. Select ‘Light Exposure’ using the LEFT or RIGHT buttons. 3. Press the UP or DOWN buttons to navigate the menu, and press the OK button to confirm your selected option (+3, +2, +1, 0, -1, -2, -3). 4. Press the MODE button to exit the settings menu. 3.1.11 ISO This function adjusts the light sensitivity in your photograph.
- Page 21 5. To set the current date and time use the UP or DOWN buttons to select Date Setup, and press the OK button to enter date setup menu. 6. Use the UP or DOWN buttons to change the highlighted field. 7.
- Page 22 4. Press the MODE button to exit the settings menu. NOTE: This will delete all of your media and cannot be undone. 3.1.19 Restore Default Settings Factory default settings can be restored in this menu. This function will not delete the media stored on the memory card, and will only restore all of the menu’s setting back to factory default settings.
- Page 23 3.2 Video Recording Power the camera on and press the MODE button to switch to Video mode. A camcorder icon will appear in the top left hand corner of the screen when you are in Video mode. 1. Line up your shot by looking at the LCD screen to see what is in view. 2.
- Page 24 button to confirm your required quality option (Normal, Fine, Super Fine), Super Fine uses the least amount of compression for saving, and as a result produces a higher photo quality. 4. Press the MODE button to exit the settings menu. 3.2.4 White Balance White Balance changes the color of light in your pictures, making it seem warmer or cooler depending on how the light you're shooting in affects the...
- Page 25 3.2.8 ISO This function adjusts the light sensitivity in your photograph. 1. In Video Mode press the SETTINGS button. 2. Select ‘ISO’ using the LEFT or RIGHT buttons. 3. Press the UP or DOWN buttons to navigate the menu, and press the OK button to confirm your selected option (ISO Auto, ISO 100, ISO 200, ISO 400).
- Page 26 3.2.12 Auto Power Off This function sets the duration of time in which the camcorder will wait with no user input before automatically powering off. 1. In Video Mode press the SETTINGS button. 2. Select ‘Auto Power Off’ using the LEFT or RIGHT buttons. 3.
- Page 27 Playback Mode Videos and photos captured on your camera can be easily played back. 1. Press the MODE button to enter Playback mode, a play icon will display in the top left corner of the screen. 2. Press the UP or DOWN buttons to cycle through the captured videos and photos stored on the memory card.
- Page 28 3.4.3 Protect/Lock This function protects the photo/video file. The file will be protected from being deleted accidentally. Files must be unprotected to be deleted. 1. In Playback Mode press the SETTINGS button. 2. Select ‘Protect/Lock’ using the LEFT or RIGHT buttons. 3.
- Page 29 4.1 Technical Specifications Model Number Minolta MN40WP Lens Fixed Focus • f=8.15mm • F/3.0 Zoom 16X Digital Zoom Image Sensor 13MP CMOS Sensor Shutter Electronic • Anti-Shake Image Stabilization JPEG: 48 MP • 30 MP • 24 MP • 20 MP • 16 MP • 12 MP Pixels (photo) •...
- Page 30 Minolta is a registered trademark of JMM Lee Properties, LLC and is used in the United States by Elite Brands Inc. under license. 40 Wall Street, 61st Floor, New York, NY 10005 USA • Tel: 800-441-1100 www.minoltadigital.com • www.elitebrands.com Copyright © 2021 Elite Brands Inc.
Need help?
Do you have a question about the MN40WP and is the answer not in the manual?
Questions and answers
Putting in the battery: instructions not clear
To insert the battery in the Minolta MN40WP:
1. Unlock and open the battery door by sliding the battery door notch away from the opening. Use a fingernail or a pointy object for better grip.
2. Insert the lithium-ion battery into the battery compartment with the metal contacts facing the inside of the camera. The battery only fits in one direction.
This answer is automatically generated
I connected the camera with the computer, as I have done many times before and it is not going into mass data storage and uploading my pictures. I also used the computers at the library and it did not work there either (it had worked a several times previously when I used the library computers).
Your Minolta MN40WP camera may not be entering mass data storage mode for several reasons:
1. Connection Issue – Ensure the camera is properly connected to your PC using the provided USB cable.
2. Memory Card Issue – Check if the memory card is inserted correctly and not damaged.
3. Camera Settings – Some cameras require selecting a specific mode for data transfer. Check if your camera has such an option.
4. USB Port or Cable Problem – Try using a different USB port or cable to rule out hardware issues.
5. PC Compatibility – Ensure your computer recognizes the device. If not, try restarting the computer or checking for driver updates.
If the issue persists, try removing the memory card and inserting it directly into a computer using a compatible card reader.
This answer is automatically generated
I connected the camera with the computer, as I have done many times before and it is not going into mass data storage and uploading my pictures.
The Minolta MN40WP camera may not be entering mass data storage mode due to the following reasons:
1. Connection Issue – Ensure the cable is properly plugged into both the camera and the computer.
2. Memory Card Not Inserted – The camera may require a memory card to be present for file transfer.
3. Incorrect Mode – Some cameras require switching to a specific mode for USB data transfer.
4. Driver or Compatibility Issue – The computer may not recognize the camera due to missing drivers or compatibility issues.
5. Damaged USB Port or Cable – A faulty USB cable or port may prevent connection.
Try using a different cable, checking camera settings, or inserting the memory card directly into the computer.
This answer is automatically generated
How do you set the date and time
Can’t find uploaded pictures on computer
Taking selfie
why is it saying card error? and not letting me anything ?
