SIGNAL WIRING AND PRO-BUS INSTALLATION INSTRUCTIONS

NOTE: Refer to "Illustration 1, NET-EC Typical Playback System Diagram" in the "Overview of NET-EC Wiring
Connections" section of this quick guide and the illustrations on this page.
Start
Connect switcher (A)
to your NET-EC:
Will NET-EC be used for
device control?
If using, connect Tascam DV-D6500
DVD player cables to the DVply ports
(B) on your NET-EC.
Connect one end of an RJ-11 cable to Event
Controller's PRO-BUS output (C) and the other
cable end into the input of a PRO-BUS interface.
Using attached device cable, connect
PRO-BUS interface to VCR/DVD player.
Are all of the VCRs/DVD players
connected to a PRO-BUS interface?
Yes
Set the DIP switches on each PRO-BUS
(see instructions included with PRO-BUS).
DIP Switches
Page 4 of 7
Connect power supply
No
(D) to NET-EC and plug
Event Controller into
Yes
No
from the output of the first
Connect power supply
(D) to NET-EC and plug
Rear View of NET-EC
Configure NET-EC for Ethernet
network access (E). See the
Configuration Instructions"
AC outlet.
section of this quick guide.
Connect an RJ-11 cable
PRO-BUS to input of
another PRO-BUS.
Event Controller into
AC outlet.
B
"Ethernet Network
PRO-BUS Interface Connections
Configure NET-EC for
Ethernet network access (E).
See the "Ethernet Network
Configuration Instructions"
section of this quick guide.
A C E D
End
NET-EC
Input (Source)
Equipment
PRO-BUS
Interfaces
End
